SPARKFOX W20S102 User Manual

HDMI
TRAVEL CABLE
FOR NINTENDO SWITCH™
User manual
PLEASE NOTE:
The Nintendo Switch™ Lite console does not support TV Dock mode.

1. Package contents

Switch HDMI Travel Cable x 1
User Manual x1

2. Product features

The HDMI Travel Cable is the portable alternative to taking the
Nintendo Switch dock with you when you travel. Simply connect the
HDMI cable to the HD compatible TV and the Type-C cable to the
console for big screen gaming.
Outputs the console video signal in 1080P resolution to any HDMI
compatible TV.
Play and charge at the same time using the Official AC Adapter*.
Compact for easy transportation.
10 feet cable length.

3. Product instruction

HDMI LED Type-C Female
Type-C Male

4. Setup instructions

NOTE: *This product requires the Official AC Adapter (supplied with
the console) to function.
**PLEASE DO NOT USE OTHER AC ADAPTERS AS THIS COULD CAUSE
DAMAGE TO YOUR CONSOLE**
AC Adapter
Type-C Female (Sold separately)
HDMI
HDTV
Switch™
Type-C Male
Attach the HDMI connector on the Travel cable to a free HDMI port
on your TV or monitor.
*Please make sure that the TV is set to the same channel the HDMI cable is plugged into
Connect the USB-C head on the AC adapter in to the female USB-C
port on the Travel Cable.
Connect the AC adapter into the power socket.
Connect the USB-C Male cable into the USB-C port of the console.
Note: The product can use 5V and 15V power supply
Note: This product does not require batteries.

5. LED function

With the AC adapter and HDMI cable connected, the LED on the
cable box will light up green.
6. Attention
Please make sure that the NIntendo Switch console is updated with the
latest system software version. We recommend version 6.0.0 or above.

PRECAUTION AND MAINTENANCE

1. Store in a cool, dry & dust free area.
2. Do not store in areas of extreme low temperatures (0ºC) or High
(40ºC).
3. Avoid direct sunlight and heat sources.
4. Do not allow the product to get wet or dirty; doing so may cause
damage.
5. Do not clean with benzene, paint thinner, acetone, alcohol or other
solvents.
6. Do not take the product apart; doing so will void your warranty and
may cause electrical shock or damage to internal components.
7. Please help to conserve the enviroment by recycling the cardboard
packaging of this product.
8. This product should NOT be disposed of in normal household waste.
It should be disposed of separately. Please take it to an electrical
waste collection point.
