ＬＣＯＳ-ＳＬＭ

X15213 Series

OPERATION MANUAL

・Please read this operation manual carefully before using this device.

・Failure to follow the instructions in this manual

may result in a serious accident.

・Keep this manual in a convenient location at all times.

Doc. No. LEJ-B60002

First edition Mar. 18, 2021

Table of Contents

Need help?

Do you have a question about the LCOS-SLM X15213 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Hamamatsu LCOS-SLM X15213 Series

Page 1 ＬＣＯＳ-ＳＬＭ X15213 Series OPERATION MANUAL ・Please read this operation manual carefully before using this device. ・Failure to follow the instructions in this manual may result in a serious accident. ・Keep this manual in a convenient location at all times. Doc. No. LEJ-B60002 First edition Mar.
Page 2: Introduction
1. Introduction Be sure to read it.  Be sure to read "Safety Precautions" before use.  Read this operation manual carefully before using the product.  Keep this manual in a safe place and read it when necessary. 2. Before using the device ...
Page 3: Safety Precautions
3. Safety Precautions Please be sure to follow the rules. This device is a Class II device specified in the IEC 61010 -1 standard (Safety requirements for measurement, control and laboratory electrical equipment) (Equipment with protective grounding terminal). In order to use the device correctly and safely, observe the following safety precautions when operating the device.
Page 4: Warning
Warning ■Handling the Power Cable Turn off the power before installing or removing cables, and then hold the connectors. Do not operate the product with wet hands or mount or remove the cable. There is a risk of electric shock or malfunction and it is very dangerous. ■Cables Do not damage, or place heavy objects on cables.
Page 5: Caution
Caution Be sure to read the following precautions before using the product. ■This equipment is a precision optical instrument. (a) Do not apply excessive vibration or impact. (b) Do not store or operate in a dusty or wet environment, or at high temperature and humidity. (c) Do not touch or scratch the opening of the LCOS-SLM.
Page 6: Table Of Contents
Table of Contents Introduction ............................... 1 Before using the device ........................... 1 Safety Precautions ........................... 2 Warning .............................. 3 Caution ............................... 4 Overview ..............................6 Characteristics ............................7 Absolute maximum ratings ......................... 7 Operating Environment Conditions ....................7 LCOS-SLM Head ..........................7 LCOS-SLM Controller .........................
Page 7: Overview
4. Overview LCOS-SLM is a liquid-crystal on silicon (LCOS) spatial light modulator that can modulate only the phase of incident light. The phase of the incident light can be controlled arbitrarily by generating and displaying an image using a DVI output device (PC, etc.). LCOS-SLM has the following features:.
Page 8: Characteristics
5. Characteristics Absolute maximum ratings Parameter Value Unit Operating temperature + 10 to + 40 (no condensation) °C Storage temperature -20 ~ + 55 (no condensation) °C Note1) Be careful of humidity because humidity can cause characteristic deterioration. Note2) Since LCOS-SLM is temperature dependent, it is recommended to use it at an ambient temperature of about 25 °C.
Page 9: Lcos-Slm Controller
LCOS-SLM Controller Parameter Value Unit Input power supply voltage ± 5 Allowable voltage fluctuation Current consumption Digital Video Interface (DVI-D) Input signal USB-B (2.0 High speed) Weight AC Adapter Parameter In/Out Value Unit Power supply voltage Input 100 AC to 240 AC Frequency Input 50/60...
Page 10: Internal Configuration
6. Internal configuration As shown in Fig. 2, the LCOS-SLM consists of a glass substrate, a transparent electrode, an alignment film, a liquid crystal layer aligned in parallel, a dielectric multilayer mirror, and a silicon substrate. An active matrix circuit is formed on the silicon substrate to apply voltage to the pixel electrode and the pixel electrode. The number of pixels of the X15223 series is 1272×1024, and arbitrary control is possible for each pixel.
Page 11: Names And Descriptions Of Parts
7. Names and descriptions of parts This section describes the names and descriptions of each part of the device and the bundled product. LCOS-SLM Head The LCOS-SLM modulates the phase of the incident light. Do not remove the cover as it may cause damage. Caution If the cover is removed, the product is not covered.
Page 12: Lcos-Slm Controller
LCOS-SLM Controller The LCOS-SLM controller includes a circuit to generate data and control signals, an air-cooled fan to cool the circuit heating elements, and a voltage conversion board to drive them. The controller processes the image signals from the PC over the DVI-D cable and sends control signals to the LCOS-SLM. FPC cable Fig.5 Back of the controller ...
Page 13: Relay Board／Relay Board Cover
Relay board／Relay board cover The relay board is used to connect the LCOS-SLM head to the LCOS-SLM controller. See "Connecting/Removing Equipment" on page 14 for connecting. Be sure to attach a cover to the relay board. Caution Peripheral devices may be affected. Actuator FPC Connector A15218-01...
Page 14: Power Cable／Ac Adapter
Power Cable／AC Adapter Provides external power to the LCOS-SLM controller and LCOS-SLM head. Use only the supplied AC adapter/power cable to power the LCOS-SLM. In addition, the AC adapter/power cable of this product may not be shipped with the product because it does not comply with safety standards in certain areas.
Page 15: Connecting／Removing Equipment
8. Connecting ／ Removing Equipment This chapter explains how to connect and disconnect devices. Caution Turn off the power before connecting or disconnecting. Always remove static electricity from the body before touching Caution the equipment. Connection procedure Connect the LCOS-SLM head, LCOS-SLM controller and PC as follows. (1) Connect the LCOS-SLM head side FPC cable to the LCOS-SLM controller side FPC cable via the FPC connector on the relay board.
Page 16: Connecting The Relay Board
Connecting the relay board Connecting method of FPC Cable The FPC cable can be locked by inserting it deep into the FPC connector and tilting the actuator. The FPC cable can be disconnected by raising the actuator. When tilting the actuator, apply force evenly.
Page 17 Fig. 11 shows the correct connection. The FPC cable on the head side or controller side can be connected to either side of the relay board. Fig.11 correct connection state The LCOS-SLM will not function properly if the FPC cable is used with the following incorrect connection.
Page 18: Relay Board Cover Assembly
Relay board cover assembly Make sure you have all the accessories shown in Fig. 13. Fixing screws: 4 Fixed Foot: 4 Cover plate: 2 Fig.13 List of all relay board cover accessories Mounting projection GND contact Gasket Fig.14 relay board assembly As shown in Fig.
Page 19: Removal Procedure
Removal procedure (1) Turn off the power switch. (2) Remove the relay board cover screws and remove the cover. (3) You can remove various cables. The head and the FPC cable connected to the controller cannot Caution be removed. If you try to remove it forcibly, it may cause malfunction.
Page 20: Setup
9. Setup 9.1 setup example of the optical system Fig. 15 and Fig. 16 show examples of optical system setup using LCOS-SLM. Example 1 is an optical system using a half mirror. Example 2 shows a grazing incidence optical system. Example 2 has the advantage of less light loss due to the half mirror than Example 1.
Page 21: Installing The Rod Stand
9.2 Installing the Rod Stand As shown in Fig. 17, the LCOS-SLM head consists of a head (main body) and an L-shaped adapter. The bottom of the L-shaped adapter has a special hole (M6) for mounting the rod stand. Fig.17 LCOS-SLM Head The L-shaped adapter has a special hole for mounting various optical adjustment stages.
Page 22: Polarization Direction Of The Incident Light
Fig.18 L-Adapter Mounting Hole Drawing 9.3 Polarization direction of the incident light The LCOS-SLM has a liquid crystal orientation as shown in Fig.19. By making the polarization of the incident light the same as the orientation direction of the liquid crystal, only the phase of the incident light can be modulated.
Page 23: How To Set Dvi Video Output (Pc)
9.4 How to set DVI video output (PC) The desired signal for controlling the LCOS-SLM is generated by a PC (Windows ®). The signal generated by the PC is sent to the LCOS-SLM via the DVI port in the same way as the monitor display. A PC with a DVI port is required to drive the LCOS-SLM.
Page 24: How To
How to This section describes how to use LCOS-SLM. 1. Status after power up and warm-up time When the power is turned on, LCOS-SLM will boot for approximately 20 seconds. After a few seconds, the boot process ends and the LCOS-SLM starts operating normally. If the fan does not rotate, page.26 Please refer to "troubleshooting".
Page 25: Lcos-Slm Operation Check
LCOS-SLM operation check In this chapter, you run LCOS-SLM and display the attached phase image to confirm that LCOS-SLM is operating correctly. 1. Construct the optical system. The optical system shown in Fig. 20 is constructed. The incidence angle of the laser on the LCOS-SLM head should be within 5°...
Page 26 2. Configure your PC. See "How to set DVI video output" on page 21. 3. Turn on the LCOS-SLM. Warm up for about 10 minutes. 4. A computer hologram is input. Display the attached file sample _ hologram _ hpk _ xxx _ yyynm.bmp (xxx is the LCOS-SLM head S/N, and yyy is the wavelength.) on the 2nd screen.
Page 27: Trouble Shooting
Trouble shooting  LCOS-SLM does not work or does not work properly ・ Make sure the cables are connected properly. If the cables are not connected correctly, power down the LCOS-SLM controller and reconnect them. ・ Check your PC's screen settings. The output connected to the controller is active or P.21Check if "How to set up your PC"...
Page 28 4.It may not work depending on the type of laptop. In this case, there is a way to check the operation on a desktop PC. 5.Review the Windows display settings. Due to the Windows display settings, LCOS-SLM may not receive DVI input correctly. Set the display scale to 100% from "Scale and layout"...
Page 29: Technical Explanation
Technical explanation Distortion correction pattern Since the silicon substrate of LCOS-SLM is extremely thin compared to the glass substrate, it is difficult to maintain it in a perfect plane, and initial shape distortion of several [µm] remains. Therefore, when a plane wave is made incident to emit the plane wave, the remaining distortion of the silicon substrate, which is the mirror surface, causes wavefront distortion as shown in Fig.
Page 30: Warranty, Repair
Warranty, repair ■Guarantee, etc.  When using the product described in this manual, observe the maximum rating and precautions. Our company makes every effort to improve the quality and reliability of this product, but does not guarantee the integrity of this product. In particular, when the product is used for equipment that may infringe on human life, body or property, it is dangerous unless appropriate safety measures are taken in consideration of possible defects.
Page 31: Dimensional Outline
Dimensional outline Unit: mm Unindicated tolerance: ±1.0 LCOS SLM Head...
Page 32 Unit: mm Unindicated tolerance: ±1.0 LCOS-SLM Controller...
Page 33: Water-Cooled Type (L, R Series) Handling
Water-cooled type (L, R Series) handling Please refer to this manual for the basic operation of LCOS-SLM. This section is only an excerpt of how to use the water-cooled type. The heat sink is very heavy. Please use with sufficient care when Caution moving or moving.
Page 34 Precautions for handling water-cooled heat sinks Be sure to observe the following precautions and procedures. not safeguarded This can damage the LCOS-SLM and peripherals. ■Handling of circulating water Be careful not to splash the circulating water on this device. When inserting or removing the circulating water hose, be sure to turn off the power to the device and peripheral devices.
Page 35 ■Starting and circulating water ・Check that the circulating water is flowing normally. ・Ensure that the circulating water flow rate is 0.5 L/min. If the flow rate and water pressure cannot be ensured, replace the water circulating hose immediately. ・Do not stop the circulating water during laser irradiation. Do not stop water circulation during high-power laser irradiation.
Page 36 ■Removing the water circulation hose  Turn off the LCOS-SLM and peripherals (Include a circulating water controller).  Check that the circulating water has stopped.  Remove the circulating water hose on the circulating water controller side.  Air out the water in the circulating water hose and heat sink. ・Blow air into one side of the hose.
Page 37 If you want to use the mounting holes on the bottom, you must remove the head with the water-cooled heat sink (main body) once. 【Removal - Reconnection Procedure】 Use a screwdriver to loosen and remove the L-shaped fixture fixing screw on the back of the LCOS-SLM head water-cooled type.
Page 38: External Dimensions (Water-Cooled Type)
External Dimensions (water-cooled type) Unit: mm Unindicated tolerance: +/- 1.0 LCOS SLM Head (R Series) LCOS SLM Head (L Series) *1: KQB2S06-01S SMC, Compatible Tube Outer Diameter: φ6...
Page 39 Other company and product names mentioned herein may be the trademarks or registered trademarks of their respective owners. JAPAN Hamamatsu Photonics K. K.. Laser Promotion Division 1-8-3, shinmiyakoda, kita-ku, Hamamatsu City, 431-2103, Japan, Telephone: (81) 53-484-1300, Fax: (81) 53-484-1317 U.S.A Hamamatsu Corporation 360 Foothill Road, Bridgewater, N.J.
