North American Tool 6274 Operating Instructions

Cordless Screwdriver
CALIFORNIA PROPOSITION 65
WARNING: You can create dust
when you cut, sand, drill or
grind materials such as wood,
paint, metal, concrete, cement,
or other masonry. This dust
often contains chemicals
known to cause cancer, birth
defects, or other reproductive
harm. Wear protective gear.
WARNING: This product or its
power cord may contain
chemicals, including lead,
known to the State of California
to cause cancer and birth
defects or other reproductive
harm. Wash hands after
handling.
Specifications
Screwdriver:
Rechargeable battery voltage:
4.8V
Max. Speed: 150rpm
Max. Torque: 2.5Nm
Battery: Ni-CD
Battery capability : 600mAh
Forward/reverse switch
LED Light
To load a bit:
1. Rotate the
magazine to
find desired
bit
2. Remove
the bit by
lifting up and
out
Charger:
Input: 120V -60Hz
Protection against electric
shock: Class II
Protection against moisture:
IP20
Output: 6V DC, 300mA
Charge time: about 3-5 hours
feedback@natitools.com
To unload a bit:
1. Remove the drill bit
from chuck
2. Rotate drill bit down into
"lock" position
This unique cordless screwdriver
is equipped with a "flip bit" quick-
loader for maximum convenience.
3. Insert the
bit into the
chuck
To charge the unit:
1. Connect the charger adaptor
to a power outlet and insert the
plug into the socket on the
handle.
2. The red light on the battery
display will light up once the
adaptor is connected to a power
source.
3. Once the battery is completely
charged, the red light will turn off.
If possible, remove the adaptor
after the battery is fully charged.
Model: 6274
8806274 3/12
