GIGAIPC QBiX-Plus-EHLA6412-A1 Quick Start Manual

Industrial embedded system
Table of Contents

Advertisement

Quick Links

QBiX-Plus-EHLA6412-A1
(QS-6412A-SI)
Industrial Embedded System
Quick Start Guide
1
www.gigaipc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QBiX-Plus-EHLA6412-A1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for GIGAIPC QBiX-Plus-EHLA6412-A1

  • Page 1 QBiX-Plus-EHLA6412-A1 (QS-6412A-SI) Industrial Embedded System Quick Start Guide www.gigaipc.com...
  • Page 2: Copyright Notice

    Beijer assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. GIGAIPC reserves the right to make changes in the product design without notice to its users. www.gigaipc.com...
  • Page 3: Acknowledgement

    Core, Atom are trademarks of Intel Corporation • • ITE is a trademark of Integrated Technology Express, Inc. IBM, PC/AT, PS/2, and VGA are trademarks of International Business • Machines Corporation. All other product names or trademarks are properties of their respective owners. www.gigaipc.com...
  • Page 4: Packing List

    PSU ADP 19V 65W 100-240VAC (P/N: 25EP2-10065U- A3S) RJ45 to D-SUB Cable #24 150mm (P/N: 25CR0-150400- S9R) VESA Mount Bracket (P/N: 25HB1-TPL021-S8R) VESA Mount screws (P/N: 25KSD-000002-C0R) If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com...
  • Page 5: About This Document

    This User’s Manual contains all the essential information, such as detailed descriptions and explanations on the product’s hardware and software features (if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. www.gigaipc.com...
  • Page 6: Safety Precautions

    Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com...
  • Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
  • Page 8: Fcc Statement

    Skilled person have to pay special attention or take special protection. Only authorized by well trained professional person can access the restrict access location. (2) External metal parts are hot!! Before touching it, special attention or protection is necessary www.gigaipc.com...
  • Page 9: Table Of Contents

    FCC Statement ................8 High Temperature Warning ............8 Chapter 1 - Product Specifications Specifications ............... 14 Chapter 2 – QBiX-Plus-EHLA6412-A1 (QS-6412A-SI) Dimension ..............17 Getting Familiar with Your Unit........18 A) Wireless Module : How to safely install the Module (Wireless Module inclusion may vary based on local distribution) ..............
  • Page 10 3.2.11 M2E (M.2 Slot, E-key, NGFF 2230) ........ 40 3.2.12 PWR_BTN (Power button with LED) ......41 3.2.13 HDMI3 (HDMI connector) ..........42 3.2.14 RJ45_COM (Serial Port (RS-232)(RJ45 type)) ....43 3.2.15 USB3_2 (USB 3.2 Gen 1 connector) ......44 www.gigaipc.com...
  • Page 11 Super IO Configuration ..........54 4.3.6 Hardware Monitor ............55 4.3.7 Network Stack Configuration ........56 4.3.8 NVMe Configuration ............. 57 4.3.9 Offboard SATA Controller Configuration ...... 58 Chipset ................59 Security ................. 60 Boot ................63 Save & Exit ..............64 www.gigaipc.com...
  • Page 12: Chapter 1 - Product Specifications

    Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com...
  • Page 13 107.29 23.14 61.0 30.8 26.8 14.0 77.0 1.14 1.15 105.0 www.gigaipc.com...
  • Page 14: Specifications

    Specifications System QBiX-Plus-EHLA6412-A1 (QS-6412A-SI) Dimension System Size : 165W x 105D x 27H (mm) Intel® Celeron® J6412 Processor 10nm, 4 cores, 4 threads, up to 2.60 GHz TDP 10W 2 x DDR4 SO-DIMM sockets, Max. Capacity 32 GB Memory Support Dual Channel DDR4 3200 MHz memory modules...
  • Page 15 System QBiX-Plus-EHLA6412-A1 (QS-6412A-SI) Operation: IEC 60068-2-64, 3 Grms, random, 5 ~ 500 Hz, 1 hr / Per Vibration Axis, With SSD/M.2 2280 During Non-operation: IEC 60068-2-6, 2 G, Sine, 10 ~ 500 Hz, 1 Oct/min, 1 Operation hr / Per Axis...
  • Page 16: Chapter 2 - Qbix-Plus-Ehla6412-A1 (Qs-6412A-Si)

    Chapter 2 Chapter 2 – QBiX-Plus-EHLA6412-A1 (QS-6412A-SI) www.gigaipc.com...
  • Page 17: Dimension

    Dimension 107.29 23.14 61.0 30.8 26.8 14.0 77.0 1.14 1.15 105.0 www.gigaipc.com...
  • Page 18: Getting Familiar With Your Unit

    2 x USB 3.2 Gen 1 External Antenna Holes (Optional) 2 x RJ45 LAN Ports 2 x HDMI DC Jack [Front Side] [Right Side] 2 x USB 3.2 Gen 1 Power button HDMI Micro SD COM Port (RS-232)(RJ45 Type) www.gigaipc.com...
  • Page 19 Follow below direction to push the bottom cover. open the chassis. ( * Caution : Stop pushing the bottom cover when the slide rail appeared. ) Please lift the bottom cover up vertically to avoid damaging the thermal pad. www.gigaipc.com...
  • Page 20 [Bottom PCB Side] Information A M.2 2230 E-Key connector B M.2 3042 B-Key connector C M.2 2280 M-Key connector D DDR4 SO-DIMM Slot www.gigaipc.com...
  • Page 21: A) Wireless Module : How To Safely Install The Module (Wireless Module Inclusion May Vary Based On Local Distribution)

    Module (Wireless Module inclusion may vary based on local distribution) Carefully insert the wireless module into Lock the screw in the middle. the M.2 slot 青山依舊在,幾度夕陽紅。慣看秋月春風。一 壺濁酒喜相逢,浪花淘盡英雄。是非成敗轉頭 Install the antenna on the left side of the connection wireless module down. www.gigaipc.com...
  • Page 22: B) 5G Module Installation: How To Safely Install The Module (5G Module Inclusion May Vary Based On Local Distribution)

    B) 5G module Installation: How to safely install the module (5G Module inclusion may vary based on local distribution) Remove the screw from the screw hole (Loca�on : MSO1) Carefully insert the 5G module into the slot, and secure with the screw. www.gigaipc.com...
  • Page 23: C) M.2 Ssd Installation: How To Safely Install The M.2 2280 Ssd

    C) M.2 SSD Installation: How to safely install the M.2 2280 SSD Remove the screw from the screw hole (Loca�on : MSO7) Carefully insert the M.2 SSD into the slot, and secure with the screw. www.gigaipc.com...
  • Page 24: D) Memory Installation: Ddr4 So-Dimm

    D) Memory Installation: DDR4 SO-DIMM www.gigaipc.com...
  • Page 25: Antenna Installation (Antenna Inclusion May Vary Based On Local Distribution)

    Antenna Installation (Antenna inclusion may vary based on local distribution) Either for Wifi antenna or 5G antenna installation. www.gigaipc.com...
  • Page 26: Vesa Bracket Installation

    VESA Bracket Installation A�ach the screws provided on the underside of A�ach the VESA moun�ng plate to the rear of a compa�ble the QBiX-Plus. display using the screws provided. The QBiX-plus can now be mounted by sliding the device into place. www.gigaipc.com...
  • Page 27: Safety And Regulatory Information

    At the end of its serviceable life, this product should not be treated as household or general waste. It should be handed over to the applicable collection point for the recycling of electrical and electronic equipment, or returned to the supplier for disposal. www.gigaipc.com...
  • Page 28: Chapter 3 - Motherboard Pin Define

    Chapter 3 Chapter 3 – Motherboard Pin Define www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 29: Jumpers And Connectors

    Jumpers and Connectors www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 30 M.2 Slot, E-key, NGFF 2230 PWR_BTN Power button with LED HDMI3 HDMI connector RJ45_COM Serial Port (RS-232)(RJ45 type) USB3_2 USB 3.2 Gen 1 Connector www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 31: Fan (Fan Connector)

    3.2.1 FAN (FAN connector) Pin 1 FAN Connector Connector PN Vendor 85205-0470N A1250WV-S-04PC JOINT-TECH Definition Pin No www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 32: Dc_In (Dc Jack Connector)

    3.2.2 DC_IN (DC Jack connector) DC_IN Connector Connector PN Vendor WTJ-020-88JSB KYOYAKU www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 33: Hdmi1, Hdmi2 (Hdmi Connector)

    HDMI Connector Connector PN Vendor 1165-2CG04-24P TCONN Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p TX1n TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 34: Usb3_1 (Usb 3.2 Gen 1 Connector)

    USB3_1 (USB 3.2 Gen 1 connector) USB 3.2 Gen 1 connector Connector PN Vendor UEA1141-R23L12-7H FOXCONN Definition Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 35: Lan1, Lan2 (Lan Connector)

    1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Pin No. Definition Pin No. Definition P1_MDI2+ P1_MDI0+ P1_MDI2- P1_MDI0- P1_MDI3+ P1_MDI1+ P1_MDI3- P1_MDI1- www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 36: Hp (Headphone Jack)

    3.2.6 HP (Headphone Jack) 3.2.7 SODIMMA1, SODIMMB1 (DDR4 SO-DIMM Slot) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 37: Battery1 (Battery Cable Connector)

    3.2.8 BATTERY1 (Battery cable connector) Pin 1 Battery Cable Connector Connector PN Vendor 85205-0270L ACES A1250WV-S-02PC JOINT-TECH Pin No. Definition 3.3V www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 38: M2B (M.2 Slot, B-Key, Ngff 3042)

    Pin No. Definition Pin No. Definition GPP_RESET M2B_DET M2B_DRP 3.3V WWAN_ 3.3V Disable2 M2B_CFG2 3.3V USB3 RXn USB3_RXp SIM_RST# Connector PN Vendor SIM_CLK 80149-8521 BELLWETHER www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 39: M2M (M.2 Slot, M-Key, Ngff 2280)

    M2_LED CLK_p 3.3V 3.3V Pin No. Definition Pin No. Definition 3.3V SUSCLK 3.3V PEDET 3.3V 3.3V 3.3V Connector PN Vendor PCIE9_RXn 80159-8521 BELLWETHER PCIE9_RXp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 40: M2E (M.2 Slot, E-Key, Ngff 2230)

    SUSCLK 3.3V PCIE_CLKREQ PERST# USBp 3.3V PCIE_WAKE BT_Disable# USBn WIFI_Disable# 3.3V 3.3V Pin No. Definition Pin No. Definition Connector PN Vendor APCI0076-P001A LOTES PCIE_TXp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 41: Pwr_Btn (Power Button With Led)

    3.2.12 PWR_BTN (Power button with LED) www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 42: Hdmi3 (Hdmi Connector)

    HDMI Connector Connector PN Vendor 1165-2CG04-24P TCONN Pin No. Definition Pin No. Definition TX2p CLKn TX2n TX1p TX1n TX0p Hot Plug TX0n Detect CLKp www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 43: Rj45_Com (Serial Port (Rs-232)(Rj45 Type))

    3.2.14 RJ45_COM (Serial Port (RS-232)(RJ45 type)) RJ45-COM connector Pin No. Definition www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 44: Usb3_2 (Usb 3.2 Gen 1 Connector)

    3.2.15 USB3_2 (USB 3.2 Gen 1 connector) USB 3.2 Gen 1 connector Connector PN Vendor UEA1141-R23L12-7H FOXCONN Definition Definition USB3_RX1n USB3_RX2n USB3_RX1p USB3_RX2p USB3_TX1n USB3_TX2n USB3_TX1p USB3_TX2p www.gigaipc.com GIGAIPC reserves the right to modify or revise the content at anytime without prior notice.
  • Page 45: Chapter 4 - Bios

    Chapter 4 Chapter 4 – BIOS www.gigaipc.com...
  • Page 46: Introduction

    Execute command or enter the submenu Increase the numeric value or make + changes Decrease the numeric value or make – changes General Help Previous Values Load Optimized Defaults Settings Save changes & Exit the BIOS Setup program Exit the BIOS Setup program www.gigaipc.com...
  • Page 47: The Main Menu

    ME FW version Shows ME firmware version Set the Date for the system System Date (Format : Week - Month - Day - Year) Set the time for the system System Time (Format : Hour - Minute - Second) www.gigaipc.com...
  • Page 48: Advanced

    Advanced The Advanced menu is to configure the functions of hardware settings through submenu. Use arrow keys to move among the items, and press <Enter> to access into the related submenu. www.gigaipc.com...
  • Page 49: Tpm Configuration

    4.3.1 TPM Configuration Use TPM Configuration submenu to choose TPM interface. Item Description TPM Device PTT (Default setting) Selection www.gigaipc.com...
  • Page 50 Item Description Security Device Enabled : Enables TPM feature (Default setting) support Disabled : Disables TPM feature None : No execution will be conducted (Default setting) Pending operation TPM clear : Set to clear data on TPM www.gigaipc.com...
  • Page 51: S5 Rtc Wake Settings

    Enable or Disable System to wake on a specific time. Wake system Disabled : Disables system to wake on a specific time (Default setting) from S5 Fixed Time : Enables system to wake on a specific time (Format : hr : min : sec) www.gigaipc.com...
  • Page 52: Cpu Configuration

    CPU C-states Enabled : Enables C states (Default setting) Disabled : Disables C states CPU will adjust frequency depends on it's loading. CPU P-states Enabled : Enables CPU P states function (Default setting) Disabled : Disables CPU P states function www.gigaipc.com...
  • Page 53: Sata Configuration

    4.3.4 SATA Configuration Item Description SATA Mode AHCI : Configures the SATA controllers to AHCI mode. (Default setting) Selection M.2 Port shows M.2 SATA interface SSD information www.gigaipc.com...
  • Page 54: Super Io Configuration

    Serial Port 1 Enabled : Enables allows you to configure the serial port settings Configuration Disabled : if Disabled, displays no configuration for the serial port Device settings : Display the specified Serial Port base I/O address and IRQ www.gigaipc.com...
  • Page 55: Hardware Monitor

    4.3.6 Hardware Monitor Item Description CPU temperature Shows current CPU temperature System temperature Shows current system temperature www.gigaipc.com...
  • Page 56: Network Stack Configuration

    When Network stack is enabled : Ipv4 PXE Support Disabled : Disables Ipv4 PXE Support Enabled : Enables Ipv4 PXE Support When Network stack is enabled : Ipv6 PXE Support Disabled : Disables Ipv6 PXE Support Enabled : Enables Ipv6 PXE Support www.gigaipc.com...
  • Page 57: Nvme Configuration

    4.3.8 NVMe Configuration NVMe Configuration shows information when your M.2 NVMe PCIe SSD is installed. www.gigaipc.com...
  • Page 58: Offboard Sata Controller Configuration

    4.3.9 Offboard SATA Controller Configuration www.gigaipc.com...
  • Page 59: Chipset

    Enable/Disable Watchdog Timer function Watchdog Timer Enabled : Enables Watchdog Timer function Disabled : Disabled Watchdog Timer function (Default setting) Enable/Disable BIOS Lock function BIOS Lock Enabled : Enables BIOS Lock function (Default setting) Disabled : Disabled BIOS Lock funtion www.gigaipc.com...
  • Page 60: Security

    To set up Administrator's password Administrator Minimum length : 3 Password Maximum length : 20 To set up User's password User Password Minimum length : 3 Maximum length : 20 Secure Boot Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 61 No : Cancel to restore factory settings Reset To Setup Yes : Agree to setup mode Mode No : Cancel to setup mode Enables expert users to modify Secure boot policy variables without full Key Management authentication Press <Enter> to configure the advanced items www.gigaipc.com...
  • Page 62 'UEFI CA' from database from DB No : Cancel to remove 'UEFI CA' from database Restore DB variables to fac tor y Restore DB defaults defaults Yes : Agree to restore DB defaults No : Cancel to restore DB defaults www.gigaipc.com...
  • Page 63: Boot

    Enabled : Enables Full screen LOGO Show on POST screen LOGO Show Disabled : Disables Full screen LOGO Show on POST screen (Default setting) Shows the information of the storage that be installed in the system Boot Option #1 Choose/set the boot priority www.gigaipc.com...
  • Page 64: Save & Exit

    Yes : Agree to load optimized defaults No : Cancel to load optimized defaults Enable/Disable Me FW image re-flash function Me FW Image Enabled : Enables Me FW image re-flash function Re-Flash Disabled : Disables Me FW image re-flash function (Default setting) www.gigaipc.com...
