- Page 1 M1 Digital Console Assembly & User Instructions Model No: XTTM1-C-101 Manual P/N: 5815901-Rev A...
-
Page 2: Table Of Contents
M1 Digital Console Assembly & User Instructions Table of Contents IMPORTANT SAFETY INSTRUCTIONS ..............1 Electrical Specifications and Disposal Instructions..........1 M1 Digital Console Assembly Instructions............2 Assembly Preparation................2 1. Remove Cover Plate................3 2. Install Batteries and Attach Console ............4 3. Connect Cables, Install Shroud and Handle Grip ........5 M1 Digital Console User Instructions ..............6 Console Buttons ..................6 Console Setup ...................7... -
Page 3: Important Safety Instructions
• Use this machine only for its intended use as described in this manual. Use only attachments recommended by Torque Fitness. • Clean with a damp cloth. Do not spray cleaner directly on the display; moisten the cloth first, then wipe the display. Do not allow moisture from perspiration to accumulate as it is extremely corrosive. -
Page 4: M1 Digital Console Assembly Instructions
M1 Digital Console Assembly Instructions Assembly Preparation Unpack all contents, removing all packaging and protective bags. Verify all items shown below are included and undamaged. A #2 Phillips screwdriver (not provided) is required to complete the assembly. Digital Console ... -
Page 5: Remove Cover Plate
Remove Cover Plate 1. Insert M1 handles (if they are not currently installed), then tip M1 upright to rest on handles. 2. Use #2 Phillips screwdriver to remove two (2) screws, two (2) nuts, and the resistance handle grip; set aside for re-installation in assembly step 3-5. -
Page 6: Install Batteries And Attach Console
2. Install Batteries and Attach Console 1. On back of console, remove battery cover thumb screw and battery cover; set aside. 2. Slide out battery carriage and insert batteries in carriage as shown. 3. Replace battery cover and secure to back of console with thumb screw. 4. -
Page 7: Connect Cables, Install Shroud And Handle Grip
3. Connect Cables, Install Shroud and Handle Grip 1. Lower M1 base back to its standard position on the floor. 2. Balance the console/shroud assembly on the base as shown, then connect the two (2) cables from mast to cables in base (not shown). One cable pair has 2-pin connectors;... -
Page 8: M1 Digital Console User Instructions
M1 Digital Console User Instructions Console Buttons The console features three (3) buttons to control the digital display: END / RESET Press this button to end a workout and activate the workout summary display. Press and hold the button for three seconds to reset the console data to the neutral state or cancel programming. -
Page 9: Console Setup
Console Setup (Optional) The default console values for Units, Beep, and Backlight may be changed if desired. Follow these steps to verify or change the settings: Press and hold “DATA” and “END” simultaneously for three seconds to access the Setup screens. Press “DATA”... -
Page 10: Display
Display The digital LCD includes the following data at the top of the screen: USER This field identifies the current user. The default value is 1 (”User 1”). A multi-user workout can have up to four (4) users. TIME During a workout, this field displays the elapsed time of the current User’s workout, actively counting up (in minutes:seconds). -
Page 11: Limited Product Warranty
Canada and not transferable to any other person. What is covered Torque Fitness warrants that this product is free from defects in materials and workmanship, when used as intended, in normal conditions and provided proper care and maintenance as described in the product’s Assembly and User Instructions. - Page 12 Toll free: 1-877-TORQUE5 (1-866-664-9894) 11201 Xeon Street NW Ste 101 or 763-754-7533 (8:30 am – 5:00 CST). Coon Rapids, MN USA 55448 For sales: sales@torquefitness.com www.torquefitness.com For service: service@torquefitness.com © 2022 Torque Fitness. All rights reserved. P/N 5815901 REV A 11/2022...
