Summary of Contents for Laskomex Bastion Draco

  • Page 1 Video door phone set Assembly and operating manual...

  • Page 3: Operating Conditions

    1. OPERATING CONDITIONS NOTE! For affirmation of safety put on the mains terminal covering (plastic element attached to the feeder) after connect the feeder to the mains. Covering installation method is shown on drawing. All the connection make with the power supply turn off. 2.
  • Page 4 ELEMENTS OF BASTION VIDEO DOOR PHONE MVC-6501 monitor BVC-6501 external panel...
  • Page 5 ZS-15 feeder Electro-catch (not include in the set) Feeder to electro-catch (option - not included in the basic set)
  • Page 6 4. BEFORE THE ASSEMBLY Specify the places where video door phone elements are to be mounted. Electric installation of video door phone. Distance Connection <15m <60m <30m +Vcc,GND,audio 0,75mm 0,75mm 0,4mm external panel - monitor 0,75mm video 0,4mm Coaxial cable monitor - monitor 0,75mm DCV feeder - external monitor...
  • Page 7 Optional - connecting second monitor +Vcc Gnd audio video 230V AC 15V DC/0.8A 12V AC/1A 230V AC +Vcc G n d audio video Wiring in external panel...
  • Page 8 MVC-6501 +Vcc Gnd audio video +Vcc Gnd audio video 230V AC 15V DC/0.8A 12V AC/1A 230V AC MVC-6501 +Vcc Gnd audio video +Vcc Gnd audio video Wiring in external panel 230V AC 15V DC/0.8A MVC-6501 J100 J103 +Vcc Gnd audio video ZS-15 230V AC 15V DC/0.8A...
  • Page 9 ASSEMBLY AND CONNECTING ELEMENTS OF VIDEO DOOR PHONE Assembly and connecting MVC-6501 monitor Connecting an additional monitor J100 J102 J103...
  • Page 10 Assembly and connecting the external panel. Feeder assembly Assembly of electro-catch 6. OPERATING VIDEO DOOR PHONE...

  • Page 11: Maintenance

    The electro-catch is activated once the button is released. 7. MAINTENANCE ATTENTION! 8. TECHNICAL DATA MVC-6501 monitor BVC-6501 external panel ZS-15 feeder...
  • Page 12 List of collecting units of used Laskomex equipment is available on www.laskomex.com.pl website telephone Product packing should be removed according to environment protection regulations. Remember! Selective collection and recycling of used electronic and electric equipment considerably contributes to the protection of human health and life as well as protection of natural environment.
