QuietOn 3 - ANC Earbuds Manual

We want you to get the most out of your Quietude experience.
Therefore, please read this leaflet and accompanying Quick Guide carefully before using the device. Failure of following the instructions below could result in product damage or malfunction or even injury.

Getting started videos: www.quieton.com/start

How does QuietOn 3 operate?

1. First foam tips attenuate outside noise passively.
2. Then Active noise cancelling creates anti-noise which reduces noise efficiently.

To ensure that QuietOn 3 works efficiently, you should seal the earbuds in your ear airtightly. When the device is placed airtightly, the foam tip attenuates the noise exactly to the right level.

The Active Noise Cancelling works only when the noise signal and the anti-noise signal are matching.

Getting started

1. QuietOn 3 earbuds switch on automatically when the device is taken out from the charging case. No buttons needed.
2. Make sure to insert earbud with letter L to left ear, earbud with letter R to right ear. Compress the foam tip by rolling it with your fingers. By default the foam tip size is small (S).

3. Pull back your ear while inserting the foam part to your ear.

4. Rotate the device backwards for optimal orientation. Wait for 15-30 sec for the foam to expand and for it to create a seal.


NOTE: After the seal is achieved, ANC and passive noise cancelling start working together and the performance improves gradually. When you listen to wide bandwidth noise with QuietOn 3 in your ears for a while and then take them out simultaneously, you perceive the full performance and realize how effective QuietOn 3 is.

How can I be sure that I have set QuietOn 3 airtightly?

1. Check if the device is visible from the front view. If so, try to snug it in better.

2. Check if the foam tip size (XS, S, M, L) is correct for your ear and replace it if needed. To ensure the correct size, press the device when it is inside your ear. You should feel a change of air pressure inside the ear canal.


If the ears are hairy, it might cause problems in achieving airtightness and might therefore result in a lack of noise cancelling performance.

How test if the device is functioning correctly?

QuietOn 3 functionality can be verified by using the charging case.

Put the top front area (where the magnet is) of the case really close to the earbud. Then slowly detach it and you will hear a snap sound in low volume. To be able to hear it you should be in a silent environment. The snap sound indicates that the earbud works correctly. This can be tested for both earbuds.

Wait a sec, I can still hear sounds with QuietOn 3 in my ears?

QuietOn 3 is efficient in canceling the noise but it will not create total silence. Nothing does. Here is a graph which shows how the QuietOn 3 performs with snoring. QuietOn 3 excels in the lower frequencies in the sound spectrum, such as the heavy bass music rumbling through the walls or the snoring of your partner next to you. When it comes to higher frequencies, the noise cancelling is similar to a pair of high-quality foam earplugs. So, no need to worry about oversleeping: You will not miss out on your alarm clock in the morning. If the snoring is particularly loud, it can be still partially heard, but the noise level is much lower to help you sleep.

How to be sure the earbuds battery is charged?

The earbuds are always charging when the battery is not full, and the battery of the charger case is not empty. Charging takes about 2 hours.

1. When the case is closed, the LED lights indicate the progress of the charging with a breathing sequence. Whenever the battery gets fuller, more and more leds are lit.
2. When the case is open, the LED lights show the battery level of the earbuds. If all lights are lit, earbuds are fully charged and ready to use. If at least one LED is lit (more than 30%), it is enough for one night. When the earbud is taken from the case, it turns on automatically.

How to charge the charger case?

• Attach the small end of the USB-C cable to the port behind the charging case. You can find the USB-C cable in the sales box.
• Attach the bigger end to the mobile phone's charger or the laptop's USB type-A port providing 5 V and max 3 A.
• LEDs indicate the charging status.
• Charging takes around 3 hours.
• When the case is opened, it indicates its battery status for 30 sec.
• If at least one LED is lit (more than 30%), this is enough to charge the earplugs once.

STORAGE

QuietOn earbuds should be stored in charging case. Please refer to the storage temperature ranges listed in the "Temperature ranges" section. Batteries are fully charged at the factory, they will self-discharge gradually like all batteries and might need recharging before use. Please note that the battery may malfunction if not used or charged for an extended period. To keep batteries in good condition while in storage, recharge the earbuds at least every 50 days.

CLEANING AND MAINTENANCE

It is important to clean the device to maintain its functionality. To maintain the performance of your QuietOns, ensure also that your ears are clean before using the earbuds since earwax may affect earbuds' performance.

The body of the earbud can be cleaned with a dry cloth. Do not wash the device with water, solvents, toxic chemicals, detergents or any liquid as that may damage the device.

The foam tips are wiped with a soft damp cloth or dry tissue. Do not use solvents, chemicals or detergents or soak the foam tips with water as that may damage the foam tips or the earbud.

The interior of the charging case should be kept free from dust and debris. When cleaning the interior, use dry cotton sticks. When cleaning the exterior, use dry or damp cloth. Be careful with USB port. Be careful with charging contacts, do not bend those as the device will not charge if they are bent or damaged.

TEMPERATURE RANGES

Operating temperature range for the earpiece: -4°F to 122°F (-20°C to 50°C). Storage temperature range (complete kit): -4°F to 122°F (-20°C to 50°C).

Charging temperature range: 32°F to 113°F (0°C to 45°C).

WARNINGS

Note that the device is not a hearing protector and not designed for situations that require hearing protecting. The earbuds do not remove noise completely, so even when wearing the earbuds be careful to avoid loud noises that could damage your hearing

For long periods of storage, keep the battery between -4°F (-20°C) and 122°F (50°C). Using or storing the product outside of the recommended temperature ranges may damage the products, reduce the battery's capacity, or reduce the battery's lifespan. The product may not work temporarily if used outside the optimal temperature range (either too hot or too cold). Storing the product in very hot areas such as inside a car in the summertime may result in damage to the device or cause the battery to explode.

If there is any drainage from your ear or you have an ear infection, do not use the device before having consulted your physician. Failure to do so may result in hearing loss or injury. Do not use device with wet ears to avoid device to break or eartips to swell.

The sound attenuation caused by the device can create a risk in situations where it is important to hear environmental sounds and warning alarms, for example, road traffic or warning sirens on a construction site. Note that alarm sounds will sound different when wearing the earplugs.

Local laws may restrict the use of QuietOn in traffic. Always obey local laws.

Do not use the earbuds if they produce excessively loud sound since the device may be broken and should be returned to the seller.

The device contains small parts that may present a choking hazard to small children and animals. The device is not suitable for small children.

The device contains magnets, which may affect magnetic stripe cards, pacemakers or similar devices. The device is not waterproof. Do not wet the unit. This may create a short circuit, which can cause a risk of fire and may damage the device. The charging case and earbuds are not waterproof or IP rated.

Do not expose the device to high temperatures. Do not use the device in case of mechanical breakage of the device. This may create a short circuit, which can cause a risk of fire and damage the device. Use and store the device carefully. Use only an approved USB charger or computer to charge: connected via USB type-A to USB-C cable or USB-C to USB-C cable. The charger should be compatible with the applicable safety standards: CE or UL / CSA / IEC / EN 62368. Do not leave the device on charge for long periods of time. The charging case shall be supplied by adapter providing 5V and 0.2 – 3A.

CAUTIONS

Only use compatible QuietOn eartips. Do not insert the earbud directly into the ear without a correctly attached eartip. When used according to the User Instructions, this device helps reduce exposure to noise, such as noise from vehicles and aircraft. If your hearing seems dulled or you hear a ringing or buzzing during or after any noise exposure, your hearing may be at risk and you should move away from such noise to protect your ears.

Battery performance will reduce over time. Notice that if the battery is empty, device's performance will be affected and active noise cancelling and hearing modes are not functioning. The attenuation is then at passive level. The performance of active noise cancelling earbuds may be adversely affected if sustained oscillation (whistling or instability) is perceived. If refitting the earbuds does not overcome this, you should contact us.

NO MODIFICATIONS

Modifications to this device shall not be made without the written consent of QuietOn. Unauthorized modifications may void the warranty.

DISPOSAL

QuietOn active noise cancelling earbuds have a non-replaceable rechargeable lithium-ion battery. Earbuds and batteries are required to be recycled by local, state/province, and national laws. To properly recycle/dispose of the battery, always follow local solid waste disposal regulations. Never expose the batteries to fire or excessive heat.

LIMITED WARRANTY

This warranty shall apply extended only to the original end-use purchaser or the person receiving the product as a gift and shall not be extended to any other person or transferee.

Unless a different warranty period is stated in the owner's guide provided with your QuietOn product, for a period of 2 years (in EU) or 1 year (other countries) from the date of retail purchase by the original end-use purchaser, QuietOn warrants that this product, when delivered to you in new condition, in original packaging, from a QuietOn authorized reseller and used in normal conditions, is free from any defects in manufacturing, materials and workmanship. The eartips are consumables and not under warranty.

Contact the QuietOn organization in your country/region (visit www.QuietOn.com for QuietOn contact information in your country/region) for specific return and shipping instructions; Label and ship the product, freight prepaid, to the address provided by the QuietOn organization in your country. The product must be properly packed for shipping. All the parts included in the original sales package must be included. Place any necessary return authorization number prominently on the outside of the carton. Cartons not bearing a return authorization will not be accepted.

FURTHER INFORMATION

Further information should be sought from company website www.quieton.com or QuietOn Ltd/ Support, Hakamaantie 18, 90440 Kempele, Finland.

This product conforms to all applicable EU directive requirements.
The complete Declaration of Conformity can be found at www.quieton.com/declarations.

This device complies with UL/CSA/IEC/EN 62368.
Accessories are available from QuietOn web shop.
Navigate to www.quieton.com for additional ordering information.
