- Page 1 AirMax5N/ESD 802.11a/n 1T1R Wireless Outdoor CPE User’s Manual Version 3.0...
- Page 2 Copyright and Disclaimer Version 3.0 This guide is written for firmware version 3.0 or later. Copyright & Disclaimer No part of this publication may be reproduced in any form or by any means, whether electronic, mechanical, photocopying, or recording without the written consent of OvisLink Corp.
- Page 3 SUBJECT TO THE FOLLOWING TWO CONDITIONS: (1) THIS DEVICE MAY NOT CAUSE HARMFUL INTERFERENCE AND (2) THIS DEVICE MUST ACCEPT ANY INTERFERENCE RECEIVED, INCLUDING INTERFERENCE THAT MAY CAUSE UNDESIRED OPERATION. All Trademarks are properties of their respective holders. AirLive AIRMAX5N/ESD User’s Manual...
-
Page 4: Table Of Contents
3.4 Introduction to Web Management ............ 18 3.4.1 Welcome Screen and Login...............18 3.5 Initial Configurations ................ 20 3.5.1 Choose the wireless Operation Modes ............20 3.5.2 Change the Device’s IP Address ...............21 3.5.3 Set the Time and Date ................22 3.5.4 Change Password ..................22 AirLive AirMax5N/ESD User’s Manual... - Page 5 5.1.3 Password Settings ..................52 5.1.4 System Management.................53 5.1.5 Ping Watchdog ..................53 5.1.6 Firmware Upgrade ..................54 5.1.7 Configuration Save and Restore..............55 5.1.8 Factory Default ..................56 5.2 Device Status................... 57 5.2.1 Device Information..................57 5.2.2 Wireless Information...................58 5.2.3 Internet Information..................58 AirLive AirMax5N/ESD User’s Manual...
- Page 6 7.2.1 AP Wireless Settings .................64 7.3 Client: Client Mode ................67 7.3.1 Device C IP Address..................67 7.3.2 Client Wireless Settings................68 8. Specifications ..................70 8.1 Features ..................70 8.1.1 General Feature ..................70 8.2 Specifications................... 70 9. Wireless Network Glossary..............73 AirLive AirMax5N/ESD User’s Manual...
-
Page 7: Introduction
This product requires professional installation. Please do not attempt to install the device without the necessary knowledge in regards to your country's wireless regulations. Functions and features in your product’s firmware might be different due to regulations in your country. AirLive AirMax5N/ESD User’s Manual... -
Page 8: How To Use This Guide
4.2.5 and 4.2.6 Channel and Channel Width: This part explains the concept of variable Channel Width and how to use them. Channel Width can be 40MHz, or 20MHz. 4.3 WDS Settings: Here explains the WDS setting page. AirLive AirMax5N/ESD User’s Manual... -
Page 9: Firmware Upgrade And Tech Support
Since 2009, AirLive has added the “Newsletter Instant Support System” on our website. AirLive Newsletter subscribers receives instant email notifications when there are new download or tech support FAQ updates for their subscribed airlive models. To become an AirLive newsletter member, please visit: http://www.airlive.com/member/member_3.jsp AirLive AirMax5N/ESD User’s Manual... -
Page 10: Features
The AirMax5N can perform as a multi-function wireless device. Through the AirLogic web interface, users can easily select which wireless mode they wish the AirMax5N to perform. The AirMax5N can be configured to operate in the following wireless operation modes: AirLive AirMax5N/ESD User’s Manual... -
Page 11: Access Point Mode
Because the radio is divided into client + AP mode, the Repeater mode will have less performance and distance. We recommended using a dual radio product like Airlive Duo or A.Duo if you require full performance in this application. AirLive AirMax5N/ESD User’s Manual... -
Page 12: Wds Bridge Mode
Distribution System) capability. If you require the PC’s MAC addresses to be preserved when the data pass through the Repeater, it is necessary to use the WDS Repeater mode. Because the radio is divided into WDS + AP mode, the Repeater mode will have less performance and distance. AirLive AirMax5N/ESD User’s Manual... -
Page 13: Client Infrastructure Mode
Infrastructure Mode. On the LAN side, it acts like a wired router for IP sharing function. This mode is best used for IP sharing application for WISP subscribers. In this mode, the WAN is the wireless client side; the LAN is the wired side. AirLive AirMax5N/ESD User’s Manual... -
Page 14: Ap Router Mode
AirMax5N will become WAN port. Both the wireless and the passive PoE port of AirMax5N becomes the LAN side. User can manage the AirMax5N through the wireless or passive PoE port. And if the remote management is opened, user can also get to manage AirMAx5N via the WAN side. AirLive AirMax5N/ESD User’s Manual... -
Page 15: Installing The Airmax5N
30 degree in horizontal direction. The AirMax5N is a 5GHz CPE device only; it cannot operate in 2.4GHz. If you choose to use the external antenna, please remember to connect the external antenna first before power on AirMax5N. AirLive AirMax5N/ESD User’s Manual... -
Page 16: Package Content
The PoE Ethernet cable is not included in the package. You may choose an outdoor specification Ethernet cable according to the length you need. 2.3 Knowing your AirMax5N Below are descriptions and diagrams of the product: AirLive AirMax5N/ESD User’s Manual... - Page 17 Data is transmitting or receiving on the wireless. Port linked. No link. 3. WAN LED Data is transmitting or receiving on the WAN Flashing interface. Port linked. No link. 4. LAN LED Data is transmitting or receiving on the LAN Flashing interface. AirLive AirMax5N/ESD User’s Manual...
-
Page 18: Hardware Installation
1. Push the button in the side to remove 2. Pass through Ethernet cable from the hole; upper housing. insert the cable to Secondary port. 3. Install the upper housing and make 4. Install POE Injector sure the housing is well installed. AirLive AirMax5N/ESD User’s Manual... -
Page 19: Standard Pole Mount
Male R-SMA to Male N-Type connector. Please note that you should not connect the power until the external antenna is attached to avoid damaging the Once you have the converter cable, please follow the installation steps below. AirLive AirMax5N/ESD User’s Manual... - Page 20 Connect the converter cable to the antenna port. Please run the cable through the cable hole Push back the cover. You should connect the AirMax5N to an external antenna before power on to avoid damaging the RF AirLive AirMax5N/ESD User’s Manual...
