5 kWh Home Battery

Installation Manual

Model Number: AS-5KW-LB2

Table of Contents

Need help?

Do you have a question about the AS-5KW-LB2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Altius AS-5KW-LB2

Page 1 PROTECT YOUR WARRANTY This unit must be installed by a registered, licensed installer as required by Government regulations. 5 kWh Home Battery Installation Manual Model Number: AS-5KW-LB2...
Page 2: Table Of Contents
Contents Important Safety Information Product Overview Getting Started Installation Startup and Shutdown Procedure Equipment Interface Instructions Operations Troubleshooting Other Useful Information Installer’s Notes After Sales Support 1300 886 605 (AUS) | tempo.org/support...
Page 3: Important Safety Information
Important Safety Information IMPORTANT SAFETY INSTRUCTIONS READ CAREFULLY AND KEEP FOR FUTURE REFERENCE Read this manual thoroughly before first use, even if you are familiar with this type of product. The safety precautions enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to. Keep the manual in a safe place for future reference, along with the completed warranty card, purchase receipt and carton.
Page 4 Important Safety Information (Cont.) • Static electricity: Any static electricity could damage veneer on the electrostatic sensitive components. Before touching the plug in, circuit board or chips, be sure to use correct electrostatic prevention measures. • WARNING! Power supply: When installing or maintaining this battery, the power supply must be disconnected first.
Page 5 Important Safety Information (Cont.) • DANGER! Battery terminals: Verify that no voltage between the battery terminals and the ground is present before maintenance or repair. In this product, the battery circuit is not isolated from the input voltage. Hazardous voltages may occur between the battery terminals and the ground.
Page 6: Product Overview
Product Overview Fig. 1 Side Front After Sales Support 1300 886 605 (AUS) | tempo.org/support...
Page 7 Product Overview (Cont.) Scope of delivery Parts list Wall Mount Wiring Block Battery Management System (BMS) Switch CAN2.0B COMM to inverter / RS485 COMM to inverter RS485 COMM to parallel battery / RS485 COMM to parallel battery LED indicators Red alarm indicator SOC indicators DIP switches 10 Grounding enclosure...
Page 8 Product Overview (Cont.) Battery Panel Diagram (Fig. 2) Battery Interface Image (Fig. 3) After Sales Support 1300 886 605 (AUS) | tempo.org/support...
Page 9: Getting Started
Getting Started Unpacking • This product has been packaged to protect it against transportation damage. Unpack the battery and lay out the separate components. Keep the original packaging carton and materials in a safe place. It will help prevent any damage if the product needs to be transported in the future.
Page 10: Installation
Installation Diagram of system Fig. 4 This system works through connection with solar panels and the grid. Firstly, your solar panels generate energy from the sun in the form of DC electricity. This then flows through an inverter, which converts the DC electricity into AC electricity for use in the home.
Page 11 Installation (Cont.) Installation Location • The installation location of this product is key. It should be installed indoors in a location that can be accessed conveniently for maintenance purposes. The installation location should also allow for sufficient space for pedestrian passage. •...
Page 12 Installation (Cont.) Installation Procedure WARNING! Make sure the main wire is in compliance with the standard of rated capacity of battery to avoid hazards like electric shock or fire. WARNING! Do not use the wall receptacle as the input power source for the battery, as its rated current is less than the battery’s maximum input current.
Page 13 Installation (Cont.) • Prior to wiring, check the anode and cathode of the battery. The anode and cathode terminals should MUST be connected correctly. • During battery connection, please wear protective gloves. When using metal tools, such as a as torque wrench, please use insulating packaging so that the two ends of the metal tools will not make contact with the positive and negative terminals of the battery at the same time, to avoid a short-circuit.
Page 14 Installation (Cont.) Installation of the lithium battery, wiring and startup; • Make sure the battery pack is switched off, before installing it onto the wall- mounting bracket. • The anode and cathode of the battery pack should be connected to the switching mode power supply or inverter.
Page 15 Installation (Cont.) Fig. 8 Connecting the wires WARNING! Ensure the power is completely switched off before installing any wires! Failure to take the correct precautions can result in electrocution, serious injury, or death. See pages 3-5 for comprehensive safety instructions, as well as specific safety information on pages 12-13.
Page 16 Installation (Cont.) • Connect both the positive and negative power lines of the inverter and battery, according to the setting of the circuit breaker (Fig. 9). • Please note, the cable from circuit breaker to inverter is not provided. • Use the screw hole indicated with a red square to install another grounding wire (Fig.
Page 17 Installation (Cont.) Software Installation Optionally, you can install battery monitoring software onto your computer system, to fully configure the battery monitor the battery parameters. (Note: Battery monitoring software is achieved via the inverter monitoring app.) Installation of Battery/Batteries in Parallel IMPORTANT! Installation and wiring must be completed in accordance with local electrical laws and regulations.
Page 18 Installation (Cont.) Four packs: 20.48 kWh And so on. Parallel Communication • When multiple packs are connected in parallel, the RS485 interface is used as the parallel communication interface. The client pack can read the sum of the server battery data of all parallel packs through the RS485 communication. Two packs RS485 parallel connection 1: Fig.
Page 19 Installation (Cont.) • In parallel system, choose the positive power line of the inverter and last battery, according to the setting of the circuit breaker (Fig. 12). Just plug the power line in breaker. Fig. 12 • Please note, the cable from circuit breaker to inverter is not provided. •...
Page 20 MPPT charger controllers or UPS, must have the pre-settings below implemented before you start. Setting AS-5KW-LB2 Max. Charging Voltage 57 V Floating Charging Voltage 57 V Max.
Page 21 Installation (Cont.) • Please connect the inverter and battery BMS as outlined in the diagram below (Fig. 14) Fig. 14 After Sales Support 1300 886 605 (AUS) | tempo.org/support...
Page 22 Installation (Cont.) DIP Switches For multi-battery communication where the battery packs are connected in parallel, use the DIP switch to distinguish different pack addresses. The hardware address can be set by the DIP switch on the panel below. Fig. 15 Fig.
Page 23: Startup And Shutdown Procedure
Startup and Shutdown Procedure Boot sequence: Click Battery Management System (BMS) Switch. The SOC indicators are on, the RUN indicator is always on, and the ARM indicator is off. Turn on the DC isolation connecting the inverter to the battery. Closing sequence: Click Battery Management System (BMS) Switch.
Page 24: Equipment Interface Instructions
Equipment Interface Instructions Address Switch Function (only in parallel) When the batteries are set up to work in parallel, the host/client pack and server packs need to be addressed as follows: Dial code switch position Instruction No cascade, use single Set to Pack1 (Host/Client) Set to Pack2 Set to Pack3...
Page 25: Operations
Operations LED Indicators: System Status Definition Switch on Sleeping All OFF Standby Normal SOC Indicators Standby Normal SOC Indicators Flashing OC ALM Flashing SOC Indicators Flashing Charging OV ALM SOC Indicators OT ALM Flashing SOC Indicators Normal Flashing Indicators SOC Indicators Alarm Flashing Flashing...
Page 26: Troubleshooting
Troubleshooting If the system is not operating correctly, please see the table below for troubleshooting options. Issue Possible Cause Solution No indicator or alarm on Press “Reset” to enter Sleep mode the front display panel normal operation mode The indicator light will turn on for (approx.) 3 seconds Battery voltage too low Charge battery immediately...
Page 27 Troubleshooting (Cont.) • Current: If current is larger than 75 A, battery protection will turn on. To fix this, check whether current is over this limit. If it is, change the settings on the power supply side. • High Voltage: If the charging voltage is above 57 V, the battery protection will turn on.
Page 28: Other Useful Information
Other Useful Information Storage Before storing this battery, charge it at for least 7 hours. Store the battery covered and upright in a cool, dry location. The recommend long-term storage temperature is -10 °C - 35 °C. During storage, recharge the battery every 3 months for 1-2 hours (assuming a storage temperature of -10 °C - 35 °C).
Page 29 Other Useful Information (Cont.) Service, repair and spare parts CAUTION! If your battery appears not to be operating correctly, contact our after sales support centre for advice. Do not attempt to repair the appliance yourself! Please note that if you book a service, the appliance must be accessible for the technician to perform any necessary repair.
Page 30 Other Useful Information (Cont.) Battery Pack Technical Specifications Model Number AS-5KW-LB2 Nominal voltage 51.2 V Rated capacity 100 Ah Rated reserved energy 5120 Wh Standard charging current 40 A Maximum continuous charging current 40 A Minimum continuous charging current 10 A Total charging cut-off voltage 57.6 V...
Page 31 Other Useful Information (Cont.) Compliance This appliance has been fully tested and meets all requirements as set out by standards AS IEC 62691 & AS/NZS 62368 & EN 61000. The RCM Mark (Regulatory Compliance Mark) indicates that the product complies with the relevant guidelines of the ACMA as well as corresponding government requirements for the safety of electrical devices.
Page 32 Other Useful Information (Cont.) Licensed installer/electrician details Please ask your licensed installer/electrician to fill in the details below so you have them on record should you need to contact the installer in the future. Proof of professional installation is also required for warranty claims. Please fill in the details below: Name of licensed installer: ............
Page 33: Installer's Notes
Installer’s Notes After Sales Support 1300 886 605 (AUS) | tempo.org/support...
Page 34 Installer’s Notes (Cont.) After Sales Support 1300 886 605 (AUS) | tempo.org/support...
Page 35 Installer’s Notes (Cont.) After Sales Support 1300 886 605 (AUS) | tempo.org/support...
Page 36 Warranty returns Should you for any reason need to return this product for a warranty claim, make sure to include all accessories with the product. Product does not work? If you encounter problems with this product, or if it fails to perform to your expectations, make sure to contact our After Sales Support Centre on (AU) 1300 886 605 for advice.
