- Page 1 INSTRUCTION MANUAL ADVANCED IN-HELMET COMMUNICATION...
- Page 2 RPB Safety Asia Pacific Headquarters 10 Holt Place, Harewood, Christchurch, New Zealand. T: +64-3-357-1761 F: +64-3-357-1763 E: sales.nz@rpbsafety.com www.rpbsafety.com RPB, advancing your safety and NOVA 3 are registered trademarks of RPB Safety For technical assistance contact our Customer Service Department Form #: 7.20.518...
- Page 3 SET UP (09-903) Figure 1.1 Figure 1.2 Connect the PTT Cable to the Hand Set. Use a Flat head screwdriver to tighten the connection screw. Figure 1.3 Figure 1.4 Attach the PTT to your belt so your elbow Place the helmet on and connect the clips can activate the Button.
- Page 4 SET UP (09-903) CONTINUED Figure 1.5 Figure 1.6 Connect the PTT cable to the head set To operate the device, press your elbow cable and place the cable underneath the onto the PTT Button, and then speak. cape. PROTECTIVE SHROUD Figure 2.1 Figure 2.2 The Protective Shroud is used when work-...
- Page 5 Open the zip in the inner bib so that the Close the zip so that there are no gaps. Cable from the Head Set can pass though. Then refer to the Set up Section to com- plete the Set Up of the Nova 3 Talk Helmet.
- Page 6 UPGRADE CONTINUED Figure 3.5 Figure 3.6 To swap the Nova 3 Talk headset from the Remove the headset from the sidepad and left side to the right side. cut the cable ties. Figure 3.7 Figure 3.8 Place the headset on the right hand frame,...
- Page 7 MAINTENENCE Figure 4.1 Figure 5.2 Figure 4.2 After removing the cape from the helmet, Carefully remove the headset from the take the sidepad out of the helmet. sidepad. Note: this device is fragile, please use extreme care. Figure 4.3 Figure 4.4 Seperate the cover and the sidepad.
- Page 8 RADIO CONNECTORS MOTOROLA 09-930 AXU4100, AXV5100, BPR40, CLS1110, CLS1410, CLS1413, CLS1450C, CLS1453C, CP100, CP150, CP185, CP200, CP88, CT125, CT150, CT250, CT450, CT450LS, DTR, DTR410, DTR550, DTR650, GP200, GP2000, GP300, GP308, GP68, GP88, GTI, GTX, LTS2000, P040, P080, P110, P1225, P1225LS, P200, P2000, PR400, RDK, RDU, RDU2020, RDU2080D, RDU4100, RDU4160D, RDV, RDV2020, RDV2080D, RDV5100, SP10, SP21, SP50, VL50, XTN, XTN446, XTN500, XTN600, XU1100, XU2100, XU2600,...
- Page 9 09-933 TC-268, TC-268S, TC-270, TC-368, TC-368S, TC-370 KENWOOD TH-22AT, TH-235A, TH-28A, TH-42AT, TH-48A, TH-77A, TH-78A, TH-D7A(G), TH-F6, TH-F6A, TH-G71A, TH-K2AT, TK-208, TK-2100, TK-2102, TK-2130, TK-2160, TK-2170, TK-220, TK-2200, TK-2200LP, TK-2212L, TK-2302VK, TK-240, TK-240D, TK-248, TK-250, TK-260, TK-260D, TK-260G, TK-270, TK-270G, TK-272G, TK-308, TK-3100, TK-3101, TK-3102, TK-3130, TK-3131, TK-3160, TK-3170, TK-3173, TK-320, TK, 3200, TK-3200LP, TK-3212L, TK-3230, TK-3230XLS, TK-3302UK, TK-340, TK-340D, TK-348, TK-350, TK-353, TK-360, TK-360G, TK-370, TK-370G, TK-372G, TK-373, TK-430,...
- Page 10 PARTS LIST...
- Page 11 Item Number Description Part Number Communication Upgrade Kit 09-903 09-913 Two Pin 09-930 Multi Pin 09-931 Multi Pin 09-932 Two Pin 09-933 Multi Pin 09-934 One Pin 09-935 Other Radio Connectors may be available.
- Page 12 The RPB® 4000-01 Cool Air Tube cools compressed breathing air coming into the respirator by up to 30°F while the RPB® 4000-20 Hot Air Tube will heat the compressed air by up to 30°F. These maximize worker comfort and increase productivity in hot or cold climates.
