Summary of Contents for E.L.M. Leblanc TRL 7.26 RF
- Page 1 Machine Translated by Google TRL 7.26 RF User manual OK / Registered models and patents • Ref 6720816708 (2015/05) FR – PPLIMW15228Ab Room thermostat with weekly programming with radio frequency A passion for service and comfort...
-
Page 2: Table Of Contents
Other symbols Symbol Meaning ÿ Step to follow ÿ Reference to another passage in the document • Enumeration/Registration in the list – Enumeration / List entry (2nd level) Tab. 1 TRL 7.26 RF – 6720816708 (2015/05) -
Page 3: General Safety Instructions
2.1 Declaration of Conformity The manufacture and operation of this product comply with the European directives in force as well as the additional conditions required by the country concerned. Conformity has been proven by CE marking. TRL 7.26 RF – 6720816708 (2015/05) -
Page 4: Display
Adjust the hours using the + or - buttons. The ambient temperature reappears after a few seconds. The TRL now maintains room temperature to prevent ÿ Press the OK button. ÿ freezing. Adjust the days using the + or - keys. TRL 7.26 RF – 6720816708 (2015/05) - Page 5 9 preset programs and 4 user programs are available. ÿ By Your user program will now follow if you place the TRL in “Auto ” mode. pressing the + or - buttons the program number starts flashing. TRL 7.26 RF – 6720816708 (2015/05)
-
Page 6: Special Functions
You can make it easier to lock by pressing the clip on the left side. 6 Summary of the instruction manual A summary of the instruction manual is available on the side of the TRL. 0 010 006 684-001 0 010 007 329-001 Fig. 5 TRL 7.26 RF – 6720816708 (2015/05) -
Page 7: Using The Receiver
ÿ Check that there is no interference from a device on the 868.3 MHz frequency (permanent emission). If the yellow LED [2] does not light up: ÿ Check the connection of the receiver. ÿ Check the mains supply (230 VAC). TRL 7.26 RF – 6720816708 (2015/05) -
Page 8: Technical Specifications
868,3 MHz, <10 mW. Radio frequency Distance of approximately 100 meters in open field. Distance of approximately 30 meters in residential area. Certifications THIS. EN 300220-3, EN 301489 (Radio frequency certifications) TRL 7.26 RF – 6720816708 (2015/05) - Page 9 Machine Translated by Google...
- Page 10 Machine Translated by Google...
- Page 11 Machine Translated by Google...
- Page 12 Machine Translated by Google elm leblanc - head office and A technical team of specialists answers all factory: 124, 126 rue de Stalingrad - F-93711 Drancy Cedex your questions live: Monday to Friday from 8:00 a.m. to 5:30 p.m. www.elmleblanc.fr A passion for service and comfort elm leblanc and its logo are registered trademarks of Robert Bosch GmbH Stuttgart, Germany.
