SAFETY-VIEW PLUS K. D. 16-PERSON
ASSEMBLY INSTRUCTIONS
1.
(heck material received against the packing list. First check the number of packages received and then
check the contents of each package.
2. (heck material received for damage. If damage has occurred. secure a "damage not at ion" from the carrier.
3. Identify each part as it is unpacked and put like parts together as close as possible to the working area
in which they are to be assembled.
4. Be careful to use the correct hardware as specified in the assembly instructions.
5. Items with suffix (xx) are available options.
IN THE INTEREST OF SAFETY. ALL LOCKERS MUST BE SECURELY ANCHORED TO THE FLOOR AND/OR WALL.
FOR SAFETY. HANDLE ALL COMPONENTS CAREFULLY AND WEAR WORK-GLOVES WHEN ASSEMBLING LOCKERS.
STOCK LOCKER
General Instructions
CAUTION
INST ALL ALL UNITS PLUMB AND TIGHTEN ALL HARDWARE SECURELY
RETAIN INSTRUCTIONS FOR FUTURE REFERENCE.
www.StoreMoreStore.com | 1-855-786-7667
INSTRUCTION ASY-H-SVP16K0-1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Safety-View Plus KD Stock Locker and is the answer not in the manual?

Questions and answers

Summary of Contents for STOREMORESTORE Safety-View Plus KD Stock Locker

  • Page 1 IN THE INTEREST OF SAFETY. ALL LOCKERS MUST BE SECURELY ANCHORED TO THE FLOOR AND/OR WALL. FOR SAFETY. HANDLE ALL COMPONENTS CAREFULLY AND WEAR WORK-GLOVES WHEN ASSEMBLING LOCKERS. INST ALL ALL UNITS PLUMB AND TIGHTEN ALL HARDWARE SECURELY RETAIN INSTRUCTIONS FOR FUTURE REFERENCE. www.StoreMoreStore.com | 1-855-786-7667 INSTRUCTION ASY-H-SVP16K0-1...
  • Page 2 STRIKE PLATES ARE OPTIONAL - INCLUDES TWO RIVETS© TWO-YEAR WARRANTY HALLOWELL KO LOCKERS ARE COVERED AGAINST ALL DEFECTS IN MATERIALS AND WORKMANSHIP EXCLUDING FINISH, DAMAGE RESULTING FROM DE LIBERA TE DESTRUCTION AND VANDALISM FOR A PERIOD OF TWO YEARS. www.StoreMoreStore.com | 1-855-786-7667 INSTRUCTION ASY-H-SVP16K0-2...
  • Page 3 DESCRIPTION OF PART(S) NEEDED & PART COMPANY NAME & CONT ACT PERSON NUMBER(S) AS SHOWN IN PARTS LIST WHERE THE PRODUCT WAS PURCHASED FROM COLOR IF REQUESTING PARTS BY TELEPHONE. ASK FOR CUSTOMER SERVICE & PROVIDE THE ABOVE INFORMATION. www.StoreMoreStore.com | 1-855-786-7667 INSTRUCTION ASY-H-SVP16K0-3...
  • Page 4 ASSEMBLY OF NUMBER PLATE HARDWARE USED FOR MAIN LOCKER ASSEMBLY (}:mm 10 - 24 X 3/8" MBT200 SLOTLESS BOLT @ N201 HEX NUT @ TIGHTEN NUT WITH A NUT DRIVER OR WRENCH (SCREW IS TAMPER RESIST ANT) www.StoreMoreStore.com | 1-855-786-7667 INSTRUCTION ASY-H-SVP16K0-4...
