AllScanner VXDIAG VCX-DoIP User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

Table of Contents

Need help?

Do you have a question about the VXDIAG VCX-DoIP and is the answer not in the manual?

Questions and answers

Summary of Contents for AllScanner VXDIAG VCX-DoIP

Page 2: General Information
This manual only describes the operation and use of the product. Please refer to the maintenance manual of the original vehicle for specific vehicle maintenance and diagnosis. Due to the product update, Shenzhen Allscanner Technology Co., Ltd. reserves the right to change the contents of this manual without prior notice to users.
Page 3: Product Introduction
Product Introduction Product Overview VCX-DoIP is the latest generation of vehicle network interface equipped with DoIP Ethernet diagnostic technology, integrating four automobile industry standards into one device, not only supporting all traditional vehicle bus protocols, but also supporting the latest high-speed Ethernet diagnostic protocol, with strong compatibility.
Page 4 Designed to meet four major automotive industry standards SAE-J2534-1/2 Pass-Thru Driver with EURO 5   ISO-22900 MVCI & D-PDU  ISO-13400 DoIP  RP-1210A/B/C Heavy Duty VDA J2534 Factory Grade ECU Programming Function  ECU software upgrade and calibration ...
Page 5 vehicle bus protocol ISO-13400 DoIP CAN125/CAN250/CAN500/CAN1000 ISO-9141 K-Line SAE-J1939 CAN ISO-14230 K-Line SAE-J1708/J1587 On RS485 ISO-17987 LIN BUS CAT DATALINK (Caterpillar) ISO-15765 CAN ATA DATALINK (Caterpillar) SAE-J1850-VPW (GM Class2) SAE-J1850-PWM (FORD SCP) ISO-11898-2 DWCAN ISO-11898-3 DWFTCAN SAE-J2411 SWCAN (GMLAN) VAG TP16 CAN VAG TP20 CAN (SAE-J2819) VAG KW81 (SAE J2818) SAE-J2610 SCI (Chrysler)
Page 6: Technical Specifications
Technical specifications Item Description 32-bit 560MHz MIPS processor 32MB FLASH network processor 128MB DDR 32-bit 180MHz ARM processor protocol processor 1MB FLASH Diagnostic interface (vehicle) ISO22900-1 standard 26PIN diagnostic interface DoIP interface (vehicle) ISO13400-4 Option1/2 Ethernet Wired interface (PC) USB3.0 Type-B Network Interface (PC) RJ-45 LAN 10/100M Ethernet Wireless Interface (PC)
Page 7: Pilot Lamp
pilot lamp Equipment working status (red) Always on after startup Flashes on error Fast blinking during wireless Wireless network status (blue) communication Slow flashing during wireless distribution network Flashing red during USB Host communication status (blue) communication Flashing blue for LAN communication Flashing red for legacy protocol Vehicle communication status (red)
Page 8: Software Installation Requirements
The VX Manager administrative tools and drivers must be installed on your PC before you can use the device to begin vehicle diagnostics. This installer is included on the product CD-ROM or you can download the latest version of the installer from the following link: http://www.allscanner.com http://www.vxdiag.net/#download Software Installation Requirements ...
Page 9 1. Run Setup 2. Double-click to run the VX Manager installer. 3. Start Installation 4. Welcome to the installation interface. Click [Next] to continue. 5. Select Installation Components 6. You can check the factory diagnostic drivers you want to install during this process, or you can use VX Mananger to freely install the factory drivers you want after installation.
Page 10 7. Installation in progress 8. Please be patient as the installation process may take several minutes. 9. Installation complete 10. Click[Finish] to finish the installation. A VX Manager shortcut will be generated on the desktop and Start menu after installation.
Page 11: Hardware Connection
Start of Use Hardware Connection Before using the equipment, the hardware must be correctly connected: the vehicle end of the equipment is connected to the vehicle through OBD-II diagnostic cable, and there are three ways to connect the equipment with the PC end: The PC end of the device is connected to the PC via a USB communication cable the PC side of that deviceis connecte to a PC via a LAN network cable Device connected to P C via WIFI...
Page 12: Usb Connection
USB connection The first time you connect the USB cable to your PC, Windows prompts you to find new hardware and automatically completes the driver installation. The network adapter can be seen in the device manager after the driver is successfully installed: Realtek USB FE Family Controller。...
Page 13 Device Connection Configuration The VX Manager default connection type configuration is: AUTO automatic, can support automatic identification of all connections, generally without modification. If you confirm that you need to modify the connection type, you can modify it in the Device Management-> Device Configuration interface. Device Connection Detection After the device is properly connected as described above, start the VX Manager management software.
Page 14: Basic Functions
VX Manager Administrative Tools Basic Functions Reconnect Reconnect the device and refresh the device information. Equipment Testing The device self-tests and the LEDs flash and beep. Restart the device The device is reset and restarted. Update Firmware Download and update the device firmware program online. Update Authorization Download and update device authorization data online.
Page 15 View Authorization Connect the VCX device to the computer.   Running the VX Manager Management Software  Open the [Device Management]->[Device Authorization] page to see all authorization lists supported by the current device. Update Authorization  The VCX device license must be updated online regularly. If it is not updated for more than 60 days, the device license will expire, which will affect the use of the authorized functions.
Page 16 Diagnostics Driven Management Start the VX Manager device management software, open the [Vehicle Diagnostics] tab, and click the [My Applications] option on the left side of the page to display the licensed diagnostic drivers. Install Diagnostic Driver Open the [Vehicle Diagnosis]->[My Application] page, click the diagnosis application to be installed, such as [FORD IDS], and the driver information interface will pop up.
Page 17 Driver Installation Process [Installation]V X Manager will obtain the latest diagnostic driver from the server and install it, and then you can start using the original diagnostic function. The installation interface is as follows: Update Diagnostic Driver With the upgrade of the original software, the diagnostic driver is continuously optimized and updated. Please always keep up to date! Open the [Vehicle Diagnosis]->[My Application] page.
Page 18: Warranty Clause
warranty clause One year limited warranty The product warranty period is one year. The warranty start time and end time shall be based on the date of supply invoice. If the invoice is lost, the purchase time shall be calculated according to the factory date.
Page 19: Maintenance Services
Please contact us as follows: Room A103-104, 1/F, Building A, Shenzhen Aerospace Science and Technology address Innovation Research Institute, No.6, Keji South 10th Road, South Hi-tech Zone, Nanshan District, Shenzhen Telephone +86-0755-33000960 Zip Code 518057 Product info@allscanner.com Consulting Technical support@allscanner.com support...
