- Page 1 IOT TOOLBOX Create an IoT chain quickly and easily QUICK START GUIDE Version 1.1.1 3 Transmitters of your choice 1 Gateway Ethernet or 4G option...
-
Page 2: Table Of Contents
IOT TOOLBOX - QUICK START GUIDE - V1.1.1 Table of contents INFORMATIONS 4G Gateway Installation ETHERNET Gateway Installation 3.1. Cables connexion 3.2. Computer Network Settings 3.3. Gateway Network Settings Page of 9... -
Page 3: Informations
IOT TOOLBOX - QUICK START GUIDE - V1.1.1 1. INFORMATIONS To know what is your IoT Toolbox version, check the sticker on the side of the box, like display below: Ethernet Toolbox version composition: 4G Toolbox version composition: • 1 Multitech gateway •... -
Page 4: G Gateway Installation
IOT TOOLBOX - QUICK START GUIDE - V1.1.1 2. 4G GATEWAY INSTALLATION Connect the white antenna LoRa on the « RF » connector of the Multitech gateway. Connect the black antenna GSM on the « CELL » connector of the Multitech gateway. Connect the power supply adaptor on the Multitech gateway. -
Page 5: Ethernet Gateway Installation
IOT TOOLBOX - QUICK START GUIDE - V1.1.1 3. ETHERNET GATEWAY INSTALLATION 3.1. Cables connexion Connect the white antenna LoRa on the « RF » connector of the Multitech gateway. Connect the Ethernet cable on « E-NET » port of the Multitech gateway. Connect the power supply adaptor on the Multitech gateway. -
Page 6: Computer Network Settings
IOT TOOLBOX - QUICK START GUIDE - V1.1.1 3.2. Computer Network Settings On your computer, click on: « Start Menu > Control Panel > Network and Sharing Center ». (For Windows 8 and higher, search for and open Control Panel and select Network And Internet). Click «... - Page 7 IOT TOOLBOX - QUICK START GUIDE - V1.1.1 Select « Internet Protocol Version 4 » (TCP/IPv4) and click on « Properties ». Select « Use the following IP address » and enter the IP address 192.168.2.3 and the Subnet Mask 255.255.255.0. Then click OK and close the Local Area Connection properties window.
-
Page 8: Gateway Network Settings
IOT TOOLBOX - QUICK START GUIDE - V1.1.1 3.3. Gateway Network Settings You are now able to communicate with the Gateway. It is necessary to connect your gateway to your company network in order to have a link between the LoRa Network and Internet. To do so, you need to ask to your network administrator an IP address, the network mask and the company gateway that you will address to the Multitech gateway. - Page 9 IOT TOOLBOX - QUICK START GUIDE - V1.1.1 Click on « Save and Restart » to save the new network interface settings. The Multitech Gateway is now rebooting and ready to be connected on the network of the company. Once the gateway is rebooted, disconnect the Ethernet cable of gateway backpanel (E-NET) and connect the network cable of your company.
