Summary of Contents for Crystal Image RMPW-161-19
- Page 1 KVM switch and rackmount screen technology User Manual 19” Widescreen LCD 1440 x 900 RMPW-161-19 7U Rackmount Display Panel Options : - SDI / MCS - AV / HDMI / Audio - Touchscreen / DC power - MIL-type or lockable connector UM-CV-751-RP-W19-Q322V1 www.rackmountsales.com...
- Page 2 Legal Information First English printing, July 2022 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents < Part. 1 > RMPW-161-19 Package Content Structure Diagram & Dimension Installation < Part. 2 > Specifi cations / OSD Product Specifi cations On-screen Display Operation ( OSD ) < Part. 3 > Options 3G / HD / SD-SDI Broadcast-grade input P.10... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 5: Rmpw-161-19
< Part 1 > RMPW-161-19 < 1.1 > Package Content RMPW-161-19 RMPW-161-19 unit X 1 - 6ft VGA cable X 1 - Power adapter X 1 - Power cord X 1 < 1.2 > Structure Diagram Front view Power adapter... - Page 6 < 1.2 > Dimension Front View Side View UNIT : mm Bottom View 1mm = 0.03937 inch Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 480 x 58 x 310 mm 529 x 124 x 495 mm 5.8 kg 7.9 kg...
-
Page 7: Installation
< 1.3 > Installation RMPW-161-19 Step ■ Mount the display panel with M6 screw set. ■ M6 screw x 4 pcs required ( Left & right side ). M6 screw sets are not provided. Step ■ Fix the LCD into the rack. -
Page 8: Specifi Cations / Osd
< Part 2 > Specifi cations / OSD < 2.1 > Product Specifi cations Panel Size ( diagonal ) 19-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines ) 1440 x 900 Brightness ( typ. ) Contrast Ratio ( typ. ) 1000:1 Color 16.7 M... - Page 9 RMPW-161-19 Environmental Operating Temperature 0 to 55°C degree Conditions Humidity 10~90%, non-condensing Altitude 16,000 ft Storage / Non-operating Temperature -20 to 60°C degree Humidity 5~90%, non-condensing Altitude 40,000 ft Shock 10G acceleration (11ms duration) Vibration 10~300Hz 0.5G RMS random Physical...
- Page 10 Intentionally Left Blank UM-CV-751-RP-W19-Q322V1 www.rackmountsales.com...
-
Page 11: On-Screen Display Operation ( Osd )
< 2.2 > On-screen Display Operation ( OSD ) RMPW-161-19 Membrane Switch Function Turn the monitor on or off Display the OSD menu Act as an Enter key to select screen setting options Scroll through menu options and adjust the displayed control... - Page 12 < 2.2 > On-screen Display Operation ( OSD ) Picture Brightness : Adjust the screen brightness Contrast : Adjust the diff erence between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position H-Position...
- Page 13 < 2.2 > On-screen Display Operation ( OSD ) RMPW-161-19 OSD Set Language : Select the language in which the OSD menu is displayed - English OSD H-Position : Align the screen image left or right OSD V-Position : Align the screen image up or down...
-
Page 14: Options
< Part 3 > Options < 3.1 > Options : 3G / HD / SD-SDI input Crystal Image’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with CIT displays, a SDI input... - Page 15 ( Multi-display Control ) More control is always good. Especially when it is necessary and easy. Crystal Image provides MCS solution to control the OSD of various CIT LCD display up to 64 units. The RS-232C is used for the communication between the PC and the fi...
-
Page 16: Av4.4, Hdmi, S-Video + Bnc, Audio
< 3.3 > AV4.4, HDMI, S-Video + BNC, Audio AV4.4 Option - HDMI ( HDMI 1.4, HDCP 1.4 ) - Audio ( Audio input & output ) BNC Option - BNC ( Composite, BNC ) - Audio ( Audio input & output Audio DVI-D Power... - Page 17 < 3.4 > Touchscreen & driver RP-W719 Resistive 1-pt Touch screen Specifi cation Model e-Resistive Technology 5-Wire Resistive Touch Point Single Method Stylus or Finger ≤ 50g / Stylus=R0.8 Activation Force Durability 10 million touches Response Time 15 ms Optical Transmittance 80% ±...
- Page 18 < 3.5 > Options : DC Power Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load 50 mA 50 mA 50 mA...
-
Page 19: Mil-Type Or Lockable Connector
< 3.6 > MIL-type or Lockable Connector RMPW-161-19 Input Part no. MIL Standard MIL - type MS3470W8-33P MIL - DTL - 26482 DC Power Connector ( Male ) MS3470W14-15P MIL - DTL - 26482 ( Male ) There are several additional MIL DC and VGA connector types with varying design characteristics to meet cost considerations and to provide users with the most design fl... - Page 20 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. P.16 UM-CV-751-RP-W19-Q322V1 www.rackmountsales.com...
