LD128EN-100 总线设备编址器
LD128EN-100series bus equipment addressing device
Installation and Operation Manual
版号
Version No.
V1.0
安装使用说明书
编制 Drafted by ：
审核 Reviewed by ：
批准 Approved by ：
信息
Details
编号： LD-FJ/Y-219-02 SS
共
页
日期 Date ： 2011.4.30
席红梅
日期 Date ： 2011.4.30
武丽
日期 Date ： 2011.4.30
陈洪颖
更改人
日期
Modified by
Date
Advertisement
Table of Contents
Summary of Contents for Leader LD128EN-100 Series
- Page 1 编号： LD-FJ/Y-219-02 SS LD128EN-100 总线设备编址器 安装使用说明书 LD128EN-100series bus equipment addressing device Installation and Operation Manual 共 页 编制 Drafted by ： 日期 Date ： 2011.4.30 席红梅 审核 Reviewed by ： 日期 Date ： 2011.4.30 武丽 批准 Approved by ： 日期 Date ： 2011.4.30 陈洪颖...
- Page 2 LD128EN-100 安装使用说明书 V1.0 LD128EN-100 总线设备编址器安装使用说明书 目 录 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 目 录 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 第一章 概述 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 第二章 部件说明 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 第三章 结构特性 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 第四章 操作说明 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 第五章 注意事项 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 第六章 售后服务 ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ 附录： LD6800E/LD6800EC 模块类型表 LD-FJ/Y-219-02 SS 北京利达华信电子有限公司...
- Page 3 LD128EN-100 安装使用说明书 V1.0 第一章 概述 1.1 产品特点 LD128EN-100 总线设备编址器是为 LD128EN 总线产品而设计的。通过编址器对 LD128E 系列及 LD128EN 系列总 线产品的地址进行读写。携带方便、操作过程简单。 1.2 主要用途及适用范围： 各种工业及民用建筑中。 1.3 产品名称及型号 总线设备编址器， LD128EN-100 1.4 对环境及能源的影响： 产品的壳体为塑料注塑而成，无污染。 第二章 部件说明 2.1 液晶指示说明 液晶由 4 位数字组成。如（图 1 ） （图 1 ） 液晶上第 4 位表示状态，显示字母表示编址器的功能：显示 P 时为写总线设备的地址；显示 C 时为读总线设 备的地址；显示...
- Page 4 LD128EN-100 安装使用说明书 V1.0 “ “ 表示： L”→ 写类型； E”→ 读类型； “ ” “ “ ” “3”→ 写总线漏电设备的 通道数 ； 4”→ 读总线漏电设备的 通道数 ； “ “9”→ 写总线消火栓的反馈地址； 7”→ 读总线消火栓的反馈地址； “ “ ” 备注：显示 8” 为读编址器的软件版本号功能，按 确定 后显示的数字为软件版本， 现为 170 ，表示编址器的软件版本是 V1.70 “...
- Page 5 LD128EN-100 安装使用说明书 V1.0 开关在编址器的上侧，向左（ ON ）是开，向右（ OFF ）是关。 4.3 、实例说明 4.3.1 对一个探测器写入地址 128 号 “ ” “ 按 写 按键，使液晶的第 4 位显示 P” 。 “ ” “ “ 按 移位 键，将移位标记移至百位，此时按 +”/“-” 按健，使液晶百位显示为 1” ； 将移位标记 “ “ “ 移至十位，此时按 +”/“-” 按健，使液晶十位显示为...
- Page 6 LD128EN-100 安装使用说明书 V1.0 ( 图 9) 注意：更换前应关闭电源开关，从电池盒中将电池与电池扣拆离。 5.2 自动关机后的开机 当编址器由于长时间（无按键操作 3 ～ 4 分钟）不进行操作，编址器自动关机；编址器自动关机后，将编址器 的电源开关置于关的位置，再置于开的位置，编址器开启，恢复正常工作状态。 5.3 配件 二总线夹子线（带中号鳄鱼夹红、黑各一个） 一根 备用二总线接线插头 一个 安装使用说明书 一份 第六章 售后服务 我公司保证所有出厂产品均为合格产品，发现问题请及时与我公司客户服务中心联系，我们将竭诚为您 服务。用户不得自行拆开或维修，否则后果自负。 公司名称：北京利达华信电子有限公司 公司地址：北京经济技术开发区荣京东街 17 号 邮政编码： 100176 公司电话： 86-10-67876688 公司传真： 86-10-67876684 售后服务热线： 86-10-67876671 。 网址：...
- Page 7 LD128EN-100 安装使用说明书 V1.0 LD6800E/LD6800EC 附录： 模块类型表 类型 型号 具体内容描述 类型值 类型 型号 具体内容描述 类型值 LD6800E-2 脉冲启动 1 回答 2 取反 86 直流启动 单输入 LD6800E-2 脉冲启动 1 回答均取反 直流启动回答取反 LD6800E-1 输出控 LD6800E-2 脉冲启动 脉冲启动 2 制模块 LD6800E-2 脉冲启动 2 回答 1 取反 89 脉冲启动回答取反...
-
Page 8: Table Of Contents
LD128EN-100 Operation, installation, user manuals and product datasheets V1.0 User’s manual for LD128EN-100 series bus equipment addressing device Table of Contents Table of Contents ················································································································· Chapter One Summary ······································································································· Chapter Two Instruction of components ··············································································· Chapter Three Structure····································································································· Chapter Four Operation instruction ·····················································································... -
Page 9: Chapter One
Summary Summary LD128EN-100 series bus equipment addressing device is designed for LD128E series bus products. Using it the address and type of LD128E and LD128EN series bus products can be configured and read out. Besides, it is portable and easy to operate. -
Page 10: Chapter Three
3-4 top view Chapter Four Operation instruction LD128EN-100 series wiring method of bus equipment addressing device 4.1 、 On top of the addressing device there is a socket, used for bi-bus plug of equipment. Please open the battery cover at device bottom, put in 9V battery to fit with the battery backle. -
Page 11: Chapter Five
When the addressing device is automatic shut down after longtime not operated (3 to 4 minutes), switch off the power supply and then switch it on again, normal operating condition is regained. 5.3 Accessories Bi-bus clip wire (middle size clip red and black) Secondary bi-bus plug User’s manual LD-FJ/Y-219-02 SS Beijing Leader Huaxin Electronics Co., Ltd... -
Page 12: Chapter Six
However, customers shall bear the consequences of self-repairing and maintenance. Company name ： Beijing Leader Huaxin Electronics Co. Ltd Address ： No. 17 Eastern Rongjing Road, Beijing Economy-technology Developed Area Postcode ：... -
Page 13: Appendix ： Type Table Of Ld6800E Module
LD6800E-2 Impulse start 1 LD6800E-2 answer 2 reversed Impulse 1 start, answe r Impulse start, LD6800E-2 LD6800E-2 answer 1&2 reverse d 1 reversed P.S.: LD6800EC-1 refers to LD6800E-1; LD6800EC-2 refers to LD6800E-2 LD-FJ/Y-219-02 SS Beijing Leader Huaxin Electronics Co., Ltd...
