Redball 680 Parts And Operator's Manual

High clearance sprayer
Hide thumbs
Table of Contents

Advertisement

Quick Links

680 High Clearance
Sprayer
Parts and Operator's
Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 680 and is the answer not in the manual?

Questions and answers

Summary of Contents for Redball 680

  • Page 1 680 High Clearance Sprayer Parts and Operator’s Manual...
  • Page 2 Abuse or modifications to the sprayer that change the performance other than original factory specifications void the warranty. Redball, LLC reserves the right to make product improvements to the equipment at any time. It shall not be obligated to make such changes to machines already in service.

  • Page 3: Table Of Contents

    680 High Clearance Sprayer Table of Contents TABLE OF CONTENTS Safety Instructions Section A Safety First Safety Instructions for Operation Safety Decal Placement Operation Instructions Section B Inspect Unit System Overview Hitch Liquid Tanks & Cradle Frame Sprayboom, Hoods, & Nozzles Liquid Pumping &...
  • Page 4 680 High Clearance Sprayer Table of Contents TABLE OF CONTENTS Connection & Startup Section C Connection Hitch Visual Inspection Axles Fixed Axles Adjustable Row Crop Width Axles Tire Weight Capacities Hydraulics Tractor System Pressure Hydraulically Driven Pumps Centrifugal Pump Diaphragm Pump...
  • Page 5 680 High Clearance Sprayer - Safety Instructions Section A 11-01...

  • Page 6: Safety First

    680 High Clearance Sprayer - Safety Instructions Section A Safety First Accidents can be prevented by recognizing the causes or hazards before an accident occurs..and doing something about them. Regardless of the care used in the design and construction of this equipment, there are some areas...

  • Page 7: Safety Instructions For Operation

    680 High Clearance Sprayer - Safety Instructions Section A Safety Instructions for Operation DO NOT ALLOW ANYONE TO OPERATE THIS REDBALL SPRAYER UNTIL HE OR SHE HAS READ THIS MANUAL AND IS COMPLETELY FAMILIAR WITH ALL SAFETY AND OPERA- TION PROCEDURES.
  • Page 8 680 High Clearance Sprayer - Safety Instructions Section A 4. People who are allergic to any of the chemicals used must never be allowed in or near the sprayer. 5. Always park the sprayer on a level surface, and lock the tractor brakes,or block the tires, before making adjustments or repairs.
  • Page 9 680 High Clearance Sprayer - Safety Instructions Section A 11. Do not replace components or parts with those ® other than genuine Redball Factory Service Parts. To do so may reduce the effectiveness of safety features or decrease the accuracy of the unit.
  • Page 10 680 High Clearance Sprayer - Safety Instructions Section A ® SAFETY DECALS ON A REDBALL 680 HIGH CLEARANCE SPRAYER P/N 004773 P/N 004774 P/N 004776 P/N 004772 P/N 004775 CAUTION DO NOT open the lid of the eductor while in operation as splashing of chemical may occur.

  • Page 11: Safety Decal Placement

    680 High Clearance Sprayer - Safety Instructions Section A SAFETY DECAL PLACEMENT REF-006068A 11-01 Section A...
  • Page 12 680 High Clearance Sprayer - Safety Instructions Section A NOTES: 11-01 Section A...
  • Page 13 680 High Clearance Sprayer - Operation Instructions Section B 11-01...

  • Page 14: Inspect Unit

    680 High Clearance Sprayer - Operation Instructions Section B Inspect Unit Check machine thoroughly for screws, bolts, fittings, IMPORTANT etc., which may have come lose during transport or operation. System Overview ® The Redball sprayer is comprised of the following subsystems: •...
  • Page 15 680 High Clearance Sprayer - Operation Instructions Section B Hitch Verify hitch is correctly attached to the tractor. See Section C for connection procedures. Liquid Tanks & Cradle Frame A structural steel cradle skid and frame weldment sup- ports the polyethylene solution and clean water rinse Pintle &...

  • Page 16: Hydraulically Driven Centrifugal Pump3

    680 High Clearance Sprayer - Operation Instructions Section B Liquid Pumping & Plumbing The liquid system begins with a suction line supplying a pump. This pump is powered via tractor hydraulics, and provides flow to the sprayer. The pump and plumbing...
  • Page 17 680 High Clearance Sprayer - Operation Instructions Section B There are two basic rules to follow when operating a hydrauli- cally driven centrifugal pump: IMPORTANT 1. Never run the pump in a “Non-Flooded” condition. 2. Always have the correct oil flow to the pump motor.

  • Page 18: Fill Solution Tank

    680 High Clearance Sprayer - Operation Instructions Section B Fill Solution Tank Loading of the solution tank is accomplished without the use of the trailer sprayer pump via the following steps. 1. Close all valves. 2. Remove solution quick fill cap & connect load hose.

  • Page 19: Utilizing Eductor (Optional)

    680 High Clearance Sprayer - Operation Instructions Section B Eductor Lid Fill Solution Tank, Utilizing Eductor (Optional): Loading of the solution tank, using the optional eductor, is accomplished via the following steps: 1. Close all valves. 2. Remove solution quick fill cap & connect load hose.

  • Page 20: Rinse Eductor While Filling

    680 High Clearance Sprayer - Operation Instructions Section B Only you, the operator can determine the length of time IMPORTANT required to completely rinse all chemical residue from the sprayer tanks and plumbing systems. Rinse Eductor While Filling: a. Open the clean water rinse valve.

  • Page 21: Fill Clean Water Rinse Tank

    680 High Clearance Sprayer - Operation Instructions Section B Fill Solution Tank, With Tank Agitation: Loading of the solution tank, using tank agitation, is accomplished via the following steps: 1. Close all valves. Agitation 2. Remove solution quick fill cap & connect load hose.

  • Page 22: Rinse Agitation System

    680 High Clearance Sprayer - Operation Instructions Section B Rinse Agitation System Rinsing the agitation plumbing is achieved via the following steps: Only you, the operator can determine the length of time IMPORTANT required to completely rinse all chemical residue from the sprayer tanks and plumbing systems.

  • Page 23: Rinse Sprayboom Plumbing

    680 High Clearance Sprayer - Operation Instructions Section B The number of times the tank must be rinsed is dependent on the chemical present in the solution tank. Only you, the opera- IMPORTANT tor can determine the number of rinsing required to thoroughly clean all chemical residue from the sprayer tanks and plumbing systems.

  • Page 24: Spraying

    680 High Clearance Sprayer - Operation Instructions Section B Spraying Bypass Valve TeeJet ® System Only Spraying is accomplished via the following steps: Closed Position 1. Close all valves. 2. Open the solution tank valve and the solution tank main valve.

  • Page 25: Spraying With Agitation

    680 High Clearance Sprayer - Operation Instructions Section B Spraying with Agitation: Certain chemicals require con- tinuous agitation. If agitation is required during spraying, open the agitation valve provided. If severe foaming of Agitation your chemical is occurring, check the chemical label or...

  • Page 26: Sprayboom Folding Out

    680 High Clearance Sprayer - Operation Instructions Section B Remove the cylinder lock prior to operation. Operating the IMPORTANT boom with the cylinder lock in place may cause damage to the Henschen Suspension. U-Bracket Solution Tank Sprayboom Folding Out - Operation:...

  • Page 27: Sprayboom Folding In

    680 High Clearance Sprayer - Operation Instructions Section B U-Bracket Solution Tank Sprayboom Folding In - Operation: Folding the boom into the cradle position requires the following steps: 1. Raise the entire boom up to the maximum height using the parallel up/down switch.

  • Page 28: Solution Spray Control System

    680 High Clearance Sprayer - Operation Instructions Section B Solution Spray Control System See the controller manufacturer’s manual for operation instructions. Light and Marking System The light system on the sprayer works with the tractor’s light sytem. Amber lights flash in unison with the tractor amber flashing lights.
  • Page 29 680 High Clearance Sprayer - Connection & Startup Section C 11-01...

  • Page 30: Connection

    680 High Clearance Sprayer - Connection & Startup Section C CONNECTION Hitch Redball provides two types of hitches: a pintle and cle- ® vis and a 2-point attachment type. Adjust Pintle Hitch so sprayer is level when connected to Safety tractor drawbar.

  • Page 31: Axles

    680 High Clearance Sprayer - Connection & Startup Section C Axles Axle Fixed Row Crop Width Axles ® The Redball Model 680 High Clearance Sprayer has an option of fixed axles. These axles are ordered at a pre- set width and are not adjustable.

  • Page 32: Tire Weight Capacities

    680 High Clearance Sprayer - Connection & Startup Section C Tire Weight Capacities - 25 MPH Use this chart as a guide to determine the maximum amount of various solutions your NOTE sprayer tires are rated for. 8 MPH is the service or field speed for this sprayer. 25 MPH is used here to demonstrate a speed used to transport the sprayer, NOT as a service or field speed.
  • Page 33 680 High Clearance Sprayer - Connection & Startup Section C Tire Weight Capacities - 8 MPH Use this chart as a guide to determine the maximum amount NOTE of various solutions your sprayer tires are rated for. Maximum Solution Tank Capacity in Gallons at 8 MPH with 320/85 x R38 Size Tires...

  • Page 34: Hydraulics

    680 High Clearance Sprayer - Connection & Startup Section C Hydraulics Hydraulic quick couplers should be coupled to the trac- tor. Make certain to correctly connect the pressure and return line hoses to the tractor, the hydraulically driven centrifugal pump and the fold cylinders. See the Pump Manufacturer’s recommendations for settings on...

  • Page 35: Directional Stack Hydraulic Boom Function Controller

    680 High Clearance Sprayer - Connection & Startup Section C Hydraulically Driven Centrifugal Pump: Refer to the manufacturer's recommendations to set the hydraulic oil flow from the tractor to the hydraulic motor driving the centrifugal pump. Make sure the hydraulic flow from your tractor does not exceed these specifications caus- ing the pump to "over speed".
  • Page 36 680 High Clearance Sprayer - Connection & Startup Section C All paths for the hydraulic oil are blocked allowing no hydraulic flow increasing pressure in the system until the Power Connections pressure reaches a limit where the hydraulic system in the tractor stops the flow to the manifold.

  • Page 37: Solution Spray Control System

    680 High Clearance Sprayer - Connection & Startup Section C Solution Spray Control System The solution spray control console should be installed in the cab, and the wire harness routed to the back of the Directional Stack Controller Brackets tractor per installation instructions provided by the control manufacturer.

  • Page 38: Boom Adjustment

    680 High Clearance Sprayer - Connection & Startup Section C Boom Adjustment Center Section Springs Redball ® assembles the center section springs so the compression length is the same from the center tab on Center Tab Boom Center Section both sides. Generally no further adjustment is needed.
  • Page 39 680 High Clearance Sprayer - Storage Section D 11-01...
  • Page 40 680 High Clearance Sprayer - Storage Section D When storing the sprayer for longer periods of time, the following procedures must be followed to lessen the chance of rust and corrosion on the unit. It maybe easier to perform functions 1 - 5 while the unit is connected to the tractor this will allow for pumping and spray flushing power.
  • Page 41 680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E 11-01...

  • Page 42: Liquid Tank, Frame And Plumbing

    680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E IMPORTANT Proper maintenance of the Sprayer and the tractor is critical for peak performance, reliability and accuracy of this system. The following is a guideline of the type of maintenance and servicing that should be performed on this unit.

  • Page 43: Hydraulics

    680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E Hydraulics 1. Inspect cylinder shafts for corrosion or damage. Repair or replace shaft to avoid hydraulic leaks or cylinder failure. 2. Inspect hydraulic hoses. Replace any hose that shows signs of wear or damage.

  • Page 44: Lubrication

    680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E Lubrication Apply grease to all grease zerks daily when in use (more often if sprayer is utilized in severe conditions). Grease zerks are located at: • Top & bottom at the wing attach point (Item 1 ) •...

  • Page 45: Wheel Lug Nut Torque

    680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E Wheel Lug Nut Torque When receiving your sprayer or replacing a tire, follow these steps for insuring proper lug-nut torque: Failure to check and maintain the proper lug nut torque could result in elongation of rim and/or broken lug-bolts.

  • Page 46: Bolt Torque Data

    680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E BOLT TORQUE DATA The chart provided contains information concerning stan- dard hardware used on this machine. It is recommended that all fasteners be tightened to the torque values speci- fied.The grade of the bolt is identified by the markings on...

  • Page 47: Troubleshooting

    680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E TROUBLESHOOTING Hydraulic System The word “System” donates hydraulic pump, motor, plus all lines, valves, filters, controls, etc., leading to and between lines. SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION Hydraulic system...
  • Page 48 680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION Hydraulic System noisy Hydraulic fluid too viscous If very cold, let unit idle (Continued) or too cold stand at idle until it warms Inlet line to auxiliary...
  • Page 49 680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E Liquid System SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION Poor spray pattern Nozzles too large See Nozzle Supplier - Nozzles Dribble Strainer Clogged Clean Strainer - Spray atomizing Nozzle too small See Nozzle Supplier &...
  • Page 50 680 High Clearance Sprayer - Maintenance, Service & Troubleshooting Section E SYMPTOM PROBABLE CAUSE CORRECTIVE ACTION Boom movement without Cartridge valve not closed a. Clean cartridge valve boom function switch body to remove conta- movement mination preventing valve from closing completely.
  • Page 51 680 High Clearance Sprayer - Parts & Schematics Section F 11-01...
  • Page 52 680 High Clearance Sprayer - Parts & Schematics Section F Description: Decal Placement 11-01 Section F Ref-006068A...
  • Page 53 680 High Clearance Sprayer - Parts & Schematics Section F Description: Decal Placement Item# Part # Description Quantity 004641 Decal, 750 Gal. Sight Gauge 004796 Decal, 1000 Gal. Sight Gauge 004145 Decal, 1350 Gal. Sight Gauge 006215 Decal, 1600 Gal. Sight Gauge...
  • Page 54 680 High Clearance Sprayer - Parts & Schematics Section F Description: Complete Frame 11-01 Ref-006265B Section F...
  • Page 55 680 High Clearance Sprayer - Parts & Schematics Section F Description: Complete Frame Item# Part # Description Quantity 004000 Frame, 750 Gal. Weld 004100 Frame, 1000 Gal. Weld 004125 Frame, 1350-1600 Gal. Weld 004065 Plate, L.H. Cover 004066 Plate, R.H. Cover...
  • Page 56 680 High Clearance Sprayer - Parts & Schematics Section F Description: Complete Frame Item# Part # Description Quantity BM-10/24-050 Bolt, Mach. 10/24 x 1/2 PH-Pan BU031-100-175-2 U-Bolt, 5/16 x 1 x 1 3/4 Gr. 2 Sq. BU038-200-300-2 U-Bolt, 3/8 x 2 x 3 Gr. 2 Sq.
  • Page 57 680 High Clearance Sprayer - Parts & Schematics Section F This Page Was Intentionally Left Open 11-01 Section F...
  • Page 58 680 High Clearance Sprayer - Parts & Schematics Section F Description: Drawbar Assembly 11-01 Ref-006264B Section F...
  • Page 59 680 High Clearance Sprayer - Parts & Schematics Section F Description: Drawbar Assembly Item# Part # Description Quantity 004150* Hitch, Weld (750 Frame Only) 004870* HItch, Weld (1350 All., 1000/40-60’) 006025* Hitch, Weld (1600 Frame Only) 006037* Hitch, Weld (1000 Frame/90’ Only) 004582* Drawbar, 2-Pt.
  • Page 60 680 High Clearance Sprayer - Parts & Schematics Section F Description: Sight Gauge and Tank Support Assembly Ref-007479 11-01 Section F...
  • Page 61 680 High Clearance Sprayer - Parts & Schematics Section F Description: Sight Gauge and Tank Support Assembly Item# Part # Description Quantity NW60401 Bulkhead Fitting 3/4” HB-075-90 Hose Barb El, 3/4 MPT x HB Poly #12J Clamp, 3/4” Stainless Clamp SIGHT-34 Hose, 3/4”...
  • Page 62 680 High Clearance Sprayer - Parts & Schematics Section F This Page Was Intentionally Left Open 11-01 Section F...
  • Page 63 680 High Clearance Sprayer - Parts & Schematics Section F Description: Boom Sections 11-01 Ref-007621C Section F...
  • Page 64 680 High Clearance Sprayer - Parts & Schematics Section F Description: Complete Boom Break Down Direction of Travel Item# Part # Description Quantity 004860 Bracket, Nozzle Mount 004861 Tube, Mount Nozzle 15’ 004862 Tube, Mount Nozzle 5’ 004863 Tube, Mount Nozzle 10’...
  • Page 65 680 High Clearance Sprayer - Parts & Schematics Section F Description: Complete Boom Break Down Item# Part # Description Quantity 19349-211-785NY Hose Shank 3/4 HB, EL Diaph QJ363-750-1-NYB Turret, 3 - Outlet, 3/4 Tee QJ365-750-1-NYB Nozzle Body Mult, W/L Hose S LN-031-NI Lock Nut, 5/16”...
  • Page 66 680 High Clearance Sprayer - Parts & Schematics Section F Description: Complete Center Section Break Down 11-01 Ref-006262B Section F...
  • Page 67 680 High Clearance Sprayer - Parts & Schematics Section F Description: Complete Center Section Break Down Item# Part # Description Quantity 001662 Slide, Nylitron Wear 001717 Spring, Compression 93240 Spring, Compression (used on 100’) 004385 Mount, Center Weld 004404 Rod, Threaded End...
  • Page 68 680 High Clearance Sprayer - Parts & Schematics Section F Description: Cradle Assembly 11-01 Ref-006263B Section F...
  • Page 69 680 High Clearance Sprayer - Parts & Schematics Section F Description: Cradle Assembly Item# Part # Description Quantity PCT-012-150 Pin, Cotter 1/8 x 1 1/2 LN-038-NI Locknut, 3/8” Nylon Insert LN-050-NI Locknut, 1/2” Nylon Insert 004800 Weld, Cradle Pin 2...
  • Page 70 680 High Clearance Sprayer - Parts & Schematics Section F Description: Light Kit Assembly 11-01 Ref-006389A Section F...
  • Page 71 680 High Clearance Sprayer - Parts & Schematics Section F Description: Light Kit Assembly Item# Part # Description Quantity 001186 Bracket, Light Mounting 006978 Turn Signal Module II 007179 Harness; 20’ Tractor/Implement 007183 Harness; Light (Trailer Units) 004560 Light, Red Light...
  • Page 72 680 High Clearance Sprayer - Parts & Schematics Section F Description: TeeJet ® 844 Controller, TeeJet ® Valves (Optional) Item# Part # Description Quantity #16J Clamp, 1” Stainless 004556 Mount, 2 1/2” Valve 011612 Hose, 1” 150# Black Rubber 150G Gasket, 2”...
  • Page 73 680 High Clearance Sprayer - Parts & Schematics Section F Description: TeeJet ® 844 Controller, TeeJet ® Valves (Optional) Item# Part # Description Quantity 38550-344AE2RL1 Valve, Regulating Valve Asb 1” 39000 Cable Seal, Green 45988-1 Cable; Signal; Valve End 90-50143 844-F Kit;...
  • Page 74 680 High Clearance Sprayer - Parts & Schematics Section F Description: TeeJet ® 844 Controller, Banjo ® Valves (Optional) Item# Part # Description Quantity #16J Clamp, 1” Stainless 004556 Mount, 2 1/2” Valve 011612 Hose, 1” 150# Black Rubber 150G Gasket, 2”...
  • Page 75 680 High Clearance Sprayer - Parts & Schematics Section F Description: TeeJet ® 844 Controller, Banjo ® Valves (Optional) Item# Part # Description Quantity 90-50143 844-E Core Kit, Console, Manual, Mt Brket 48348 TeeJet 844-E; Console Only 004114 Plate Strainer Bracket...
  • Page 76 680 High Clearance Sprayer - Parts & Schematics Section F ® ® Description: Raven Controller, TeeJet Valves (Optional) Item# Part # Description Quantity #16J Clamp, 1” Stainless #20J Clamp, 1 1/4” Stainless 004108 Plate, Flow Meter2 004114 Mount, Flow Meter 007659 Bracket, Reg.
  • Page 77 680 High Clearance Sprayer - Parts & Schematics Section F Description: Raven ® Controller, TeeJet ® Valves (Optional) Item# Part # Description Quantity 150G Gasket, 2” Flanged Valves 30035 Connector, Terminal 18 Ga. Male 38045 Connector, Body Shroud 3 Pin...
  • Page 78 680 High Clearance Sprayer - Parts & Schematics Section F Description: Raven ® Controller w/Banjo ® Valves (Optional) Item# Part # Description Quantity #16J Clamp, 1” Stainless #20J Clamp, 1 1/4” Stainless 004108 Plate, Flow Meter2 004114 Mount, Flow Meter...
  • Page 79 680 High Clearance Sprayer - Parts & Schematics Section F Description: Raven ® Controller w/Banjo ® Valves (Optional) Item# Part # Description Quantity 011612 Hose, 1” 150# Black Rubber 012012 Hose, 1 1/4” 150# Black Rubber 150G Gasket, 2” Flanged Valves 30035 Connector, Terminal 18 Ga.
  • Page 80 680 High Clearance Sprayer - Parts & Schematics Section F Description: Plumbing using the Hydraulically Driven Centrifugal Pump Section F 11-01 Ref-006252B...
  • Page 81 680 High Clearance Sprayer - Parts & Schematics Section F Description: Plumbing using the Hydraulically Driven Centrifugal Pump Item# Part # Description Quantity #16J Clamp, 1” Stainless #20J Clamp, 1 1/4” Stainless #36J Clamp, 2” Stainless 011612 Hose, 1” 150# Black Rubber 012012 Hose, 1 1/4”...
  • Page 82 680 High Clearance Sprayer - Parts & Schematics Section F Description: 680 Centrifugal Plumbing w/Flanged Fittings Item# Part # Description Quantity NW60401 Bulkhead Fitting 3/4” NW60427 Bulkhead Fitting 1” RB100-075 Reducer Bushing, 1 x 3/4 Poly RN100-075 Reducer Nipple, 1MPT x 3/4MPT TEE 100 Tee, Poly, 1”...
  • Page 83 680 High Clearance Sprayer - Parts & Schematics Section F This Page Was Intentionally Left Open 11-01 Section F...
  • Page 84 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulically Driven Centrifugal Pump Assembly 11-01 Ref-006254A Section F...
  • Page 85 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulically Driven Centrifugal Pump Assembly Item# Part # Description 9303C-HM4 9303C-HM1 9304C-HM1 9306C-HM1C 9306C-HM1C 004656 Hyd. Hose, 180” 8FJX x 8 MB 006213 Mount, Pump Frame 150G Gasket, For 2” Flanged Valve 200G Gasket, For 2"...
  • Page 86 680 High Clearance Sprayer - Parts & Schematics Section F Description: Plumbing using the Hydraulically Driven Diaphragm Pump 11-01 Ref-006255A Section F...
  • Page 87 680 High Clearance Sprayer - Parts & Schematics Section F Description: Plumbing using the Hydraulically Driven Diaphragm Pump Item# Part # Description Quantity M220MPT 2” Manifold x 2” Full Port #16J Clamp, 1” Stainless Clamp #20J Clamp, 1 1/4” Stainless Clamp #36J Clamp, 2”...
  • Page 88 680 High Clearance Sprayer - Parts & Schematics Section F Description: Plumbing using the Hydraulically Driven Diaphragm Pump Item# Part # Description Quantity V-204FP Valve, 2” 4 Bolted Ball Valve V-200 Valve, 2” Bolted Ball Valve MV100CF Valve, 1” Flanged Valve M100G Gasket, For 1”...
  • Page 89 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulically Driven Diaphragm Pump Assembly, Hydraulic Components Breakdown Be sure Check Valve, Item 8, goes into Port A. IMPORTANT Pressure compensated flow control, Item 3, is factory set at 10 GPM.
  • Page 90 680 High Clearance Sprayer - Parts & Schematics Section F Description: Eductor Kit Assembly (Optional) Item# Part # Description Quantity #16J Clamp, 1” Stainless #20J Clamp, 1 1/4” Stainless #36J Clamp, 2” Stainless 004556 Mount, 2 1/2” Valve 004769 Decal, Eductor Rinse...
  • Page 91 680 High Clearance Sprayer - Parts & Schematics Section F Description: Eductor Kit Assembly (Optional) Item# Part # Description Quantity FW-031 Flatwasher, 5/16 HB-075-100-90 Hose Barb Ell, 3/4MPT x 1 HB ELL HB-125 Hose Barb, 1 1/4” MPT x HB, Poly HB-125-90 Hose Barb Ell., 1 1/4 MPT x HB ELL...
  • Page 92 680 High Clearance Sprayer - Parts & Schematics Section F Description: Inline Strainer Mounting Kit (Optional) Item# Part # Description Quantity #16J Clamp; 1” Metal Clamp #36J Clamp; 2 1/4” Metal Clamp 006987 Plate; Strainer Mount BU031-200-275 U-Bolt; 5/16 x 2 x 2 3/4 Sq.
  • Page 93 680 High Clearance Sprayer - Parts & Schematics Section F Description: Electric Fillmeter Kit (Optional) Item# Part # Description Quantity 200A Coupling; 2” Male ADPT/FPT 200CAP Coupling; 2” Female CAM Lever CAP 200D Coupling; 2” Female CAM Lever/FP 200PL Coupling; 2” Plug FT200 Fillmeter;...
  • Page 94 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulic Boom Control Routing Hoses conducting oil to extend the cylinder connect to the IMPORTANT top solenoid ports. Hoses conducting oil to retract the cylinder connect to the bottom solenoid ports.
  • Page 95 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulic Boom Control Routing Item# Part # Description Quantity 6400-6-8 Hyd. Adapter, 3/8JIC & 3/4ORB Male 8010-15P Hyd. Quick Coupler, Univ. Poppet K256 2” x 20” Welded Cylinder 645215 3”...
  • Page 96 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulic Valve Breakdown Notes: 1. Torque Items 9, 11, & 12 to 20 Ft Lbs. 2. Torque Item 6, 7, 8 & 10 to 25 Ft Lbs. 3. Torque Item 1 & 2 to 13 Ft. Lbs.
  • Page 97 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulic Valve Breakdown Item# Part # Description Quantity 210-016 FTG 6401-6-8/E-MJ-MO 210-023 FTG 6400-6-6/S-MJ-MO 253-022 Coil 6309412 DW 253-028 Coil 6359412 DW 270-011 Block M14259-1 7CIR 273-008 Cart SV10-40-0-N-00-25...
  • Page 98 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulic Switch Box Breakdown Pin Function See Notes Notes: 1. Pin Location noted on male and female connector plug Pin Number and function 1 - Battery (-) 2 - Right Wing Down...
  • Page 99 680 High Clearance Sprayer - Parts & Schematics Section F Description: Hydraulic Switch Box Breakdown Item# Part # Description Quantity 782-1051 Fuse; 10 AMP AGC10 115-0171-211 Console Cable 46215 Fuse; 15 AMP, Spade Auto 063-0172-036 Switch Box Back 106-0159-438 Mounting Knob 107-0171-314 Mounting Bracket, Raven®...
  • Page 100 680 High Clearance Sprayer - Parts & Schematics Section F Description: Switch Box Cable Pin No & Function 1 - Battery (-) 2 - Right Wing Down 3 - Ring Wing Up 4 - Right Fold Out 5 - Right Fold In 6 - Right 180°...
  • Page 101 680 High Clearance Sprayer - Parts & Schematics Section F Description: Switch Box Cable Item# Part # Description Quantity 115-0171-212 Cable, 31’ Use w/Switch Box 38042 Connector; Body Shroud, 2 Term 39010 Plug, Dust Cover Plug Notes: 1. Pin location noted on male and female connector plug.
  • Page 102 680 High Clearance Sprayer - Parts & Schematics Section F Description: Cylinder Assembly 11-01 Ref-006270C Section F...
  • Page 103 680 High Clearance Sprayer - Parts & Schematics Section F Description: Cylinder Assembly P/N 645215 20TD12-112 P/N 645216 Wing Tilt 60’ Boom 90’ Boom Item# 180° Fold 180° Fold Description Quantity 492675 492672 492675 Clevis Cap 492670 492665 492670 Rod Cap...
  • Page 104 680 High Clearance Sprayer - Parts & Schematics Section F Description: Cylinder Assembly; P/N K256 11-01 Ref-006271B Section F...
  • Page 105 680 High Clearance Sprayer - Parts & Schematics Section F Description: Cylinder Assembly; P/N K256 Item# Part # Description Quantity 45288 Shaft; Weldment 40259 FND Gland 20296 Seal Kit 91304 Tube Weldment 98261 Ppiston 96007 3/4-16UNF Locknut 56040 Danuser Threaded Eye...
  • Page 106 680 High Clearance Sprayer - Parts & Schematics Section F Description: Parallel Cylinder Assembly 11-01 Ref-006272B Section F...
  • Page 107 680 High Clearance Sprayer - Parts & Schematics Section F Description: Parallel Cylinder Assembly Item# Quantity Description P/N 645213 P/N 645214 Nut, Hex (Tie Rod) NUT-050 NUT-050 Nut, Hex (Cyl. Rod) 130556 130560 SC Sckt Set 3/8UNC 148390 148390 Plug 3/4-16, SOC HD...
  • Page 108 680 High Clearance Sprayer - Parts & Schematics Section F Description: 8-Bolt Adjustable Axle Assembly Section F 11-01 Ref-006267D...
  • Page 109 680 High Clearance Sprayer - Parts & Schematics Section F Description: 8-Bolt Adjustable Axle Assembly Item# Part # Description Quantity 004500* Spindle Weld; Short 007392* Spindle Weld; Long 004902* Weld; Axle 62” - 80” (Single) 007388* Weld; Axle 88” - 120” (Single) 004898* Weld;...
  • Page 110 680 High Clearance Sprayer - Parts & Schematics Section F Description: 10-Bolt Adjustable Axle Assembly Item# Part # Description Quantity 007166* Spindle Weld; Short 007333* Spindle Weld; Long 006161* Weld; Axle 62”-80” (Single) 007327* Weld; Axle 80”-120” (Single) 006163* Weld; Axle 120”-152” (Single) 006222* Weld;...
  • Page 111 680 High Clearance Sprayer - Parts & Schematics Section F Description: 10-Bolt Adjustable Axle Assembly Item# Part # Description Quantity BU075-500-900-5 U-Bolt; 3/4 x 5 x 9 Gr. 5 LN-075-NI Locknut; 3/4 Nylon Insert BH-050-500-5 Bolt, 1/2” x 5” Hex. Gr. 5 LN-050-NI Locknut, 1/2”...
  • Page 112 680 High Clearance Sprayer - Parts & Schematics Section F Description: 8-Bolt Fixed Axle Assembly (5/8” Stud) 11-01 Ref-006965C Section F...
  • Page 113 680 High Clearance Sprayer - Parts & Schematics Section F Description: 8-Bolt Fixed Axle Assembly (5/8” Stud) Item# Part # Description Quantity 006944* Axle; 8-Bolt Fixed 72” 007540* Axle; 8-Bolt Fixed 76” 006943* Axle; 8-Bolt Fixed 88” 006942* Axle; 8-Bolt Fixed 120”...
  • Page 114 680 High Clearance Sprayer - Parts & Schematics Section F Description: 10-Bolt Fixed Axle Assembly (3/4” Stud) 11-01 Ref-006964B Section F...
  • Page 115 680 High Clearance Sprayer - Parts & Schematics Section F Description: 10-Bolt Fixed Axle Assembly (3/4” Stud) Item# Part # Description Quantity 006961* Axle; 10-Bolt Fixed 72” 006958* Axle; 10-Bolt Fixed 88” 006953* Axle; 10-Bolt Fixed 120” BH-075-250-5 Bolt; 3/4 x 2 1/2 Gr. 58 LN-075-NI Locknut;...
  • Page 116 680 High Clearance Sprayer - Parts & Schematics Section F NOTES: 11-01 Section F...
  • Page 117 680 High Clearance Sprayer - Warranty Section G 11-01...
  • Page 118 680 High Clearance Sprayer - Warranty Section G Serial and Model Number Location This plate is in the Model and Serial Number Plate Plumbing Enclosure The following page contains a space for you to record the information about your sprayer found on this plate.
  • Page 119 Redball, LLC within thirty (30) days of the date that such defect or improper workmanship is discovered, or should have been discovered. Parts shall be returned through the selling representative and transportation charges must be prepaid by the buyer.
  • Page 120 The Employees of ® would like to thank you for purchasing this Redball High Clearance Sprayer. We are proud of our quality and believe this product will exceed your expectations! For More Information Contact: Redball, LLC 140 30th Avenue SE...
  • Page 121 To Our Valued Redball Customer: First, we at Redball, LLC, would like to thank you for your recent purchase. In an effort to serve you better, please take a moment to warranty register your new Redball ® product. Warranty reg-...
  • Page 122 Place Stamp Here Redball, LLC 140 30th Ave SE PO Box 159 Benson, MN 56215 11-01...
