Lunar Artefacts OPTIC Classic LAPI-C-MK1 Quick Start Manual

Hide thumbs Also See for OPTIC Classic LAPI-C-MK1:
1
2
3
4
5
6

Advertisement

Table of Contents

72mm
40mm
THE POINTER INSTRUMENT
OPTIC EDITION
Model :
Pointer Instruments Classic (LAPI-C-MK1)
Interface :
Bluetooth 5.0 | Wireless 2.4G dongle | USB-C
Sensor :
Pixart PAW 3805 Optical Sensor
-Glass thickness minimum 5mm-
DPI :
800 | 1200 | 2000 | 3000
Hand Orientation :
Ambidextrous
Recharge :
Wireless Charging | USB-C
Dimensions :
124mm x 72mm x 40mm
Weight :
Aluminium 120g | Brass 195g
Compatibility :
Windows | MacOS | Linux | Android
Battery :
3.7V - 850 mAh Li-ion Rechargeable Battery
-Molex 51006 or "Losi Connector"- 9mm x 43mm x 25mm-
LUNAR ARTEFACTS
LONDON

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the OPTIC Classic LAPI-C-MK1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lunar Artefacts OPTIC Classic LAPI-C-MK1

Summary of Contents for Lunar Artefacts OPTIC Classic LAPI-C-MK1

  • Page 1 124mm x 72mm x 40mm Weight : Aluminium 120g | Brass 195g Compatibility : Windows | MacOS | Linux | Android Battery : 3.7V - 850 mAh Li-ion Rechargeable Battery -Molex 51006 or “Losi Connector”- 9mm x 43mm x 25mm- LUNAR ARTEFACTS LONDON...
  • Page 2 OVERVIEW -1- Top latch point -2- Left mouse button -3- Right mouse button -4- Scroll wheel -5- Charge indicator -6- Battery compartment -7- Magnetic latch -8- USB-C Socket -9- Battery indicator -10- Power switch -11- USB Dongle -12- DPI (Sensitivity) button -13- Tracking sensor -14- Connection button -15- Wireless charging point...

  • Page 3: Product Features

    PRODUCT FEATURES - Replaceable Top Cover - - Solid Brass or Aluminium Base - - Wireless Qi | USB-C Cable Charging - - Bluetooth 5.0 | 2.4G Dongle | USB-C Cable - - Track On Glass Sensor - - Plug and Play Replaceable Switches - - Designed For Longevity - BOX CONTENTS -1- The Pointer Instrument.
  • Page 4 CONNECTIONS - Bluetooth Connection - To power on the mouse, turn the ON/OFF switch to the ON position. Tap the connection button to switch to Bluetooth mode with the Bluetooth indicator ON. Press and hold down the connection button for 3 seconds and then release.

  • Page 5: Dpi Settings

    - Cable Connection - Insert the USB-C into the mouse. Connect the USB-A to the computer. Switch the power button to the ON position. Press the connect button until both LED lights are ON. The mouse will be charging while plugged in- DPI SETTINGS DPI settings: Press to change...

  • Page 6: Help And Support

    HELP AND SUPPORT Please scan the QR Code below to be taken to our Help and Support: www.lunarartefacts.com/support Here you will find multi-language guides, FAQ and other useful information regarding the Pointer Instrument, as well as the contact form to get in touch with Customer Support. 38 Spital Square, London, E1 6DY, United Kingdom support@lunarartefacts.com www.lunarartefacts.com ©2022...
