MIDWEST TROPICAL INC.
3420 West Touhy Avenue., Lincolnwood, Illinois 60712 U.S.A
Please read carefully BEFORE installing your Model
WP-II WATER PANEL
WP-II WATER PANEL
To insure many years of use, please follow these simple instructions carefully.
Unpack the Water panel II unit and its parts carefully. Carefully peel off and remove any protective
brown paper that may remain on the acrylic parts.
This aquatic sculpture is shipped complete in one carton containing all of the following equipment:
WP-II WATER PANEL ASSEMBLY INSTRUCTION
1)
Place the Water Panel-II's black acrylic base in the desired location with the cord slot on
your right. The base unit has been designed to provide stability for the WP-II. It must be
placed on a strong, level surface. It is further recommended that you place the Water Panel
unit near an electrical outlet. Place Water Panel Tank Section firmly between the slots
inside the black acrylic base (make sure Tank Section rests properly between the channeled
slots). Carefully slide Water Panel Tank Section down inside the base.
2.)
Your Water Panel-II is now ready to be filled with water. It is highly recommended that
you use distilled water to fill the Water Panel II. The water Panel-II holds approximately 90
fl. ounces of water, therefore one-gallon of distilled water (readily available at most grocery
stores) is more than adequate. Pour water slowly and carefully into the Water Panel
chambers through the top to ensure no spillage. Unit should be filled approximately 1/2
inches from the top, or as soon as you reach the end of the acrylic chamber bars. Make sure
that the hex nut that secures the removable wand and air line is securely tightened. To
tighten, turn the hex nut clockwise with your hand. Do not over tighten so as not to strip the
threads. Next, check the unit to ensure that there is no spillage.
•
Clear Acrylic Channeled tank section with Check Valve,
*
Black Acrylic HEADER UNIT
*
Air Pump
*
Black Acrylic Base
*
Black Acrylic Base Cover
*
Fluorescent Light Fixture With Bulb
*
One Tri-Color Neon Fluorescent Color Strip
TM
Airline Tubing, Bubble Wand Installed
TM
II or
II WAVE.
⊗
Advertisement
Table of Contents
Related Manuals for Midwest Tropical WP-II WATER PANEL II
Summary of Contents for Midwest Tropical WP-II WATER PANEL II
- Page 1 MIDWEST TROPICAL INC. 3420 West Touhy Avenue., Lincolnwood, Illinois 60712 U.S.A Please read carefully BEFORE installing your Model WP-II WATER PANEL II or WP-II WATER PANEL II WAVE. To insure many years of use, please follow these simple instructions carefully.
- Page 2 Page 2 WATER PANEL-II ASSEMBLY INSTRUCTION CONT. Unpack the air pump and place it on the narrow unsloted side of black acrylic base (Refer to Figure 4) located on one side of the base. Make sure that the cord of the air pump wraps around the side of the Water Panel Base, and that the nozzle of the air pump is aimed toward the hex nut with airline extending out as in Figure 4.
- Page 3 HELPFUL HINTS FOR EASY CARE AND MAINTENANCE OF YOUR WATER PANEL-II Your Water Panel-II is constructed using high quality cell-cast acrylic. When dusting or cleaning your Water Panel II periodically, it is recommended that for extra luster and brilliance that you use an acrylic cleaner, which is available at many hardware and grocery stores.
- Page 4 MIDWEST TROPICAL INC. 3420 West Touhy Avenue., Lincolnwood,Illinois 60712 U.S.A. WATER PANEL-II PLEASE SPECIFY 8, 10 0R 12 CHAMBERS !!!!! Quantity Item Description Cost Total _______ Air Pump $24.00 $__________ _______ Light Fixture w/ Bulb – 12” $24.00 $__________ _______ One Set of 4 Neon Fluorescent Solid Color $22.00...
