DMTrade SPE-203DL Installation Manual

Model No:
Technical data
Column qty 3 Input voltage 100-240V
Max loading
125KG Max speed 38mm/s
capacity
Height range 600-1230mm Temperature 0- 40°C
Length range Certification
1100-1800mm CE FCC CUL
Frequency continuous operation for 2 mins at most after pause for 18 mins
Component list
8
10
5
6
4
3
2
1
No. Part Qty No. Part Qty No.
1 1 2 1
Short pedestal Long pedestal
No. Part Qty No. Part Qty No.
7
6 1 1
Short supporting plate Long supporting plate
SPE-203DL
Installation G uide
Accessor y list
Attention: The drawings below are only for reference which might be
slightly different from the actual object, please in kind prevail. Any
tools missing or installation problems, please contact the customer
service firstly.
No. Image
M6×16mm
A
ST4.2x20mm
B
M8×16mm
C
D
Square spacer
E
Wrench
4x4mm
Installation 1:
Right corner desktop
7
9
Installation 2:
Left corner desktop
Part Qty No. Part Qty No.
3 2 4 2
Lifting column Cable management
Part Qty No. Part Qty No.
Handswitch
8 1 9 1
Control box
Step 1
C
x4
E
C
5x5
6
Spec Qty Install Short supporting plate (6) and Long supporting plate (7) together, use
5*5mm Wrench(E) to tighten the screws (C).
8
18
Step 2
12
C
2 x8
Wrench
1 E
5x5mm
5x5
Install Lifting column (3) and Supporting
beam (5) together, and use 5*5mm
Wrench (E) to tighten the screws (C).
Set baseplate during installing
in order to prevent scratch from
Attention
direct touch with ground.
Step 3
A
x8
E
4x4
1
Part Qty
5 1
Supporting beam
Part Qty
10 1 Install Short pedestal (1) and Long pedestal (2) with
Lifting column (3) together, and use 4*4mm Wrench
Power cable
(E) to tighten the screws (A).
Installation 1: Right corner desktop
E
7
E
C
3
Installation 1: Right corner desktop Installation 2: Left corner desktop
Long side
E
2
A
3 1
Installation 2: Left corner desktop
E
C
7
6
5
E
2
Long side
A
3
