- Page 1 OPERATOR MANUAL SOUTHWEST POST LIFT POST MATERIAL HANDLING SERIAL NUMBER PR21.43 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355...
-
Page 2: Table Of Contents
CHECK LIFT CHAIN TENSION ........................14 TENSION THE LIFT CHAIN .......................... 15 APPROVAL DRAWING ..........................16 ELECTRICAL SCHEMATIC ........................... 17 PNUEMATIC SCHEMATIC ..........................20 WARRANTY ..............................21 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355... -
Page 3: Introduction
INTRODUCTION This manual provides operating, maintenance and service information regarding the Post Material Handling Post Lift. Keep this manual available to management, operator and maintenance personnel who are responsible for the equipment’s operation and maintenance. It is essential to read, understand and follow the recommendations of this manual before operating or servicing this equipment. -
Page 4: General Specifications
Switch the LOAD DISCH switch to the DISCH position. The drum cradle will rise. 10. Press the RESET button again to put the Post Lift in manual inversion mode. The indicator light will display 1 slow and 3 fast blinks. -
Page 5: Teach Mode Of Operation To Set Positions (Maintenance Only)
12. Switch the LOAD DISCH switch to the DISCH position. The drum cradle will invert to the load position. 13. Press the RESET button again to put the Post Lift in manual slew mode. The indicator light will display 1 slow and 4 fast blinks. -
Page 6: Emergency Stop
46 ¾” from the inlet port of the receiving equipment. This is the 46 ¾” reach dimension shown in the layout drawing below. 2. The carriage is shipped above the center of gravity. Strap the post at the carriage and lift it into position under the top plate. - Page 7 6. Following the procedure describe in the manual control section in this document, lower the car- riage to a height where the inversion assembly can be installed. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com...
- Page 8 Install the inversion assembly. There are (4) hooks that mount the inversion assembly to the carriage. Tighten the set screws. Install the slot cover. Insert the slot cover screws through the slot cover retainer and into the slot cover mounts. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355...
- Page 9 Serpentine the slot cover behind the slot cover guide rods and in front of the carriage plates. Attach the slot cover mounts to the tensioner at the base of the machine. Tighten the tensioner bolt. Install the inversion shroud using the supplied hardware. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com...
-
Page 10: Maintenance
1 slow blink and 1 fast blink: Manual clamping mode is active. 1 slow blink and 2 fast blinks: Manual lift/lower mode is active. 1 slow blink and 3 fast blinks: Manual inversion mode is active. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com... -
Page 11: Removing The Inversion Access Cover
REMOVING THE INVERSION ACCESS COVER Remove the access cover screws to gain access to the pneumatic adjustments. Adjust the pneumatic regulator up or down to increase or decrease the drum clamping pressure. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com... -
Page 12: Gain Access To The Inversion Components
GAIN ACCESS TO THE INVERSION COMPONENTS Remove the inversion shroud removal screws on both sides of the inversion shroud to gain access to the inversion components. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355... -
Page 13: Cleaning Procedures
Main power should be disconnected at the service panel supplying the lift. A secondary disconnect is located on the front of the control enclosure. DISCHARGE VALVE AND ACTUATOR REMOVAL Remove the tri-clamp connector to remove the discharge valve and actuator assembly. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355... -
Page 14: Check Lift Chain Tension
Remove the slot cover as described earlier. Check the chain tension on the underside of the carriage. The chain tension sensor has a light that should be illuminated when the chain is properly tensioned. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com... -
Page 15: Tension The Lift Chain
If the chain is loose, tighten the chain tensioning double nuts. Do not over tighten. If the chain cannot be tensioned any more, replace the chain. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com... -
Page 16: Approval Drawing
APPROVAL DRAWING POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355... -
Page 17: Electrical Schematic
ELECTRICAL SCHEMATIC POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355... - Page 18 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355...
- Page 19 POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355...
-
Page 20: Pnuematic Schematic
PNUEMATIC SCHEMATIC POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com 845-200-3355... -
Page 21: Warranty
Expendable items or normally wearing parts such as bearings, seals, gaskets, diaphragms, slot cover, silencers, hoses, etc. are specifically excluded from this warranty. POST MATERIAL HANDLING 21 Stone Castle Road, Rock Tavern, NY 12575 www.posthoist.com...
