Owner's Manual & Safety Instructions
Save This Manual
operating, inspection, maintenance and cleaning procedures. Write the product's serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Item
Weight Capacity
Assembled Dimensions
Face Plate
Wheel Diameter
Conforms with ASME PASE 2019
Email our technical support at: productsupport@harborfreight.com
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
©
Copyright
2021 by Harbor Freight Tools
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Keep this manual for the safety warnings and precautions, assembly,
59201
1,000 lb.
33-1/2" L x 27-1/2" W x 36" H
10" L x 6" W x 5/8" thick
3" (x2), 3-1/2" (x2)
Visit our website at: http://www.harborfreight.com
®
. All rights reserved.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
22d
Advertisement
Table of Contents
Related Manuals for Pittsburgh 59201
Summary of Contents for Pittsburgh 59201
- Page 1 (or month and year of purchase if product has no number). Keep this manual and the receipt in a safe and dry place for future reference. Item 59201 Weight Capacity 1,000 lb.
- Page 2 These carry important safety information. If unreadable Assure load is centered and secured or missing, contact Harbor Freight Tools to mounting attachments. for a replacement. For technical questions, please call 1-888-866-5797. Page 2 Item 59201...
- Page 3 Rear Beam (4). Figure B: Attach Front and Rear Beams Slide a Wheel (7) onto each axle at end of Rear Beam (4). Then secure with Bolt (5). For technical questions, please call 1-888-866-5797. Item 59201 Page 3...
- Page 4 10. Insert the Handle (2) through Smart of the Column (1), and insert the Pin (9). Cover and Mounting Plate (18) and replace the Handle Grip (22) that was removed previously to secure. For technical questions, please call 1-888-866-5797. Page 4 Item 59201...
- Page 5 Mounting Arms (19) to the engine. Secure the engine properly to the crane. Use the crane to support all of the engine’s weight directly overhead, but do not start lifting the engine stand. For technical questions, please call 1-888-866-5797. Item 59201 Page 5...
- Page 6 Note: Some parts are listed and shown for illustration purposes only, and are not available individually as replacement parts. Specify UPC 193175459695 when ordering parts. Record Serial Number Here: Note: If product has no serial number, record month and year of purchase instead. For technical questions, please call 1-888-866-5797. Page 6 Item 59201...
- Page 7 3" Wheel Nozzle Big Washer Ø14 Front Beam Smart cover 3-1/2" Wheel Middle Beam Washer Ø12 Nut M14 Mounting Plate Lock Washer Ø12 Mounting Arm Nut M12 Bolt M12x25 Bolt M14x60 For technical questions, please call 1-888-866-5797. Item 59201 Page 7...
- Page 8 Limited 90 Day Warranty Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper installation, normal wear and tear, or to lack of maintenance.
