50XM5 Installation Guide
50" Plasma Display

Display dimensions

Control Buttons
www.necvisualsystems.com
0.78
0.78
0.78
0.78
0.78
15.20
4.92
AC Inlet
Speaker Terminal
44.33
43.55 (SCREEEN AREA)
48.11
18.11
NEC Solutions (America), Inc.
Visual Systems Division
Filter Surface
20.55
LED & IR
1.45
IR
2.46
5.94
PX-50XM5
Rev 1.2
Power Button
Page 3 of 10
