Swiveling, Tilting Rotating
For technical assistance or troubleshooting
This product Wall Mount frame is intended for use only with an apparatus which has a maximum weight of 132 lbs. See apparatus
instructions. Using with an apparatus heavier than the maximum weight indicated may result in instability and cause possible
injury.
READ THIS FIRST
Read this entire manual! Do not attempt to install this product if you do not understand the instructions. Contact a qualified
mount installer if you have any doubts about a safe and secure mount installation, or if you are not sure what specific wall
materials you are attaching this mount to. Check all the parts carefully to make sure there are no missing or damaged parts.
Improper installation may result in damage to your TV, property, and personal injury.
Flat Panel Wall Mount
Installation Guide
Model: V5760STC
• Supports most 32"- 80" Flat Panel TVs
please call 1-855-998-4326.
+5 to -5
+5 to -15
Advertisement
Related Manuals for Vidao V5760STC
Summary of Contents for Vidao V5760STC
- Page 1 Swiveling, Tilting Rotating Flat Panel Wall Mount Installation Guide Model: V5760STC +5 to -15 +5 to -5 • Supports most 32”- 80” Flat Panel TVs For technical assistance or troubleshooting please call 1-855-998-4326. This product Wall Mount frame is intended for use only with an apparatus which has a maximum weight of 132 lbs. See apparatus instructions.
- Page 2 Schoenfeld International Inc. and VIDAO are not responsible for personal injury or product damage due to mishandling, incorrect mounting, incorrect assembly, or incorrect use of this product.
- Page 3 M4/M5 washers M6/M8 washers...
- Page 4 If your television has a straight back, spacers are not required. Use the selected bolts (A-H) and square washers (I) to install the bracket directly on the back of the television as shown in Fig 1a. Make sure that the two brackets are equal in height and are level. Once the brackets are aligned, securely tighten the bolts.
- Page 5 (A-H) If necessary, use additional washers (N, O) to make sure the the bolts (A-H) keep the bracket snug to the rear of the TV without over tightening.
- Page 8 A large television requires two people to lift. Schoenfeld International Inc. and VIDAO are not responsible for equipment damage or personal injury due to mishandling. Do not release the TV until you are sure that it is securely mounted. Releasing the TV without...
- Page 10 +5 to -15 +5° to -15°...
- Page 11 We warrant this product to you, the original purchaser at the time of purchase printed on a dated store receipt from an authorized VIDAO retailer and for a period of six-years thereafter that our wall mount product and all it’s parts and components are free of defects in material and workmanship under normal use.
- Page 12 Schoenfeld International Inc. and VIDAO 5001 American Boulevard West Suite 275 Bloomington, MN 55437 ©Schoenfeld International Inc. 2013 PN: V5760STC Rev 1.4V October, 2013...
