This warranty is valid only for so long as the product is used intact as shipped from PI 2 Design. Any attempt or effort to alter the Product, including but not limited to any attempt to solder, de-solder, unplug, replace,...
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 2 OPERATING SPECIFICATIONS 2.1 MERCURY V2 OPERATING SPECIFICATIONS MERCURY V2 conforms to the following specifications: Specification Value Dimensions 170mm x 123.2mm x 53.5mm (6.7” x 4.85” x 2.1”) Weight ~1.2kg (3 lbs.)
3 OVERVIEW 3.1 INTRODUCTION MERCURY V2 , designed and manufactured by PI 2 Design, is a Compute Module 4 based device designed for Professional, Studio Grade, Digital Audio Streaming. MERCURY V2 converts the Compute Module 4 I2S Interface to High-Definition Digital Audio Coax, OPTO and Balanced XLR.
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 4 ON-BOARD DEVICES OVERVIEW MERCURY V2 interfaces to the CM4 via a pair of high density Hirose Connectors. This section describes in detail the devices located on the Mercury Streamer. 4.2 COMPUTE MODULE 4 At the core of MERCURY V2 is the latest Raspberry Pi Compute Module 4.
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 4.3 WM8804 SPDIF TRANSMITTER At the core of MERCURY V2 is the Cirrus Logic WM8804 AES Digital Audio Transmitter. This device interfaces to the Compute Module 4 via I2S and I2C. The signals used to interface with the WM8804 are shown in the following table.
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 sends it as a balanced pair to the 1:1 Isolation Transformer and then to the XLR connector. 4.6 I2S PARALLEL BUFFER A 4-Bit Buffer is used to drive the I2S signals (MCLK, BCKL, LRCLK and SDO) to the RJ45.
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 5 CM4 PORTS AND GPIO 5.1 OVERVIEW MERCURY V2 uses several the Interface Ports and GPIO from the CM4 for control and status purposes. 5.2 COMPUTE MODULE 4 PORTS Certain CM4 Port pins are hardwired and are always available when enabled. The usage for these ports on MERCURY V2 are listed below in the following table.
Page 11
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 can be assigned to alternate functions as defined in the CM4 documentation. The usage of these pins (and alternate functions) on MERCURY V2 are described in the following table. GPIO...
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 GPIO Mercury Description/Notes Streamer Usage unused unused unused unused unused Table 5 – CM4 Port and GPIO Pin Assignments 5.3.1 CM4 GPIO NOTES 2. DIR is from the point of view of the CM4.
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 6 MERCURY V2 POWER 6.1 OVERVIEW MERCURY V2 is designed to be powered from an external +12V source. See the block diagram below for a simplified view of MERCURY V2 power flow. +12V +/- 20% RESETABLE DC INPUT...
Page 14
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 6.3 POWER STATUS As part of the power control circuit, GPIO24 (*PSW) is used to sense the state of the Pushbutton Power Switch. A low indicates that the Power Switch is in the on position (depressed).
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 7 MERCURY V2 SOFTWARE 7.1 OVERVIEW Due to the various resources interfaced on the Mercury Streamer, both internal and external to the CM4, it is necessary to initialize a large number of CPU registers and external devices before correct operation can begin.
This section provides the type, location, and pinout for the various connectors on the Mercury Streamer. 8.2 FRONT AND REAR PANEL AND INTERIOR VIEWS This shows the front and rear panels of MERCURY V2 as well as an internal view of the PCB. Figure 4 – MERCURY V2 Front Panel Figure 5 –...
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 USB2.0 Pinout. It is connected to the USB2504A USB Hub, Ports 3 (top) and 4 (bottom). 8.4 HDMI 0 AND 1 HDMI 0 and 1 are standard right angle HDMI female connectors and conforms to the industry standard HDMI Pinout.
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 P15 PIN Name Description No Connect Pulled to GND with 10K ohm resistor Pulled to GND with 10K ohm resistor Ground Connected to +5V via 100 ohm resistor No Connect Table 6 –...
Page 19
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 P15 PIN Name Description LRCLK I2S Left/Right Clock Ground BCK- I2S Bit Clock Ground I2S Master Clock Ground Table 7 – Parallel I2S Over RJ45 Pinout PAGE 19...
Pi 2 Design Mercury V2, Hardware Reference Manual – P1 11 ERRATA 11.15 OVERVIEW The Vertical USB and HDMI Port are not Available for Rev. P7 PAGE 21...
