Safety information Please read carefully the following information to prevent injuries, damage to material and device as well as data loss: Warning levels Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.
Page 3
Safety information 4. Hazards caused by very small parts and packaging Risk of suffocation WARNING Risk of death by suffocation or swallowing • Keep small parts and accessories away from children • Store/dispose of plastic bags and packaging in an area that is inaccessible to children •...
Page 4
Sicherheitshinweise Zur Vermeidung körperlicher Schäden, sowie von Sach-, Geräteschäden und Datenverlust beachten Sie bitte folgende Hinweise: Warnstufen Signalwort und Sicherheitszeichen kennzeichnen die Warnstufe und geben einen sofortigen Hinweis auf aWahrscheinlichkeit, Art und Schwere der Folgen, wenn die Maßnahmen zur Vermeidung der Gefahr nicht befolgt werden. warnt vor einer unmittelbar gefährlichen Situation, die zum GEFAHR Tod oder zu schweren Verletzungen führen wird.
Page 5
Sicherheitshinweise • keine Gegenstände auf dem Gerät/Netzteil abstellen 4. Gefahren durch Kleinstteile und Verpackung Erstickungsgefahr WARNUNG Lebensgefahr durch Ersticken oder Verschlucken • Kleinteile, Zubehör für Kinder unzugänglich verwahren • Plastiktüten und Verpackung für Kinder unzugänglich verwahren/entsorgen • Kleinteile und Verpackungen nicht in Kinderhände geben 5.
Page 6
Quick installation guide IB-RP109 Important product information Dear customer, please note the following information about the main boards which are suppor- ted by this device! The device has been developed for: • Compatible with: Raspberry Pi 4 Model B ®...
Page 7
Quick installation guide IB-RP109 Assembly • Please follow the drawing to assemble the appropriated Pi board to ® the IB-RP109. • The heat sinks (7/8) can be placed to the main chip sets on the PI ® board accordingly to their sizes.
Page 8
Quick installation guide IB-RP109 Note! • Start assembling from the bottom to the top, layer by layer. • Add the thermal pad (6) to the first layer below the chipset at the bottom of the Pi board. ® • After the second layer (10) you need to add the Pi board (not inclu- ®...
Page 9
• Kompatibel mit: Raspberry Pi 4 Modell B ® • Raspberry Pi Board, Antenne und Lüfter nicht im Lieferumfang enthalten ® Verpackungsinhalt: 6x Aluminiumscheiben des IB-RP109 1x Satz Kühlkörper 1x Satz Schrauben 1x Schnellinstallationsanleitung (Raspberry Pi nicht im Lieferumfang enthalten) ®...
Page 10
Schnellinstallationsanleitung IB-RP109 Zusammenbau • Um das entsprechende Pi Board einzubauen, folgen Sie bitte der ® Darstellung. • Die Kühlkörper (7/8) können bei Bedarf auf die entsprechend dimensio- nierten PCB Bauteile gesetzt werden. • Bitte entfernen Sie die Folie, bevor Sie die Kühlkörper anbringen.
Page 11
Schnellinstallationsanleitung IB-RP109 Hinweis! • Beginnen Sie mit der Montage von unten nach oben, Layer für Layer. • Positionieren Sie das Wärmeleitpad (6) auf den ersten Layer unterhalb des Chipsatzes an der Unterseite des Pi -Boards. ® • Nach der Installation des zweiten Layers (10) müssen Sie das Pi -Board ®...
