- Page 1 SMART SPEAKER SP-104...
- Page 2 HELLO Thank you for purchasing Smart Speaker. We are excited to bring convenience, joy, and excitement into your home. Wi-Fi & Bluetooth Smart Speaker provides both Wi-Fi and Bluetooth. Remote Access Control and monitor your home devices from Internet. Programming Using BKC Services, you can automate and expand the functionalities of your Smart Speaker.
- Page 3 How to Install Smart Speaker Plug your Smart Speaker to a USB power outlet. Press the power switch located at the bottom of the device to turn the device on. Go to www.blocklychain.io www.blocklychain.io...
- Page 4 Log into your account in BKC Control Panel. [or signup if you don’t have an account.] www.blocklychain.io Login Click on Devices on the menu. My Home My Home Today Devices Services Tuesday, 29 September 2021 Home 12:28 Home Europe/London Devices...
- Page 5 Select Smart Speaker from the list. My Home Add New Device Choose your device type Home Choose the type of your new device you want to install Devices Service Market Installed Services Motion Detector Door Sensor Smart Button Smart Plug Smart Speaker Activity Service Creator...
- Page 6 Go to the Wi-Fi setting on your laptop/mo- bile and switch it to Smart_Speaker Wi-Fi. Smart_Speaker HomeWi-Fi James ST1QTJ1 Tigerx 2:28 pm 12/6/2020 Go back to BKC Control Panel and click on Next. My Home Add New Device Change your Wi-Fi Home Go to Setting on your mobile and connect to the Wi-Fi name “Smart_Speaker”.
- Page 7 Choose your home Wi-Fi from the list and type the password. Then, click on Check Wi-Fi. My Home Add New Device Set your home Wi-Fi Home Choose your home Wi-Fi from the list below. Devices Manual Setting Available Wi-Fi list My Wi-Fi Service Market Wi-Fi X...
- Page 8 How to Control Smart Speaker You can control your Smart Speaker either using buttons on the device or via Control Panel on your mobile or laptop. Smart Speaker buttons On / Off Play / Pause Volume Up Volume Down Turn On/Off Smart Speaker To turn on/off Smart Speaker, press and hold the On / Off button for 2 seconds.
- Page 9 Login to your account in BKC Control Panel. Then, go to the Devices page. Your Smart Speaker card will be like below. Name of the speaker Play / Pause Repeat Shuffle Volume Sound title Last activity time Battery level Device dashboard Device connection indicator The speaker is connected to the Internet The speaker is not connected to the Internet...
-
Page 10: Internet Radio
Internet Radio To listen to a live radio station, follow the below steps: Click on the sound title. Click on the Radio tab. Click on a radio channel. Music & Podcast Player To listen to a music or podcast, follow the below steps: Click on the sound title. -
Page 11: Update Device
Update device Go to Control Panel. Go to Devices page. On the device card, click on the device da- shboard. Go to the Config tab. Click on Update Now. Note You can check the LEDs on your device to ensure that the updating process is running correctly. -
Page 12: Device Dashboard
Device Dashboard Clicking on the gear icon on the Smart Speaker card, a pop-up window opens with 3 tabs. Monitor In Monitor tab, there are data about device functions. My Speaker smart speaker Monitor Data Graph Config State Volume Filename Play iLove.mp3 Battery... - Page 13 Config In Config tab, you can update firmware, rename device, set Wi-Fi, and remove your device from BKC Control Panel. My Speaker smart speaker Monitor Data Graph Config FC:F5:C4:A5:0D:E2 Device Details Type SMART_SPEAKER Firmware Version 1.2.0 Install Time 2 August 2021 Su 5:23 Hardware Version Rename Device New Version Available...
- Page 14 BKC Control Panel In BKC Control Panel, you can register, monitor, and control your BKC devices. www.blocklychain.io...
-
Page 15: Installing Control Panel
Installing Control Panel On the phone Open the Google Chrome browser. Go to www.blocklychain.io Click on Login. Log into your account. On the pop-up page, click on Add to Home Screen. On the desktop Open the Google Chrome browser. Go to www.blocklychain.io Click on Login. - Page 16 Blocklychain Services In BKC Control Panel, BKC Services are mini apps that add new functionalities to smart devices. You can access hundreds of BKC Services in Service Market or easily develop new services on Service Creator to extend the functionality of your Smart Speaker.
- Page 17 Service Creator In BKC Control Panel, using Service Creator, you can develop new services. How to create Blocklychain Services There are two programming consoles in Service Creator: 1. Blockly Console 2. Coding Console My Home 8952 Created Service Published Service Installed Service...
- Page 18 Speaker Play Emergency Alarm 1.mp3 Text Service Creator 2. Coding Console Coding Console enables professional devel- opers to program BKC services by JavaScript syntax for Blocklychain-enabled devices including Smart Speaker. My Home Home Devices Service Gallery Installed Services Activity Service Creator...
- Page 19 Status Indicator Description Installation Blinking White - every 1 second Connecting to Wi-Fi Blinking White - every 4 seconds Connecting to Control Panel on the Internet / Ready to install Smart Speaker Battery Solid Red Low battery charge Solid Blue Charging battery Solid Green Full battery charge...
- Page 20 Connectivity Smart Speaker connects to Wi-Fi and Bluetooth at the same time. Play via Bluetooth Bring your mobile close to Smart Speaker. - iPhone 1. Go to Setting > Bluetooth and turn it on. 2. Select Smart_Speaker from your Bluet- ooth list.
- Page 21 Caution 1. Do not disassemble the product or change the batteries. 2. Do not charge the product at high temper- ature. Keep the device away from open fire to avoid explosion. 3. Improper use of your device’s battery may result in fire or explosion.
-
Page 22: Specification
Specification Product Name Smart Speaker Model SP-104 Size 9(H) x 9(W) x 6(L) cm Weight 270 g Material Wood Device Voltage/Current DC 5V/1.5A Wi-Fi 802.11 b/g/n @ 2.4GHz Bluetooth v4.2 Amplifier 5 Watt Supporting Files .mp3, .aac, .ogg vorbis, .wma,... -
Page 23: Package Content
Package Content Smart Speaker Adapter For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Bocklychain...
