Summary of Contents for Kidsauto ATV 2.0

  • Page 1 A s s e mb l y A T V 2 . 0...
  • Page 2 CHILDREN’S ELECTRONIC TOY ATV • Suitable for 3+ Years • Maximum user weight: 50 kg OWNERS MANUAL with Assembly Instructions Read and understand this entire manual before using! Please keep this manual for future reference as it contains important information. Before first time use, charge the battery for at least 8-12 hours.

  • Page 3: Specification

    About Your New Vehicle On the purchase of your new Ride-On. This ride-on car will provide your child with many miles of riding of enjoyment. To help assure you and your rider a safe ride we ask you to please read this manual carefully, and keep it for future reference.

  • Page 4: Parts List

    Parts List Q’TY (PCS) REMARK PART NAME Vehicle body Drivng wheel Normal wheel Ø12 washer Lock nut Wheel cover Spanner Handle bar Ø5 nut M5X30 machine screw Luggage carrier Ø4x16 screw Front roll bar Ø5x12 screw Rear roll bar Back rest Seat Ø10 plastic washer Split pin...

  • Page 5: Parts Diagram

    Parts Diagram...

  • Page 6: Rules For Safe Riding

    Safety PREVENT INJURIES AND DEATHS: • NEVER LEAVE CHILD UNATTENDED. ADULT DIRECT SUPERVISION IS REQUIRED. Always keep child in view when child is in vehicle. • This toy should be used with caution since skill is required to avoid falls or collisions causing injury to the user or third parties.
  • Page 7 Attach the Front Axle Hole on the front axle linkage Front bottom view • Gently turn the vehicle body upside down. 1. Fit the front axle to the vehicle body. 2. Insert the bend end of the steering column into the hole on the front axle linkage. 3.

  • Page 8: Attach The Front Wheels

    Attach the Front Wheels Front bottom view Front axle 1. Slide a Φ12 washer onto the front axle. 2. Slide a wheel onto the front axle. 3. Slide a Φ12 washer onto the front axle. 4. Tighen a lock nut to the end of the front axle with a spanner. DO NOT over tighten. 5.
  • Page 9 Attach the Rear Driving Wheels Rear bottom view Cut off the rubber band over the rear gear boxes. 1. Slide a wheel onto the rear axle. Ensure the wheel match up with the gear box. 2. Slide another Φ12 washer onto the rear axle. 3.
  • Page 10 Attach the Handle bar & Front Luggage Carrier Tools required: Long nose pliers & screwdriver. Semicircular part Turn the vehicle body over. 1. Fit the steering wheel to the end of the steering column. HINT: The handle bar is designed to fit the vehicle body only in one way.
  • Page 11 Attach the Front Roll Bar & Back Rest Front view 1. Fit the front roll bar to the vehicle body. 2. Insert the four Ø4x16 screws and tighten with a screwdriver. 3. Fit the back rest into the holes on the vehicle. 4.
  • Page 12 Attach the Rear Luggage Carrier & Rear Roll Bar Rear view 1. Turn the luggage carrier upside down. Fit the rear roll bar to the luggage carrier as shown. 2. Insert the two Ø4x16 screws and tighten with a screwdriver. 3.
  • Page 13 Connect the Power Supply & Attach the Seat Seat inside view Red vehicle connector B a t t e r 1. Plug the battery connector into the red vehicle connector as shown. 2. Fit the tabs on seat into the grooves on the vehicle. 3.
  • Page 14 Use your New Ride-on IMPORTANT! Always stop vehicle when changing the speed or direction to avoid damage the gears and motor. WITH R/C, 4WD 1. Power button: Turn the power on and off. 2. Forward-reverse switch: Changes the direction that vehicle moves from forward to reverse.
  • Page 15 Use the Remote Controller (IF EQUIPED) Brake button Forward button Right button Reverse button Left button Speed select button Speed indicator Attach the batteries of controller Lift the battery compartment door on the back of the controller and insert two AAA(LR03) batteries.
  • Page 16 Charging WARNING! ONLY AN ADULT CAN CHARGE AND RECHARGE THE BATTERY! WARNING! This product with Charging Protection: when charging, all functions will be cut off! Only an adult can charge and recharge the battery! • The POWER SWITCH must be turned in OFF position when charging. •...

  • Page 17: Troubleshooting Guide

    Troubleshooting Guide Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped Reset fuse, see <Fuse> Check that the battery connectors are firmly plugged Battery connector or wires into each other. If wires are loose around the motor are loose contact your distributor please.
  • Page 18 Maintaining • It is parents' responsibility to check main parts of the toy before using, must regularly examine for potential hazard, such as the battery, charge,cable or cord, plug, screws are fastening enclosure of other parts and that in the event of such damage, the toy must not be used until that damage had been properly removed.

  • Page 19: Disposal Of Battery

    Fuse The battery features a thermal fuse with a rest fuse that will automatically trip and cut all power to the vehicle if the motor, electric system or battery is overloaded. The fuse will reset and power will be restored after the unit is turned OFF for 20 seconds and then turned ON again.
