- Page 1 – Installation lift pump WINEARM15 Installation guide lift pump WINEARM15 07-2019...
- Page 2 I.Installation Step 1 : Acces from the bottom opening or 1.1. dismount one side of the appliance Disassemble the side indicated herewith by removing the screws Step 2 : Fix the lifting pump on the sheet 1.2. For fixing the pump you need : •...
- Page 3 Step 3 : Installation of the brackets in the 1.3. appliance To fix the brackets you need : • The parts assembly • 4x W10151 Step 4 : Sensor installation 1.4. • Reverse the cap position to open the front water outlet of the sensor •...
- Page 4 • • Cut a piece of PVC tube D 6MM • • Connect the sensor to the lift pump with this tube • • Use the rest of the tube to drive the liquid from the pump to the outside of the machine. (you can extend this pipe with the following constraints ) REAL FLOW TABLE TOTAL PIPE LENGTH (INT 6MM, 1/4")-(C)
