520004-520005-520017 PLUG-I Indoor WiFi plug WiFi INDOOR 2,4Ghz Available on the Available on the Free available on Free available on Google Play Google Play Garantie Garantie www.mythomson.com...
INDOOR WIFI PLUG CONTENTS A. SAFETY INSTRUCTIONS 1. OPERATING PRECAUTIONS 2. MAINTENANCE AND CLEANING 3. RECYCLING B. INSTALLATION 1. OPERATION 2. CONNECT THE SMART PLUG TO AN ELECTRICAL SOCKET 3. INSTALLING THE MOBILE APPLICATION AND CREATING AN ACCOUNT 4. PAIRING THE SMART PLUG 5.
Page 3
3. ROUTINES 4. EXAMPLE OF ROUTINES 5. USE WITH AMAZON ALEXA 6. PROGRAMMING WITH ALEXA (WITH OR WITHOUT A SMART SPEAKER) 6.1. DETECTION OF CONNECTED OBJECTS IN THE ALEXA APP 6.2. CONFIGURING A PROGRAMME 6.3. EXAMPLES OF POSSIBLE USES WITH OTHER ELEMENTS FROM THE AT HOME RANGE D.
INDOOR WIFI PLUG A - SAFETY INSTRUCTIONS 1 - OPERATING PRECAUTIONS 3 - RECYCLING • Do not allow children to operate the product. This logo denotes that devices no • This product is designed exclusively for indoor longer in use should not be disposed of use.
Once the smart plug is connected, follow the instructions below to pair it. - Download the Thomson At Home app from the Android Play Store or Apple App Store The smart plug is in pairing mode by default. If it has already been paired previously, see section 5 - Resetting the plug.
Select your 2.4 GHz Wi-Fi network (N.B., your AJOUTER UN PRODUIT smartphone must be connected to the Wi-Fi network to which the PLUG-I plug will be connected), enter your network password and press NEXT. Select the product you wish to pair and select the PLUG-I smart plug.
The LED will in your dashboard. Wait for the icons to go from flash rapidly to show that the reset was successful. grey to black (indicating that your Wi-Fi network connection was successful) You can now control your Thomson smart plug from your smartphone.
1.1. If you have an Android smartphone with Google HOME Assistant. Google Assistant can help you control your Your devices need to be paired in the Thomson At connected devices. Home app to be controlled with Google Assistant. For example, you can use the following commands: They must be connected on the same WiFi network.
1.2. If you have an Android smartphone without Google Assistant or n iPhone Your devices must be paired on the Thomson At Home app in order to be controlled with Google Assistant. They must be connected on the same WiFi network.
Page 11
INDOOR WIFI PLUG C - USAGE Click on the + button Press on the magnifying glass to carry out a search in the At Home app Press on "Configurer un appareil" (Configuring Enter At Home and click on the At Home logo a device) The Google Home app.
INDOOR WIFI PLUG C - USAGE Once your At Home account has been linked to Google Home, your accessories will appear automatically. You will be able to allocate each device to a particular room in order to find it more easily. Select the desired accessories and then click on "ASSOCIER A UNE PIECE"...
INDOOR WIFI PLUG C - USAGE To turn off the remote-controlled plug specifically second routine will need to be created with a suitable allocated to the room, say: command. - "OK Google Turn off the remote-controlled plug in the living room" To create a routine, press on Routines For a RGB DIANE lamp To turn on the DIANE lamp, say:...
INDOOR WIFI PLUG C - USAGE Then press on + "Ajouter une routine" (Add a routine) Click on "Ajouter des commandes" (Add commands). Write down the order you want to give your assistant orally to allow it to order the routine, without going through the time programming schedule.
Search at the top right-hand side a speaker. - Select the At Home Skill and activate for use - Enter the account used in the Thomson At Install the Thomson At Home skill Home app - Once the skill is correctly paired, press the On the main menu, click on cross at the top left-hand side.
Page 16
INDOOR WIFI PLUG C - USAGE then select At Home in the results. Select Activate the skill, Then you need to enter At Home in the search bar,...
INDOOR WIFI PLUG C - USAGE and enter the email address and password for your then "CONFIGURER L’APPAREIL" (CONFIGURE THE At Home account. DEVICE) The At Home skill is paired with Alexa. You can now create routines and programme them. 6.2.
Page 18
INDOOR WIFI PLUG C - USAGE You first need to select the action that will be triggered. To do this, press on "Programmer" (Programme), then "+", Then on "A", twice and finally "lorsque cela se produit" (when this happens). then set the start time for the action and click on "OK"...
Page 19
INDOOR WIFI PLUG C - USAGE Now that a condition has been added, you need to define an action, so select "Ajouter une action" (Add an action) Then select the day(s) on which the sequence should be triggered. Press on "Répéter" (Repeat), and "Maison connectée" (Smart home). and then select the desired frequency.
Page 20
INDOOR WIFI PLUG C - USAGE then on "enregistrer" (save). Indicate ON or OFF (ON in this example), and press on "suivant" (next), This example shows how to programme the turning on of a smart plug; you need to follow the same steps to programme its switching off.
Page 21
INDOOR WIFI PLUG C - USAGE set the duration of the action, then "suivant" (next) then on "Maison connectée" (Smart home). Now you only need to programme the final action in this time delay sequence. Press on "Ajouter une action" (Add an action)
INDOOR WIFI PLUG C - USAGE Select the same product, You have completed the programming. Your plug will turn on at a set time, and then turn off after operating for 1.5 hrs. You need to follow the correct order of actions. If you need to move a particular action, keep = pressed down, and move the action.
Page 23
INDOOR WIFI PLUG C - USAGE Use of a lighting kit for a gate: Automatic turning on of lights for 5 minutes after opening the gate...
INDOOR WIFI PLUG D - TECHNICAL AND LEGAL INFORMATION 1 - TECHNICAL CHARACTERISTICS the product itself, the technician will give you an RMA number so that you can return the unit to • Max. power of the controlled device: 3000W the shop.
Page 26
Avidsen 19 Avenue Marcel Dassault ZAC des Deux Lions - 37200 Tours - France www.mythomson.com...
