Summary of Contents for ElectroCom IQ3/XNC KNX
- Page 1 IQ3/XNC KNX Installation and configuration Version 1.0 15. mar. 2011 Electrocom Rødeledsvej 95 DK-5700 Svendborg Denmark Tel : +45 8880 7580 www.electrocom.dk...
- Page 2 p. 2 1. Introduction The XNC KNX provides the functionality for an IQ3 Controller to be able to communicate with a KNX network. The IQ3 Controller will be able to read 130 different KNX variables and write another 70 KNX variables. The 200 KNX variables available to the IQ3 Controller can be combined with your KNX network in the ETS3 software.
- Page 3 p. 3 2. XNC KNX Gateway The XNC KNX Gateway hardware has the following layout. 1. RJ45 connector for ethernet network with the IQ3 Controller 2. Power for the XNC KNX Gateway. 24V DC 3. Short circuit these two connectors equals KNX Program Address button press 4.
- Page 4 p. 4 2.1. XNC KNX Gateway settings There is a webpage server on the XNC KNX Gateway. It is possible to configure the several different settings. The XNC KNX Gateway is preprogrammed with a static IP of 10.0.0.149. To enter the webpage use the following link. http://10.0.0.149 The address will be different if the IP has been changed on the XNC KNX Gateway.
- Page 5 p. 5 3. XNC download The KNX XNC driver consists of two files: .xnc file – Application file ● .xnp file – Configuration file ● Quick list for the installation: 1. Download the strategy with the .xnp file 2. Download the .xnc file...
- Page 6 p. 6 3.1. Download the strategy with the .xnp file Start up SET (System Engineering Tool) and open your strategy. Right-click on the strategy with the mouse and you will get a menu popping up. In the menu choose “Device”->”XNC Interface Module”.
- Page 7 p. 7 3.2. Download the .xnc file Switch to “System View” and find the Trend Controller. Right-click on it and choose “Download IQ3/XNC Application”. This will open a new dialog where you press the “Open File” button and an open dialog will appear which is used to find the .xnc file. Now press the download button and the KNX XNC driver will be installed on the Trend Controller but still needs configuration.
- Page 8 p. 8 4. XNC KNX variables With the IQ3 Controller and XNC KNX it is possible to read or write XNC KNX variables. Here is a full list of the different variable types. XNC KNX variable Size Description Switch Can be ON (1) or OFF (0) Switch Control Like Switch but can also be deactived (0) or activated (1) Small Value...
- Page 9 p. 9 5. Supported KNX Datapoint Types In your KNX network you will have several different KNX Datapoint Types. Here is a list with all the KNX Datapoint Types supported by the XNC KNX. Each type of XNC KNX variables only support a certain amount of different KNX Datapoint Types.
- Page 10 p. 10 DPT ID DPT Name XNC KNX Variable 2.007 DPT_Step_Control Switch Control 2.008 DPT_Direction1_Control Switch Control 2.009 DPT_Direction2_Control Switch Control 2.010 DPT_Start_Control Switch Control 2.011 DPT_State_Control Switch Control 2.012 DPT_Invert_Control Switch Control 5.001 DPT_Scaling Small Value 5.003 DPT_Angle Small Value 5.004 DPT_Percent_U8 Small Value 5.005 DPT_DecimalFactor...
- Page 11 p. 11 DPT ID DPT Name XNC KNX Variable 9.008 DPT_Value_AirQuality Value Decimal 9.010 DPT_Value_Time1 Value Decimal 9.011 DPT_Value_Time2 Value Decimal 9.020 DPT_Value_Volt Value Decimal 9.021 DPT_Value_Curr Value Decimal 9.022 DPT_PowerDensity Value Decimal 9.023 DPT_KelvinPerPercent Value Decimal 9.024 DPT_Power Value Decimal 9.025 DPT_Value_Volume_Flow Value Decimal...
- Page 12 p. 12 DPT ID DPT Name XNC KNX Variable 14.025 DPT_Value_Electric_FluxDensity Big Value Decimal 14.026 DPT_Value_Electric_Polarization Big Value Decimal 14.027 DPT_Value_Electric_Potential Big Value Decimal 14.028 DPT_Value_Electric_PotentialDifference Big Value Decimal 14.029 DPT_Value_ElectromagneticMMoment Big Value Decimal 14.030 DPT_Value_Electromotive_Force Big Value Decimal 14.031 DPT_Value_Energy Big Value Decimal 14.032...
- Page 13 p. 13 DPT ID DPT Name XNC KNX Variable 14.061 DPT_Value_Resistivity Big Value Decimal 14.062 DPT_Value_SelfInductance Big Value Decimal 14.063 DPT_Value_SolidAngle Big Value Decimal 14.064 DPT_Value_SoundIntensity Big Value Decimal 14.065 DPT_Value_Speed Big Value Decimal 14.066 DPT_Value_Stress Big Value Decimal 14.067 DPT_Value_Surface_Tension Big Value Decimal 14.068...
- Page 14 p. 14 6. XNC Configuration The XNC KNX is configured in the XNC Interface Module. 1. The Stores are the configuration for the XNC KNX. Gateway_IP is the IP address of the XNC KNX Gateway 2. The XNC Inputs are the IQ3 Controller's inputs to the KNX network. XNC KNX variables will be written to the KNX network.
- Page 15 In ETS3 you start by installing software support for the XNC KNX Gateway. The ETS3 software support for the XNC KNX Gateway is a .zip file and can be downloaded from the following link: http://www.electrocom.dk/downloads/ETS3/XNC_KNX_Gateway.zip The software support is installed by doing the following in the ETS3: File →...
- Page 16 p. 16 7.1. Add and configure XNC KNX Gateway You will get the following dialog box when you add a device in ETS3. To add the XNC KNX Gateway follow these instructions: 1. Choose WAGO Kontakttechnik 2. Choose Modules 3. Choose TP1-Module 4.
- Page 17 p. 17 Now it is very important to import the configuration file before setting anything else up. 1. Press File → Import configuration... 2. Open the file XNC_KNX_Gateway_config.xml and press Yes button. The XNC KNX Gateway is now added to your KNX network and configured.
- Page 18 p. 18 7.2. Connect the XNC KNX datapoints to the KNX network You can now setup the KNX variables from the IQ3 Controller with the rest of the KNX network. 1. Find a KNX variable from the XNC KNX 2. Drag and drop the XNC KNX variable into the KNX network 3.
- Page 19 p. 19 7.3. Download KNX configuration The KNX configuration needs to be downloaded to the XNC KNX Gateway. Start by right click on the XNC KNX Gateway. Mouse right click → Download... 1. Press Program Address & Application button 2. Dialog waiting for press on the KNX Program Address button on the XNC KNX Gateway 3.
