Summary of Contents for Racing RAC2600EB-UK
- Page 1 ORIGINAL INSTRUCTIONS Garden Blower Vacuum RAC2600EB-UK WARNING: READ THIS MANUAL CAREFULLY BEFORE USE IT BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux – France MADE IN PRC 2018...
-
Page 2: Specification
Adjustable Type designation Rated input power Rated no-load speed speed or not RAC2600EB-UK 3000W 15000/min SPECIFICATION Rated Voltage 230V-240V~50Hz Blower velocity 250 km/h Maximum blower air output 10.7m /min Collect bag capacity Weight 2.7Kg NOISE AND VIBRATION DATA A weighted sound pressure level: 87.4 dB(A) A weighted sound power level: 98.07 dB(A) - Page 3 IMPORTANT READ CAREFULLY BEFORE USE KEEP FOR FUTURE REFERENCE Safe operating practices for hand-held mains-operated electrical garden vacuums, and garden blower/vacuums with or without shredding means and garden blowers Training a) Read the instructions carefully. Be familiar with the controls and the correct use of the machine. b) Never allow children or people unfamiliar with these instructions to use the machine.
- Page 4 m) Stop the machine, and remove plug from the socket. Make sure that all moving parts have come to a complete stop - whenever you leave the machine, - before clearing blockages or unclogging chute, - before checking, cleaning or working on the machine. n) Do not tilt the machine while the power source is running.
- Page 5 • Do not use the tool in humid places. • Do not use the tool in the presence of flammable liquids or gases. • Do not use the product with damaged guards or shields, shields or screens not in place. •...
- Page 6 Intended use • This vacuum blower is intended to be used for the vacuuming and the blowing of leaves, dust, and similar little materials. It must not to be used for vacuuming and blowing water, chemical products, flammable material, metal or wood and others dangerous objects. •...
-
Page 7: Know Your Product
KNOW YOUR PRODUCT 1. Cord guard 2. Main handle 3. On/off switch 4. Additional handle 5. Blower tube 6. Motor housing 7. Function switch 8. Collection bag 9. Wheel 10. Shoulder harness 11. Speed control governor... - Page 8 Assembly instructions(Fig.1) 1) Slide the upper tube into the motor housing, then tighten the screws and make sure the tube is firmly fixed with motor housing. Insert lower tube into upper tube and push them until they are connected firmly together then tighten the screws.
- Page 9 Operation (Fig.2) Before stating the machine, make sure that collect bag is fitted and the shoulder harness is adjusted to a suitable working position. ⚫ Switching on and off ·To switch on, press the switch like (fig. 2a). ·To switch off, press the switch like (fig. 2b). ⚫...
-
Page 10: Maintenance
vacuum Fig.3b When the collect bag is full, the vacuum power will be greatly reduced. When this happens, turn the switch to position “0” (off) and disconnect the plug from the electricity supply. Wait until the suction fan has stopped completely before operation. Open the zip fastener inside the bag, spread out the opening and empty it completely. -
Page 11: Protecting The Environment
PROTECTING THE ENVIRONMENT Meaning of crossed –out wheeled dustbin: Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact you local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being. - Page 12 EC Declaration of conformity BUILDER SAS 32, rue Aristide Bergès - ZI 31270 Cugnaux – France declare that the machine Designation: GARDEN BLOWER VACUUM Model: RAC2600EB-UK Serial number: Is in conformity with the European Directives: Machine Directive 2006/42EC EMC Directive 2014/30/EU...
