Mustang EMT501B Specifications

Mustang Pro Audio Bundles
Commerical/Education Good Solution:
PA-CEGCM - CEILING MouNt
Mustang
EMT501B
• Built in metal back box
• Power selector terminal on rear
Atlas
PA702
The PA702 includes a unique (patent pending) mounting system
that allows mounting-pole access through the amplifier via a sealed
hole incorporated into the chassis design. Simply install the projector
mounting pole, align the amplifier chassis hole with the 1.5" mount-
ing tube, & clamp the unit at the desired height above the projector
mount with the innovative pole clamp system included with the
PA702. Afterwards, install the projector as normal. As a side benefit,
the chassis "hole" mounting system provides the necessary security
to prevent theft. Output is a strong 70 watts x 2 from the efficient
rail tracking Class AB & switch mode power supply technology. Aside
from the patent pending chassis design, the PA702, includes a host of
other innovative features including an accessory outlet with AC cur-
rent sense that allows the amplifier to respond instantly from stand-
by mode when the projector is powered on. The slim profile chassis is
also designed to work in a rack mount configuration. The optional rack
mount kit allows single or dual mounting of the PA702 in the 1RU high
configuration.
Ceiling Mount
2 SPEAkErS, 2 t-BAr SuPPortS, 1 PoLE MouNt AMPLIfEr, 1 WIrELESS MIC.
Qty. 2
• 5.5" Background
Speaker w/ Back Box
• Same as above. Works with mouse trap series.
• 24" one piece tile support
• For use with EPCS502B speaker systems.
Qty. 1
• Pole Mount Amplifer
2x 70 watts
SR40 FLEXX- Diversity Reciever
• Audio Outputs: bal. XLR and
unbal. 1/4" jack, output level
adjustable, at rated deviation:
500 mV rms.
• Modulation: FM
• Audio Bandwidth: 35 to 20,000 Hz
• Signal/noise ratio: 120/230 V AC
• THD: typ. 0.8% (at rated 1 kHz)
Microphone SR 40 Single: Diversity Reciever, SR 40 Dual: Diversity
Reciever, PT 40 Pro: Microphone,HT 40 Pro: Microphone, CK 55 L:
Clip-on Microphone
Mustang
EMTBS501 • T-Bar Support for
EMT501
AkG
WMS40PRO/55 • Wireless Lavalier
Microphone
PT 40 FLEXX- Microphone
• Modulation: FM
• Signal/Noise Ratio: typ. 110 dB (A)
• RF Output: typ. 10 mW (ERP)
• Battery Life: typ. 30 h
(for 2200 mAh)
• Dimensions: 2.4 x 2.9 x 1.2 in.
• THD: typ. 0.8% (at 1 kHz)
Includes: Options CK 55 L: Clip-on
Qty. 2
Qty. 1
