Summary of Contents for Hebasto ThermoCall TC4
- Page 1 Operating Instructions ThermoCall TC4 Entry / Advanced...
-
Page 2: Table Of Contents
Table of Contents About This Document ......... 1 General Information . -
Page 3: About This Document
Dear Webasto customer, Thank you for purchasing the new ThermoCall TC4. This product provides you with a convenient, innovative way to operate your Webasto parking heater. About This Document These operating instructions supplement the explanations of the Webasto workshop or service centre carrying out the installation and the installation instructions and summarise the functions of the ThermoCall TC4 again. -
Page 4: Use
With the ThermoCall TC4 you can switch your parking heater on and off no matter how far away you are. ThermoCall TC4 is operated by SMS, a call from a landline/ mobile network or with the ThermoCall app. Essentially, any mobile and landline telephone can be used as the operating unit. -
Page 5: Operation And Programming
Operation and Programming After entering the authorised phone numbers (Entry: up to 5, Advanced: up to 15 phone numbers), the ThermoCall TC4 can be operated immediately with the factory settings. For details on programming the phone numbers, please see the following list of possible text message commands. -
Page 6: Overview Of Functions Advanced
The respective operating mode is ended. The indicator lamp on the button shows Standby mode. If the ThermoCall TC4 is called from a phone number that is not stored, the GSM module will terminate the connection without feedback. The respective heater... -
Page 7: Operating With Push Button
Operating with push button The ThermoCall TC4 comes with a push button with integrated indicator lamp that is installed in a clearly visible position in the vehicle. The push button is used both to operate and the heater and to indicate the current operating status. -
Page 8: Operating With Text Messages
Normal Boost NOTE *: Applies to air heaters, function depending on installed variant E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting ... - Page 9 E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting START Parking heater/ventilation is switched on and WINTER the settings last selected are used. The possible settings depend on the type of heater.
- Page 10 E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting STARTXXXX:XX:X Additional START and STARTXXXX 30 min. XXXXXX:XXXXXX commands for air heaters. The availability of 21°C...
- Page 11 E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting STATUS Shows whether or not the heating or the - - - ventilation mode is active.
-
Page 12: Sms Commands For Phone Numbers And Feedback
12 SMS commands for phone numbers and feedback E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting 1234ACCLIM:XXXXX Phone number authorisation. - Page 13 E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting NOTE With the SMS command 1234ACCLIMLIST up to 3 feedbacks per SMS in groups of 5 stored phone numbers are sent from the current list via SMS.
-
Page 14: Sms Commands For Setting Heating And Ventilation Time
13 SMS commands for setting heating and ventilation time E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Program function/description Factory command setting ... -
Page 15: Additional Sms Commands For Webasto Individual Select
15 Additional SMS commands for Webasto Individual Select E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting 1234COMFORT:X Selection of Webasto Individual Select circuit. -
Page 16: Sms Commands For Access Code, Factory Settings And Firmware Version
16 SMS commands for access code, factory settings and firmware version E = ThermoCall TC4 Entry , A = ThermoCall TC4 Advanced, 1234 = Example access code, X = Numbers entered by user Text message Function/Description Factory command setting ... -
Page 17: Button Feedback And Remedies
17 Button feedback and remedies The ThermoCall TC4 was developed according to the latest state of technology and the mode of operation is extremely reliable. Malfunctions are often due to the SIM card, the network operator, poor reception or incorrect operation. Information of troubleshooting is provided in the following list. -
Page 18: Troubleshooting
No tone feedback to Phone number is not stored in ThermoCall TC4 => see list direct calling of text message commands. Not reply text message Feedback function is deactivated or prepaid credit may be is sent by ThermoCall insufficient =>... - Page 20 In multilingual versions the German language is binding. The telephone number of each country can be found in the Webasto service center leaflet or the website of the respective Webasto representative of your country. Webasto Thermo & Comfort SE Postfach 1410 82199 Gilching Germany Visitors' address:...
