Summary of Contents for RoyalFire RFZ0415
- Page 1 4 . 2 k w E C O S t e e l Mu l - f u e l S t o v e I N S T R U C T I O N MA N U A L S K U : 1 0 6 8 0 4 Mo d e l : R F Z 0 4 1 5...
-
Page 2: Installation Instructions
USER GUIDE PLEASE RETAIN THIS GUIDE FOR FUTURE REFERENCE Please read this user guide carefully when you assemble, install, operate and maintain your stove. If you have any more questions, please contact your local dealer. Nominal Heat Energy Item Code Dimension (W*D*H) Weight output... -
Page 3: Installation
1.1. Safety Advice 1.1.1. Handling Necessary facilities must be available for loading, unloading and site handling. 1.1.2. Metal Parts Be careful of personal injury when installing of maintaining this appliance. 1.1.3. Other possible injuries The stove contains no harmful materials, but if there is a possibility of using any dangerous materials during installation then please seek specialist guidance and use appropriate protective equipment. -
Page 4: Material Clearances
2.4. Air Supply A permanent, unobstructed air opening is essential for the room or space containing this appliance. The air opening should be at least 3625mm when a draught stabilizer is equipped. Due care for air requirements will need to be taken if any other appliances are permitted to work in the same room and space. -
Page 5: Burning Wood
3.2.1. Primary Air Primary air is controlled through the assembly on the bottom of the door. This provides a conventional air draught which passes through the fuel bed. The primary air intakes can be adjusted to control the fire in combustion chamber. -
Page 6: Lighting The Stove
3.7. Refueling on to a low fire bed If there is insufficient burning material in the fire bed to light a new fuel charge, excessive smoke emission can occur. Refueling must be carried out onto enough glowing embers and ash that the new fuel charge will ignite in a reasonable period. -
Page 7: Troubleshooting
5.2. Baffle plate Remove and clean the baffle plate once a month to avoid soot or fly ash. Block the flue ways and produce dangerous fume emission. 5.3. Fireproof glass Use a proprietary glass cleaner to clean the glass when cool. Any material that may damage the glass should not be used to clean the panel. -
Page 8: Technical Information
TECHNICAL INFORMATION Z0415 Wood – Primary Fuel Smokeless Fuel Nominal Heat Output 4.1 kW 4.5 kW Efficiency 75.4 % 79.2% CO at 13% O2 0.10vol% 0.09vol% PM at 13% O2 23 mg/m3 24 mg/m3 OGC at 13% O2 93 mg/m3 45 mg/m3 246 ℃...
