4.3 Pin assignment in the Ex i connection box with RS232 interface

Pin assignment in the Ex i connection box RS232:
Extronics Limited
1 Dalton Way, Midpoint 18, Middlewich, Cheshire, UK. CW10 0HU
Tel: +44 (0) 845 277 5000 Fax: +44 (0)845 277 4000 E-mail: info@extronics.com Web:
The terminal assignment is located underneath the removable cover at the
front of the power supply.
Caution! Do not open enclosure in hazardous area!
Before operating the device in a hazardous area, you have to
ensure that the enclosure has been closed fully, the flat seal is
reinstalled and all screws have been tightened.
Any changes to the wiring may only be carried out by trained
staff.
Power supply Type: iSCANPS1, 3, 5, 7
Prepared
Connection coupling
Pin Wire
3 3
2 2
1 1
Connection box
Definition Number
RxD X9
GND X10
PE X11
GND X12
+UB X13
