BELLATERRA HOME 10118A1 Manual

Basin Faucet - 10118A1 & 10118A2

PACKING LIST

After you open this package, please check to ensure that all of the following items are included.
A-Faucet B-Mounting Nut C-Flexible Hoses(2)
A
IMPORTANT NOTICES: For easy installation, please read all the instruction completely before beginning.
Before installing this product, make sure that water line trash is cleared to avoid blockage.

YOU MAY NEED

D-Allen wrench
B
D
Optional accessories
C

INSTALLATION PROCEDURES

1
You should clean all the dirts from valve outlets.
Turning off the water supply valves. This is usually
found near the water meter. If you are replacing
an existing faucet, remove the faucet from the
sink and clean the sink surface thoroughly.
2A
Install with Deck Plate. Place a bead of plumber's
putty between faucet and sink. Place Deck Plate
over the three holes of sink. From underside sink,
tighten Wing nut.
3
If necessary, tighten screws using a adjustable
wrench until the faucet is firmly connected to the
sink.
2
Install without Deck Plate. Make sure the O-RING
is placed onto the bottom of Base Ring. Install
faucet through hole in sink. From underside sink,
put Plastic Washer and Mounting Nut. Position
faucet on sink properly and tighten Mounting Nut.
2B
Make sure the O-RING is placed onto the bottom
of Base Ring. Install faucet through Deck Plate.
From underside sink, put Plastic Washer and
Mounting Nut. Position faucet on sink properly
and tighten Mounting Nut.
4
Connect hot and cold water supply lines to the Water
Supply Valves.
