- Page 1 ® ® Brocade Fabric OS Access Gateway User Guide, 8.2.x User Guide 16 October 2020 FOS-821-access-AG104 16 October 2020...
-
Page 2: Table Of Contents
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Table of Contents Copyright Statement..........................7 Introduction............................8 About This Document..............................8 What Is New in This Document............................8 Supported Hardware and Software..........................8 Key Access Gateway Terms............................8 ®... - Page 3 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x F_Port Static Mapping.............................. 32 Considerations for Using F_Port Static Mapping with Other AG Features and Policies........32 Upgrade and Downgrade Considerations......................32 Device Mapping.................................32 Static versus Dynamic Mapping........................34 Device Mapping to Port Groups (Recommended)....................
- Page 4 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Disabling the APC Policy...........................48 APC Policy Considerations............................48 Port Grouping Policy..............................48 How Port Groups Work.............................49 Adding an N_Port to a Port Group...........................50 Deleting an N_Port from a Port Group........................50 Removing a Port Group............................51 Renaming a Port Group............................51 Disabling the Port Grouping Policy...........................51...
- Page 5 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Deleting a Preferred Secondary N_Port for Device Mapping (Optional)............61 Enabling and Disabling the Failover Policy on an N_Port..................61 Enabling and Disabling the Failover Policy for a Port Group...................62 Failback Policy................................62 Failback Policy Configurations in Access Gateway....................62 Failback Example...............................62...
- Page 6 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Access Gateway Cascading............................78 Access Gateway Cascading Considerations......................79 Fabric and Edge Switch Configuration........................79 Connectivity to Cisco Fabrics........................... 80 Enabling NPIV on a Cisco Switch........................80 Verifying the Switch Mode............................80 Rejoining Fabric OS Switches to a Fabric........................
-
Page 7: Copyright Statement
2018–2020 Broadcom. All Rights Reserved. Broadcom, the pulse logo, Brocade, the stylized B logo, and Fabric OS are among the trademarks of Broadcom in the United States, the EU, and/or other countries. The term “Broadcom” refers to Broadcom Inc. and/or its subsidiaries. -
Page 8: Introduction
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Introduction About This Document ® This document describes the Brocade Access Gateway (AG) basic concepts, the platforms involved, port configuration in AG mode, policy management, and SAN configuration. What Is New in This Document Starting with this release, all new and modified content is listed in the "Revision History"... -
Page 9: Contacting Technical Support For Your Brocade ® Product
• Other Resources: Licensing Portal (top), SAN Health (top and bottom), Communities (top), Education (top). If you purchased Brocade product support from a Broadcom OEM/solution provider, contact your OEM/solution provider for all your product support needs. • OEM/solution providers are trained and certified by Broadcom to support Brocade products. -
Page 10: Document Feedback
However, if you find an error or an omission or if you think that a topic needs further development, we want to hear from you. Send your feedback to documentation.pdl@broadcom.com. Provide the publication title, publication number, topic heading, page number, and as much detail as possible. -
Page 11: Access Gateway Basic Concepts
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Access Gateway Basic Concepts Brocade Access Gateway Overview Brocade Access Gateway (AG) is a Fabric OS feature that you can use to configure your fabric to handle additional devices instead of domains. - Page 12 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 1: Switch Function in Native Mode FOS-821-access-AG104...
-
Page 13: Fabric Os Features In Access Gateway Mode
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 2: Switch Function in Access Gateway Mode Fabric OS Features in Access Gateway Mode The following table lists feature support for a switch that operates in Access Gateway mode. Feature support is indicated in the following ways: •... - Page 14 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Table 1: Fabric OS Components Supported in Access Gateway Mode Feature Support Access Control Yes (limited roles) Adaptive Networking Admin Domains Audit Beaconing Bottleneck Detection Buffer Credit Recovery (CR) Buffer credit recovery support.
-
Page 15: Buffer Credit Recovery Support
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Feature Support License Yes** Lightweight Directory Access Protocol (LDAP) Log Tracking Management Server Manufacturing Diagnostics Monitoring and Alerting Policy Suite (MAPS) N_Port ID Virtualization (NPIV) Name Server Native Interoperability Mode Network Time Protocol (NTP) Open E_Port... -
Page 16: Forward Error Correction Support
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x • Between the AG device F_Port and a QLogic BR-1860 16Gb/s Host Bus Adapter (HBA) port running version 3.2 or later firmware. • Between the AG device F_Port and any device that supports credit recovery. •... -
Page 17: Supported Policy Modes
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x • An Access Gateway device N_Port connected to a Brocade fabric switch F_Port. The N_Port enables authentication when authentication is enabled on the connected switch. Enable the switch policy on the AG device, and enable the device policy on the fabric switch. -
Page 18: Supported Fabric Os Commands
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Table 3: Behavior of HBA Sending Device and Receiving AG Device with Different Policies Configured AG Device, Device Policy AG Device, Device Policy AG Device, Device Policy Mode On Mode Passive Mode Off... -
Page 19: Password Distribution Support
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Password Distribution Support You can distribute the password database to all switches that are connected to the same fabric whether they are in AG mode or Native mode. Use the distribute command on any switch that is in Native mode to distribute the password database to all AG devices and switches connected to the same fabric. - Page 20 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x NOTE You must use the configure command to enable the Remote Fosexec feature on both the sending and receiving AG device. By default, Remote Fosexec is disabled. Refer to the Brocade Fabric OS Command Reference Manual for more information.
-
Page 21: Slow-Drain Device Quarantining Support
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Slow-Drain Device Quarantining Support In a fabric, many flows share the same link or virtual channel (VC). However, the credits used to send traffic across the link are common to all flows that use the same link. Therefore, a slow-draining device slows down the return of credits and impacts the healthy flows using the link. -
Page 22: Access Gateway Port Types
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x The following table shows the SDDQ behavior with different firmware loaded in edge AG, core AG, and edge fabric switch. Table 4: SDDQ Behavior in Cascaded AG Setup Edge AG Core AG Edge Fabric Switch... - Page 23 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 4: Port Comparison You can test the link between ports on an AG device and another AG device, fabric switch, or HBA by configuring each connection in the link as a D_Port. When you configure the ports at each end of the link as D_Ports, diagnostic tests automatically initiate on the link when the D_Ports come online.
-
Page 24: Access Gateway Hardware Considerations
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 5: Diagnostic Port Configurations The following table compares port configurations between AG devices and a standard fabric switch. Table 5: Port Configurations Port Type Available on the Access Gateway? Available on the Fabric Switch? F_Port Connects hosts and targets... -
Page 25: Configuring Ports In Access Gateway Mode
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Configuring Ports in Access Gateway Mode Enabling and Disabling Access Gateway Mode Use the following steps to enable and disable Access Gateway mode. After you enable AG mode, some fabric information is erased, such as the zone and security databases. -
Page 26: Port State Description
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x 10. Enter the switchdisable command to disable the switch. 11. Enter the ag --modedisable command to disable AG mode. 12. Enter the ag --modeshow command to verify that AG mode is disabled. Port State Description The following table lists and describes the port states. -
Page 27: Port Mapping
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Port Mapping F_Ports must be mapped to N_Ports before the F_Ports can come online. The following figure shows an example in which eight F_Ports are mapped evenly to four N_Ports on a switch in AG mode. The N_Ports connect to the same fabric through different edge switches. - Page 28 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Table 8: Access Gateway Default Port Mapping Brocade Model Total Ports F_Ports N_Ports Default Port Mapping 6505 0–15 16–23 0, 1 mapped to 16 2, 3 mapped to 17 4, 5 mapped to 18 6, 7 mapped to 19 8, 9 mapped to 20...
- Page 29 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Brocade Model Total Ports F_Ports N_Ports Default Port Mapping 6547 1–28 0, 29–47 1, 21 mapped to 0 2, 22 mapped to 29 3, 23 mapped to 30 4, 24 mapped to 31 5, 25 mapped to 32 6, 26 mapped to 33...
-
Page 30: Considerations For Initiator And Target Ports
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Brocade Model Total Ports F_Ports N_Ports Default Port Mapping 6558 1–24 0, 25–47 24 mapped to 32 23 mapped to 33 22 mapped to 34 21 mapped to 35 20 mapped to 36 19 mapped to 37 18 mapped to 38... -
Page 31: Adding F_Ports To An N_Port
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Use the following recommendations for mapping between host and target ports: • Use separate port groups for the host and target ports. • If connecting a host and target port to the same AG device, map the host and target to separate N_Ports and connect those N_Ports to the same fabric. -
Page 32: F_Port Static Mapping
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x F_Port Static Mapping The F_Port static mapping feature adds the staticadd and staticdel keywords to the ag fabric OS command. These keywords simplify how you change N_Port to F_Port mapping. Using the ag --staticadd command, any existing mappings are removed and replaced with the new mapping information. - Page 33 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x group, WWNs mapped to that port group are automatically balanced among the online N_Ports in that group. For more information, see Port Grouping Policy Modes). NOTE The Port Grouping policy is not supported when both Automatic Login Balancing and Device Load Balancing are enabled.
-
Page 34: Static Versus Dynamic Mapping
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 8: Example Device Mapping to an N_Port Static versus Dynamic Mapping Device mapping is of two types, static or dynamic. Static device mapping has the following considerations: •... -
Page 35: Device Mapping To N_Ports
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x 2. To add one or multiple device WWNs to an N_Port group , use the ag --addwwnpgmapping command. All the listed device WWNs will use the least-loaded N_Port in the port group when they log in, unless a specific device mapping can be used instead. -
Page 36: Disabling Device Mapping
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x 3. To change all current device mappings to a different N_Port, use the ag --addwwnpgmapping command with the all keyword. The following command changes all the existing device mappings to use port 17. ag --addwwnmapping 17 --all 4. -
Page 37: Enabling Device Mapping
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Enabling Device Mapping Use the following steps to enable device mapping for all devices or specific devices that were previously disabled. 1. Connect to the switch and log in using an account with admin permissions. After you have logged in, you can one of the following commands to enable how devices are mapped to port groups. -
Page 38: Considerations For Access Gateway Mapping
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x If there are any additional disruptions, the server does not switch back to the virtual port, and the VM traffic does not follow the configured device mapping. Note that this behavior can also occur when a VM first boots, prior to any failover. When this behavior occurs, the VM WWN will be logged in to the fabric. -
Page 39: Device Mapping Considerations
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x For more information, see Port Grouping Policy. 1. Static device mapping to N_Port (if defined) 2. Device mapping to N_Port group (if defined) 3. Automatic Device Load Balancing within a port group (if enabled) 4. - Page 40 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 9: Example of Adding an External F_Port (F9) on an Embedded Switch Although some ports are locked as N_Ports, you can convert N_Ports to F_Ports, as follows. 1.
-
Page 41: Displaying N_Port Configurations
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Displaying N_Port Configurations Use the following steps to determine which ports on a switch are locked as N_Ports. 1. Connect to the switch and log in using an account with admin permissions. 2. -
Page 42: D_Port Support
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x D_Port Support The D_Port (diagnostic port) feature is supported on 16Gb/s and 32Gb/s ports in the configurations shown in the following table. Table 9: D_Port Support for Access Gateway D_Port Mode Switch to AG AG to AG... -
Page 43: Saving Port Mappings
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Saving Port Mappings Before configuring static D_Ports, you must remove all mappings between the ports and devices because mappings are not retained on D_Ports. This includes port (N_Port-to-F_Port), device (WWN), static, and dynamic mapping. You can use Fabric OS commands to save N_Port mappings and to delete saved N_Port mappings. -
Page 44: Managing Policies And Features In Access Gateway Mode
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Managing Policies and Features in Access Gateway Mode Access Gateway Policies Overview This chapter provides detailed information on all Access Gateway policies. These policies can be used to control various advanced features, such as failover, failback, and trunking, when used in Access Gateway mode. -
Page 45: Enabling And Disabling The Ads Policy
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x • Issuing the agshow command without operands displays a summary of F_Ports on all AG core and edge switches attached to the fabric, such as the AG devices that are directly connected to fabric. •... -
Page 46: Setting The List Of Devices Allowed To Log In
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Setting the List of Devices Allowed to Log In The following steps show how to set the allowed devices. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 47: Displaying The List Of Allowed Devices On The Switch
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x The following steps show how to add devices to a list of allowed devices. The ADS policy must be enabled for this command to succeed. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 48: Enabling The Apc Policy
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Enabling the APC Policy The following steps show how to enable the APC policy on a switch. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 49: How Port Groups Work
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x How Port Groups Work Create port groups using the ag --pgcreate command. This command groups N_Ports together as port groups. By default, any F_Ports mapped to the N_Ports belonging to a port group will become members of that port group. Port grouping fundamentally restricts failover of F_Ports to the N_Ports that belong to that group. -
Page 50: Adding An N_Port To A Port Group
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 11: Port Group 1 (PG1) Setup Adding an N_Port to a Port Group The following steps show how to add an N_port to a port group. 1. -
Page 51: Removing A Port Group
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x 3. Enter the ag --pgshow command to verify the N_Port was deleted from the specified port group. Removing a Port Group The following steps show how to remove a port group. 1. -
Page 52: Managed Fabric Name Monitoring Mode
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Managed Fabric Name Monitoring Mode When enabled, Managed Fabric Name Monitoring (MFNM) mode queries the fabric name at a specific time period. If it detects an inconsistency, for example, all the N_Ports within a port group are not physically connected to the same physical or virtual fabric, it generates a RASLOG message. -
Page 53: Considerations When Disabling Automatic Login Balancing Mode
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x switch:admin> agautomapbalance --show AG Policy: pg -------------------------------------------- PG_ID LB mode nport fport -------------------------------------------- 0 Enabled Enabled Disabled 1 Disabled This command also displays the automatic login redistribution settings for N_Ports and F_Ports. For more details on this command and its output, refer to the Brocade Fabric OS Command Reference Manual. -
Page 54: Displaying The Current Mfnm Mode Timeout Value
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Displaying the Current MFNM Mode Timeout Value The following steps show how to display the current MFNM mode timeout value. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 55: Enabling The Device Load Balancing Policy
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Manually created mappings from devices to N_Ports take precedence over automatically created mappings. See Mapping Priority for details on connection priority for AG port mapping. For more information on device mapping, see Device Mapping. -
Page 56: Enabling The Persistent Alpa Policy
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x • In “Flexible” mode, the AG logs an event that it did not receive the same (requested) ALPA from the core fabric and brings up the device with the ALPA assigned by the fabric. An unassigned ALPA value is assigned when the ALPA assigned to the device is taken by another host. -
Page 57: Displaying Device Data
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Displaying Device Data You can view the ALPA of the host related to any ports you delete from the database. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 58: Failover Configuration In Access Gateway
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Failover Configuration in Access Gateway The following sequence describes how a failover event occurs: 1. An N_Port goes offline. 2. All F_Ports mapped to that N_Port are temporarily disabled. 3. -
Page 59: Adding A Preferred Secondary N_Port (Optional)
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 12: Failover Behavior Adding a Preferred Secondary N_Port (Optional) F_Ports automatically fail over to any available N_Port. Alternatively, you can specify a preferred secondary N_Port in case the primary N_Port fails. -
Page 60: Deleting F_Ports From A Preferred Secondary N_Port
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x The following steps show how to add a preferred secondary N_Port. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 61: Deleting A Preferred Secondary N_Port For Device Mapping (Optional)
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x ag --addwwnfailovermapping 32 "10:00:00:06:2b:0f:71:0c;10:00:00:05:1e:5e:2c:11" To configure N_Port 32 as a failover port for all WWNs mapped to the N_Port, use the ag -- addwwnfailovermapping N_Port --all command. ag --addwwnfailovermapping 32 --all Deleting a Preferred Secondary N_Port for Device Mapping (Optional) Use the following steps to remove a secondary N_Port where devices will connect if their first or primary N_Port, if... -
Page 62: Enabling And Disabling The Failover Policy For A Port Group
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Enabling and Disabling the Failover Policy for a Port Group The Failover policy can be enabled on a port group. Use the following steps to enable or disable the failover on all the N_Ports belonging to the same port group. -
Page 63: Enabling And Disabling The Failback Policy On An N_Port
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 13: Failback Behavior Enabling and Disabling the Failback Policy on an N_Port Use the following steps to enable or disable the failback policy on N_Ports. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 64: Enabling And Disabling The Failback Policy For A Port Group
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Enabling and Disabling the Failback Policy for a Port Group Use the following steps to enable or disable the failback policy on all the N_Ports belonging to the same port group. 1. -
Page 65: Considerations For Failback Policy Disabled On Unreliable Links
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x ag --reliabilitycounterset "count" Specify 0 for the count as shown in the following command to disable reliability. When disabled, any reliable N_Ports are recovered to be reliable again. ag --reliabilitycounterset 0 You can view counter settings using the following command. -
Page 66: How Trunking Works
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x NOTE F_Port trunking for HBAs is only supported for HBAs connected to switch running in native mode. It is not supported for HBAs connected to switches running in AG mode. How Trunking Works Trunking in Access Gateway mode provides a trunk group between N_Ports on the AG module and F_Ports on the edge switch. -
Page 67: Setting Up Trunking
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Setting Up Trunking Use the following steps to set up trunking. 1. Connect to the switch and log in using an account assigned to the admin role. 2. -
Page 68: Enabling The Dcc Policy On A Trunk
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x switch:admin> portenable 10/14 6. After enabling the ports, execute the porttrunkarea --show enabled command. The ports that you enabled appears in the output. Enabling the DCC Policy on a Trunk After you assign a trunk area, the porttrunkarea command checks whether there are any active Device Connection Control (DCC) policies on the port with the index TA, and then issues a warning to add all the device WWNs to the existing DCC policy with index as TA. -
Page 69: Monitoring Trunking
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x trunk area 37 disabled for ports 36, 37, 38 and 39. Monitoring Trunking For F_Port masterless trunking, you must install monitors on the F_Port trunk port. If the master port changes, you need not move the monitors to the new master port. - Page 70 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Category Description Fast Write When you assign a trunk area to a trunk group, the trunk group cannot have fast write enabled on those ports; if fast-write is enabled on a port, the port cannot be assigned a trunk area. FICON FICON is not supported on F_Port trunk ports.
-
Page 71: Trunking Considerations For Access Gateway Mode
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Table 13: PWWN Format for F_Port and N_Port Trunk Ports NAA = 2 2f:xx:nn:nn:nn:nn:nn:nn Port WWNs for switch The valid range of xx is FX_Ports [0–FF], for a maximum of 256 port WWNs NAA = 2 25:xx:nn:nn:nn:nn:nn:nn... -
Page 72: Adaptive Networking On Access Gateway Considerations
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 14: Starting Point for QoS Adaptive Networking on Access Gateway Considerations • QoS is configured in the fabric, as normal, and not on the AG device. •... -
Page 73: Setting The Login Limit
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x • The value that you set is persistent across reboots and firmware upgrades. • This feature supports virtual switches, so each port can have a specific NPIV login limit value in each logical switch. •... -
Page 74: Flow Monitor
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Flow Monitor Flow Vision flow monitoring is a licensed feature supported on unified platform to manage traffic-related applications on Fabric OS devices. Storage administrators can use this platform to simulate, monitor, and capture the network’s traffic patterns and to make capacity-planning decisions based on the collected statistical data. - Page 75 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x The following illustration shows a typical application of Flow Mirror on an Access Gateway platform: Figure 15: Flow Mirror Application on Access Gateway Platform Following are considerations and limitations for using Flow Mirror for Access Gateway: •...
-
Page 76: San Configuration With Access Gateway
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x SAN Configuration with Access Gateway Connectivity of Multiple Devices Overview This chapter describes how to connect multiple devices to a switch in Access Gateway (AG) mode, and it discusses edge switch compatibility, target aggregation, direct target attachment, port requirements, NPIV HBA, and interoperability. -
Page 77: Considerations For Direct Target Attachment
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 16: Direct Target Attachment to Switch Operating in AG Mode Although target devices can be connected directly to AG ports, switch operating in AG mode must be connected to the core fabric. -
Page 78: Target Aggregation
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Target Aggregation Access Gateway mode is normally used as host aggregation. In other words, a switch in AG mode aggregates traffic from a number of host systems onto a single uplink N_Port. Similarly, many targets can be aggregated onto to a single uplink N_Port, as shown in the following figure. -
Page 79: Access Gateway Cascading Considerations
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Figure 18: Access Gateway Cascading AG cascading provides higher over-subscription because it allows you to consolidate the number of ports going to the main fabric. There is no license requirement to use this feature. Access Gateway Cascading Considerations Note the following configuration considerations when cascading Access Gateways: •... -
Page 80: Connectivity To Cisco Fabrics
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x • Install and configure the switch as described in the switch’s hardware reference manual before performing these procedures. • Verify that the interop mode parameter is set to Brocade Native mode. •... -
Page 81: Rejoining Fabric Os Switches To A Fabric
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x switchMode: Native switchRole: Subordinate switchDomain: switchId: fffc01 switchWwn: 10:00:00:05:1e:03:4b:e7 zoning: switchBeacon: ----------------------------------------= Port State Description for a description of the port state. If the switch is in Native mode, you can enable AG mode; otherwise, set the switch to Native mode, and then reboot the switch. -
Page 82: Troubleshooting
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Troubleshooting The following table provides troubleshooting information for Fabric OS switches in AG mode. Table 14: Troubleshooting Problem Cause Solution Switch is not in Access Gateway mode. Switch is in Native switch mode. - Page 83 ® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Problem Cause Solution Failover is not working. Failover disabled on N_Port. Verify that the failover and failback policies are enabled, as follows: ag --failovershow Enter the <port_number> command.
-
Page 84: Revision History
® ® FOS-821-access-AG104 User Guide Brocade Fabric OS Access Gateway User Guide, 8.2.x Revision History FOS-821-access-AG104; 16 October 2020 Updated the table in Fabric OS Features in Access Gateway Mode. FOS-821-access-AG103; 13 February 2019 Added SANnav support to the document. FOS-821-access-AG102;...
