PURLIN/CLADDING INSTALLATION
1029 MOUNTAIN HWY BORONIA VIC 3155
T +61 1300 301 755
E sales@sayfa.com.au
THIS PROPERTY REMAINS THE PROPERTY OF SAYFA GROUP AND MAY NOT BE CHANGED WITHOUT WRITTEN
PERMISSIONFOR FURTHER INFORMATION REFER TO OUR WEBSITE AT sayfa.com.au
DESCRIPTION
F +61 1300 881 092
RL429T - LADDER HEAD CANTILEVER
E sayfa.com.au
PLATFORM INSTALL DETAILS
SUPPORT BRACKET
(MAY BE CUT DOWN TO SUIT)
8 x 75mm SCREW BOLT
OR 10mm TRU-BOLT
2 PER BRACKET
CONCRETE INSTALLATION
DRG No.
DATE
D9369
28/9/2022
Code
REV
RL429T
3 (RL update)
