Summary of Contents for Midea IM1900MD
- Page 1 Ice Maker Kit MODEL: IM1900MD...
-
Page 2: Table Of Contents
Contents Introduction ............2 Important Safety Instructions. - Page 3 Ice Maker 4 Follow all instructions. 5 Do not place fingers or hands into the automatic ice making mechanism while the refrigerator is plugged in. Doing so my expose you to possible injury. 6 Keep your hands away from the ejector mechanism and the heating element that releases the ice cubes, located on the bottom of the ice maker.
-
Page 4: Features
Ice Maker Features • Produces up to 2.6 pounds of ice a day • Stores up to six pounds of ice • Prevents overflow by automatically detecting when storage bin is full Package contents Ice maker unit Ice Container Plastic Water Water Valve Plastic Clamp - Supply Tubing... -
Page 5: Installing The Ice Maker
(#5303917950) from your local hardware or plumbing supply store. Installing the ice maker Your Midea refrigerator comes set up for ice maker installation. Caution Unplug the refrigerator. To eliminate the danger of electric shock during installation, you must unplug the refrigerator. - Page 6 Ice Maker Remove the main body of the ice maker, take out the connecting plate of the water inlet sink from the accessories and insert it into the main body water inlet sink, and x the clamps (the selection steps for the refrigerator with the water owing from the top to the bottom from its internal water outlet port).
- Page 7 Ice Maker 4 Remove the terminal protection cover in the upper left corner of the freezer compartment, take out the screw and semi- x it at the positioning counterbore surface above the left side of the freezer compartment, then insert the power terminal of the ice maker main body into the socket with the upper left corner aligned, and nally suspend the ice maker main body integrally on the semi- xed screw.
- Page 8 Ice Maker After the installation of the ice maker main body, install the freezer door guide rail back to its position and place the freezer drawers. Then place the ice container from the accessories according to the stopper of the freezer drawer to store the ice. The internal installation of the ice maker box is nally completed.
- Page 9 Ice Maker 8 Then use the needle nose pliers or other tools to remove the sealed thermal insulation foam strip in the labeled sewer tube from the water hole. Clear foam strip 9 Take out the water tube connector, the sealing silicone piece, the long water supply tuber and the white head screw from the accessories.
- Page 10 Ice Maker Take out two plastic clamps from the accessories to x the long water supply tube, x the water tube clamp with screws to the embedded positioning hole on the back of the refrigerator, and tighten the screws. Plastic clamp Water supply tube 11 Take out the water valve from the accessories, connect the box terminal with the water valve terminal, use the plastic box and the...
- Page 11 Ice Maker 12 Then insert the other end of the long water supply tube directly into the quick change connector at the bottom of the water valve and tighten it. After that, place the water valve in accordance with the drawing and x the water valve iron bracket on the threaded hole of the side plate of the refrigerator press bin with the green screws in the accessories.
-
Page 12: Connecting The Ice Maker To The Water Supply
Ice Maker Connecting the ice maker to the water supply Before you begin, please note: • This water line installation is not warranted by the refrigerator or ice maker manufacturer. • Follow these instructions carefully to minimize the risk of water damage. - Page 13 Ice Maker 7 Fasten the shuto valve to the cold water pipe with the pipe clamp, then tighten the pipe clamp screws until the sealing washer begin to swell. Do not over-tighten or you may crush the tubing. 8 Route the tubing through a hole drilled in the wall or floor (behind the refrigerator or adjacent base cabinet) as close to the wall as possible.
- Page 14 Ice Maker 13 Slide a brass compression nut, then a ferrule (sleeve), onto the water supply line. 1/4” tubing 1/4” compression nut Water inlet valve 14 Push the end of the tubing into the water inlet valve as far as it will go or ¼-inch, then slide the ferrule (sleeve) into the valve inlet and finger tighten the compression nut onto the valve.
-
Page 15: Tips For Using Your Automatic Ice Maker
Ice Maker Tips for using your automatic ice maker Remember that water quality determines the quality of ice. The ice maker should not be connected to softened water. If the water softener has problems, chemical substances can damage the ice maker. To turn o the ice maker, raise the wire signal arm until it locks in the “up”... -
Page 16: Troubleshooting
Ice Maker Troubleshooting Caution Do not try to repair your ice maker yourself. Doing so invalidates the warranty. Problem Possible cause Possible solution The ice maker makes no ice The freezer temperature is too Make sure that the freezer temperature is low enough to make high. -
Page 17: Specifications
Ice Maker Problem Possible cause Possible solution The ice is discolored There may be impurities in the Flush out the water supply line and clean the ice mold tray. water supply line or the ice Install a water supply line filter if your refrigerator doesn’t have mold tray. - Page 18 Ice Maker Midea replacement parts shall be used and will be warranted only for the period remaining on the original warranty. The date on the bill established the warranty period should service be required. 1-866-646 4332.
- Page 19 Ice Maker...
- Page 20 Customer service Toll free: 1-866-646-4332 www.midea.com...
Need help?
Do you have a question about the IM1900MD and is the answer not in the manual?
Questions and answers
The arm that controls the ice maker is about 1/2 inch wide and made of plastic. it is referred as the wire arm that should be opened and closed, but the wide plastic piece will not move no power to the pump system???
If the wire arm on the Midea IM1900MD ice maker is stuck, check if there is too much ice jamming it or if it is in the wrong position, and free it if necessary. If there is no power to the pump system, check the shutoff switch. If the switch is broken, contact an appliance technician to have it tested.
This answer is automatically generated
Why does my ice maker have a 1/2 inch plastic arm that will not instead of a wire arm that is easy to move???
IM1900MD Is there an adjustment to produce more ice per day?
The Midea IM1900MD ice maker kit is designed to produce 2.7 lbs of ice per day and does not list any adjustable settings to increase daily ice production. Therefore, it cannot be adjusted to produce more ice per day.
This answer is automatically generated
I have water coming up to the water valve solenoid but nothing coming out of water valve solenoid
the 1900 ice maker filled with water froze the ice and it has been there for 36 hours and has not dumped the ice. I was told to unplug the refrigerator for 20 minutes then plug it back it to reset the machine, it has now been 12 hours later and ice is still the maker not harvested yet. How do I contact someone for help???
You can contact Midea customer support for the IM1900MD ice maker by calling the toll-free number 1-866-646-4332.
This answer is automatically generated
