Page 1
2 1A 24V Relays. Description of the unit's components Waterproof seal Removable memory LEDs EC standard 6 Switches Terminals Settings and reset Waterproof cables pass through Installation and user guide for the EEN-REC3-RW receiver Page 1 / 6 V233 – 0012 – AA...
Page 2
Drill the holes as accurately as possible in the cable grommets to prevent any water seeping into the receiver. Failure to comply with this requirement will void the warranty. Installation and user guide for the EEN-REC3-RW receiver Page 2 / 6...
Page 3
Activating the control unit To activate the EEN-REC3-RW receiver, you must program the remote controls from the website: Locate the serial number of the unit you wish to activate. Log into the website using your login and password or by opening an account ("create an account"...
Page 4
The 2-button remote controls do not operate this mode Note: • Switch 5 is not used. • Switch 6 resets the EEN-REC3 HF-RW receiver (See below). Installation and user guide for the EEN-REC3-RW receiver Page 4 / 6 V233 – 0012 – AA...
Page 5
As soon as the LED flashes every 3 seconds, the reset has been completed and the receiver has returned to its unused state. Standards The EEN-REC3-RW complies with the R&TTE Directive 1999/5/EC: electrical safety standard EN 60950(2000) applied, EMC standard EN 301 489-3 (2000) applied, radio standard EN 300 220-3 (2000) applied.
Page 6
Sizes Installation and user guide for the EEN-REC3-RW receiver Page 6 / 6 V233 – 0012 – AA...
