- Page 1 SMART PLUG PW-104...
- Page 2 HELLO Thank you for purchasing Smart Plug. We are excited to bring convenience, security, and peace of mind into your home. Remote Access Control and monitor your home devices from Internet. Manual Press Use the button as a manual switch by pressing it on the device.
- Page 3 How to Install Smart Plug Plug Smart Plug into a power outlet. Go to www.blocklychain.io www.blocklychain.io...
- Page 4 Log into your account in BKC Control Panel. [or signup if you don’t have an account.] www.blocklychain.io Login Click on Devices on the menu. My Home My Home Today Devices Services Tuesday, 29 September 2021 Home 12:28 Home Europe/London Devices...
- Page 5 Select Smart Plug from the list. My Home Add New Device Choose your device type Home Choose the type of your new device you want to install Devices Service Market Installed Services Motion Detector Door Sensor Smart Button Smart Plug Smart Speaker Activity Service Creator...
- Page 6 Go to the Wi-Fi setting on your laptop/mob- ile and switch it to Smart_Plug Wi-Fi. Smart_Plug HomeWi-Fi James ST1QTJ1 Tigerx 2:28 pm 12/6/2020 Go back to BKC Control Panel and click on Next. My Home Add New Device Change your Wi-Fi Home Go to Setting on your mobile and connect to the Wi-Fi name “Smart_Plug”.
- Page 7 Choose your home Wi-Fi from the list and type the password. Then, click on Check Wi-Fi. My Home Add New Device Set your home Wi-Fi Home Choose your home Wi-Fi from the list below. Devices Manual Setting Available Wi-Fi list My Wi-Fi Service Market Wi-Fi X...
- Page 8 How to Control Smart Plug Log into your account in BKC Control Panel. Then, go to the Devices page. Your Smart Plug card will be like below. Name of the Smart Plug Power On/Off button Current Indicator Last activity time Device dashboard Device connection indicator...
-
Page 9: Power On/Off
Power On/Off On your mobile/laptop Go to BKC Control Panel. Go to Devices page. On the device card, click on the Power On/ Off button. On your Smart Plug Press the button on the Smart Plug device. Update device Plug Smart Plug to a power outlet. Go to BKC Control Panel. -
Page 10: Device Dashboard
Device Dashboard Clicking on the gear icon on the Smart Plug card, a pop-up window opens with 3 tabs. Monitor In Monitor tab, there are data about power consumption. Plug_TV smart plug Monitor Data Graph Config Current State Voltage Option_overstate Data Graph In Data Graph tab, a bar chart represent power consumption during time. - Page 11 Config In Config tab, you can update firmware, rename device, set Wi-Fi, and remove your device from BKC Control Panel. Plug_TV smart plug Monitor Data Graph Config FC:F5:C4:A5:0D:E2 Device Details Type SMART_PLUG Firmware Version 1.2.0 Install Time 2 August 2021 Su 5:23 Hardware Version Rename Device New Version Available...
- Page 12 BKC Control Panel In BKC Control Panel, you can register, monitor, and control your BKC devices. www.blocklychain.io...
- Page 13 Installing BKC Control Panel On the phone Open the Google Chrome browser. Go to www.blocklychain.io Click on Login. Log into your account. On the pop-up page, click on Add to Home Screen. On the desktop Open the Google Chrome browser.
- Page 14 Blocklychain Services In BKC Control Panel, BKC Services are mini apps that add new functionalities to smart devices. You can access hundreds of BKC Services in Service Market or easily develop new services on Service Creator to extend the functionality of your Smart Plug.
- Page 15 Service Creator In BKC Control Panel, using Service Creator, you can develop new services. How to create Blocklychain Services There are two programming consoles in Service Creator: 1. Blockly Console 2. Coding Console My Home 8952 Created Service Published Service Installed Service...
- Page 16 Activity Text Service Creator 2. Coding Console Coding Console enables professional devel- opers to program BKC services by JavaScript syntax for Blocklychain-enabled devices including Smart Plug. My Home * Describe this function ... if ((Door1.PAYLOAD.state === ‹OPEN›)) { Home Power1.SEND_COMMAND(‹TURN_ON›);if (!(Button1.PAYLOAD.state === ‹hold›)) { Devices Power1.SEND_COMMAND(‹TURN_ON›);for (var count = 0;...
- Page 17 Smart Energy Management Smart Energy Management (SEM) is one of the main features in Control Panel which enables users to monitor their energy consumption. Users can see the detailed charts of energy consumption for devices which are connected to Smart Plug at realtime, daily, and monthly intervals.
- Page 18 Status Indicator Description Fast blinking Connecting to Wi-Fi Blinking every 4 seconds Connecting to Blocklychain server on the Internet Solid ON Smart Plug is ON Solid OFF Smart Plug is OFF...
- Page 19 Caution 1- Do not install your Smart Plug in a wet en- vironment, for example, near a bath tub, sink, or swimming pool or in a wet basement. 2- Avoid installing in areas prone to high am- ounts of dust, direct sunshine or heat. 3- Please take the Technical Data (in particular the maximum permissible switching capacity of the relay and the type of load to be connected)
- Page 20 – Connect the plug to an accessible, grounded wall socket. In the event of danger, pull the device out of the mains socket. – Do not insert plugs in a row. – Do not use plugs in multiple socket ou- tlets or with extension leads.
- Page 21 is no longer usable and defective must be separated from other waste and recycled in an environmentally friendly manner (European Directive on waste electrical and electronic equipment). To dispose of electrical and electronic equipment, use your country-specific return and collection systems.
-
Page 22: Specification
Specification Product Name Smart Plug Model PW-104 Size 11(H) x 6.2(W) x 7.2(L) cm Weight 138 g Material Power load 10A resistive max Rated Voltage (NA) AC 110V 50/60Hz Rated Voltage (EU) AC 220V 50/60Hz Switching Relay Protection 10A glass fuse Wi-Fi 802.11 b/g/n 2.4GHz... -
Page 23: Package Content
Package Content 1x Smart Plug For further help or inquiries: 1) Email support@blocklychain-iot.com, or 2) Login to your account on BKC Control Panel , click , and submit a ticket. All right reserved. Copyright © 2022 Blocklychain...
