Summary of Contents for HOA OGEC-110P
- Page 1 OGEC-110P Quick Installation Guide ______________________________________________________________ PoE Media Converter Edition 1.0, Jan 2023 Technical Support Contact Information www.hoatech.com.tw/contact.php © 2023 Hoatech Technologies Co., Ltd. All rights reserved.
- Page 2 With full gigabit port and compact design, OGEC-110P not only increases the speed of your network server, but also deliver both up to 30W of power output and high data transmission speed to Power Devices.
- Page 3 Dimension Diagram (Unit: mm) Grounding the PoE Media Converter Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from the ground screw to the grounding surface prior to connecting devices. ATTENTION This product is intended to be mounted to a well-grounded mounting surface such as a metal panel.
- Page 4 LED Indicators The front/rear panel of media converter contains several LED indicators. The function of each LED is described in the table below. Description Color State Power On PWR 1 Green Power Off Power On PWR 2 Green Power Off Link is established and no traffic is detected FX_Link Green...
- Page 5 Specifications IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet Standard IEEE 802.3z 1000Base-X Gigabit Ethernet IEEE802.3x traffic and back pressure IEEE802.3 af/at Power over Ethernet/Power over Ethernet Plus 10/100/1000Base-T(X) Jumbo Frame Size 9Kbytes Transmission Distance Ethernet 100m Fiber...
- Page 6 -40 C ~ 85C Storage temperature Operating humidity 5 ~ 95% (non-condensing) Storage humidity 0 ~ 95% (non-condensing) MTBF >50000 Hours Safety EN60950-1, IEC60950-1 Certification Compliance CE, FCC EN61000-4-5 RoHS...
