- Page 1 5128-005 and 5128-555 Models Hill Air Compressor Pump Assembly and User Manual...
- Page 2 5128-005 PUMP ONLY ASSEMBLY TOOLS REQUIRED: 14MM SPANNER OR ADJUSTABLE WRENCH Remove from carton Remove lock ring Fit base plate Replace lock ring tighten Attach handle by hand Attach connecting hose Tighten bleed screw with 14mm spanner by hand...
- Page 3 5128-555 PUMP WITH DRY PACK ASSEMBLY TOOLS REQUIRED: 14MM SPANNER OR ADJUSTABLE WRENCH Remove from carton Remove lock ring Fit base plate Replace lock ring tighten Attach connecting hose Remove Dry-Pac by hand with 14mm spanner from carton Pour in orange indicator Unscrew and Unscrew and media followed by the...
- Page 4 Level using straight edge Replace canister on Replace cap to remove excess beads location arm Insert location arm Push down over o-rings to contact with on tube shoulder (rotate to required position) Tighten bleed screw Attach handle by hand...
- Page 5 HOSE END CONNECTORS DO NOT use thread seal To attach connectors to the Fully tighten hose connector hose you will require two joint using appropriate tape or sealing washers. suitable spanners. One to spanners. hold the hose and the other to firmly attach the connector.
- Page 6 LUBRICATION It is recommended that the inner tube is lubricated every 3 months and the internal o-ring is lubricated twice a year with constant use. Only use Hill silicone grease. Replacement grease is available from www.airriflepump.com Other lubricants may damage the pump. DO NOT USE PETROLEUM/OIL OR PROPELLANT BASED PRODUCTS INNER TUBE...
-
Page 7: Troubleshooting
DRY-PAC REPLACEMENT Depending on usage and the local relative If there is any evidence of moisture when humidity the Dry-Pac material will eventually releasing the bleed screw the Dry-Pac become saturated. material should be immediately replaced. The Dry-Pac material should be replaced Replacement Dry-Pac material can be every 3-4 months when the pump is in use. - Page 8 Support British Manufacturing www.airriflepump.com...
