Tripp Lite HCRK-2 Owner's Manual

Tripp Lite HCRK-2 Owner's Manual

Medical-grade, mobile power retrofit kit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
200608041 93-2617 Retrofit Kit 2 OM.qxd
Kit Includes: Power Supply Module, Battery Module, Remote User Interface (RUI),
PowerAlert Data-Saving Software, Mounting Hardware and Cables.
Important Safety Instructions
Mounting
Connection / Start-Up
Operation
Features
Troubleshooting
Storage & Service
Safety & Regulatory Statements
Warranty & Warranty Registration
Owner's Manual
Medical-Grade,
Mobile Power
Retrofit Kit
Model #: HCRK-2
Fully tested, certified and compliant to:
• UL 60601-1 • CAN/CSA-C22.2 No. 601.1-M90 • UL 1778
1111 W. 35th Street, Chicago, IL 60609 USA
(773) 869-1234 • www.tripplite.com
Copyright © 2006 Tripp Lite. All rights reserved.
9/14/2006
2:06 PM
by
Page 1
2
3
5
7
8
10
11
11
12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HCRK-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Tripp Lite HCRK-2

Summary of Contents for Tripp Lite HCRK-2

  • Page 1 Important Safety Instructions Mounting Connection / Start-Up Operation Features Troubleshooting Storage & Service Safety & Regulatory Statements Warranty & Warranty Registration 1111 W. 35th Street, Chicago, IL 60609 USA (773) 869-1234 • www.tripplite.com Copyright © 2006 Tripp Lite. All rights reserved.

  • Page 2: Important Safety Instructions

    Equipment Connection Warnings • Do not use Tripp Lite Power Supply Modules for life support devices in which a malfunction or failure of a Tripp Lite Power Supply Module could cause failure or significantly alter the performance of a life-support device.

  • Page 3: Labeling Symbols

    Mount the Power Supply Module and Battery Module BEFORE connection. The mounting brackets are only designed to support a Tripp Lite Power Supply Module and a single Battery Module. Do not mount or place any other devices on the mounting brackets.
  • Page 4 Lay cart on its side and remove existing bracket from bottom of cart.* * The existing bracket is not required for mounting or operation of Tripp Lite's Retrofit Kit. However, Tripp Lite's mounting tray includes holes that will accept the blocks from the existing bracket (if desired).

  • Page 5: Connection / Start-Up

    200608041 93-2617 Retrofit Kit 2 OM.qxd 9/14/2006 2:06 PM Page 5 Connection / Start-Up NOTE: Several adhesive cord-management devices are included. Use them, if desired, to keep cords and cables securely stowed after connection. Connect the Remote User Interface (RUI) to the Power Supply Module The Power Supply Module will not operate without the RUI connected.
  • Page 6 200608041 93-2617 Retrofit Kit 2 OM.qxd 9/14/2006 2:06 PM Page 6 Connection / Start-Up continued Turn the Power Supply Module’s Outlets ON Press and hold the “Power” button* for one second. The alarm will beep once briefly after one second has passed. Release the button. The “Power”...

  • Page 7: Operation

    Flashing Green * Tripp Lite recommends that the Power Supply be plugged into a wall outlet, charging the battery as often as possible. Charging the batteries for brief intervals DOES NOT adversely affect battery performance. However, leaving the batteries fully discharged...
  • Page 8 200608041 93-2617 Retrofit Kit 2 OM.qxd 9/14/2006 2:06 PM Page 8 Features Remote User Interface (RUI): “Power” Button: This button turns the Power Supply Module’s outlets (and any connected equipment) on and off. To turn the Power Supply Module’s outlets ON: Press and hold the “Power”...

  • Page 9: Power Supply Module

    Consult your PowerAlert manual (included on CD) for more information. Battery Connectors: Use to connect the Power Supply Module to the Battery Module. Contact Tripp Lite for additional solutions to meet all your runtime needs. Cooling Fan: Quiet, efficient fan regulates internal temperature and prolongs equipment service life.

  • Page 10: Troubleshooting

    When the Battery Module reaches the end of its service life it will supply progressively diminishing capacity. Contact Tripp Lite for additional information. Low battery alarm sounding. Check Battery Charge Level LED Meter: Silence the alarm, if desired, with the “Alarm Mute”...

  • Page 11: Storage And Service

    Tripp Lite service technician. Safety & Regulatory Statements It is the user's responsibility to verify and ensure that Tripp Lite's Medical-Grade, Mobile Power Retrofit Kit is appropriate for use within their specific application (meeting all safety and regulatory requirements for the application).

  • Page 12: Warranty & Warranty Registration

    Limited Warranty Tripp Lite warrants its Power Supply Module to be free from defects in materials and workmanship for a period of 2 years from the date of purchase by end user. Tripp Lite warrants its Battery Module to be free from defects in materials and workmanship for a period of 6 months from the date of purchase by end user.

Table of Contents
