PurTest PT Series
U.V. Disinfection
INSTALLATION & OPERATION MANUAL
This manual covers installation, operation and maintenance
requirements for PurTest U.V. Light Disinfection Systems.
Model - PT-8, PT-12, PT-20
(During normal operation, the Green LED will flash every 5 - 10 seconds.)
It is important that those responsible for the installation of this
equipment, as well as the owner / operator, read this manual
and carefully follow the instructions and guidelines.
American Water Service, LLC
5001 Smith Farm Road
Matthews, NC 28104
ph: (704) 821-3200
fax: (704) 821-3232
Revised: 2/12
Advertisement
Table of Contents
Related Manuals for PurTest PT Series
Summary of Contents for PurTest PT Series
- Page 1 U.V. Disinfection INSTALLATION & OPERATION MANUAL This manual covers installation, operation and maintenance requirements for PurTest U.V. Light Disinfection Systems. Model - PT-8, PT-12, PT-20 (During normal operation, the Green LED will flash every 5 - 10 seconds.) It is important that those responsible for the installation of this equipment, as well as the owner / operator, read this manual and carefully follow the instructions and guidelines.
- Page 2 WARNING: The UV lamp inside of the disinfection system is rated at an effective life of approximately 9,000 hours. To ensure continuous water treatment, replace the UV lamp annually with the appropriate PurTest UV lamp. Failure to comply may present a fire hazard.
-
Page 3: Description Of Equipment
Flow rate must not exceed rated capacity of the unit. DESCRIPTION OF EQUIPMENT: The PT series has an unique design with an ultraviolet germicidal lamp housed within a single quartz sleeve surrounded by a stainless steel pressure chamber. The chamber is fabricated out of 304 Stainless Steel. -
Page 4: Installation
U.V. disinfection units must always be properly grounded. INSTALLATION: The PT series are always placed after the pressure tank and any other type of treatment devices (i.e. softeners, filters). These units are normally installed in a vertical position in an enclosed area with good ventilation. Allow clearance of at least the unit’s length at one end for quartz sleeve and bulb replacement. -
Page 5: General Installation Diagram
STEP BY STEP INSTALLATION: 1. Turn off the water before cutting into the water line. 2. Assess the installation (i.e. type of pipe, size of lines, etc.) and obtain necessary plumbing fittings for installation. Inlets and outlets on 8, 12 & 20 gpm units are 3/4" MNPT. Use Teflon tape on all threaded connections and avoid over tightening. - Page 7 OPERATING INSTRUCTIONS Your UV System is equipped with the PT-280CB UV Lamp Detector and Timer circuit board which is designed to provide a continuous monitoring system of the UV lamp operational status. This solid state electronic circuit board provides the latest in UV lamp monitoring technology. UV LAMP / CONTROL BOX START UP PROCEDURE - (4 Step Process) 1.
- Page 8 To Find out how many Months are left on the Lamp Timer - Push the reset button for 1-2 seconds then release. After an initial sound there will be a pause followed by beeping and a flashing LED. The number of beeps corresponds to the number of months left on the lamp life. To Reset 1 Year Lamp Timer –...
-
Page 9: Quartz Sleeve
QUARTZ SLEEVE: Installation of the Quartz Sleeve: Always handle quartz sleeves carefully to prevent breaking or chipping. The quartz sleeves are to be clean and free of fingerprints before installing. Remove the compression nut. Install the quartz sleeve (domed end first) into the stainless steel housing, through the threaded nipple. - Page 10 ELECTRICAL: The PT series are furnished with 6' line cord that will plug into a 110V outlet. Electrical receptacles must be properly grounded for safe operation. Improper grounding will void any warranty. When possible use a separate breaker to minimize voltage fluctuations and avoid accidental shut off.
-
Page 11: Disinfection Procedure
SANITATION PROCEDURE FOR INSTALLATION AND BULB REPLACEMENT: HOW TO DISINFECT A WATER SYSTEM: Every new well, or existing water supply system that has been disrupted for service or repair, should be disinfected before it is returned to use. Water in the well and storage tank should be treated with a strong chlorine solution to destroy disease organisms. - Page 12 LARGE DIAMETER WELLS: Dug or bored wells should be disinfected in the same way as a drilled one. Lower the water level as much as possible, remove the sand, silt and debris, and then treat with the chlorine solution. Mix thoroughly by circulating the water back into the well and use the hose to rinse the interior lining of the well.
- Page 13 REMEMBER - To make your water supply safe: - Locate your well properly. - Protect it from surface contamination. - Test water periodically for coliform bacteria. (Home-yearly, Farm-2X yearly) - Chlorinate, or filter and disinfect the water if necessary. When installing an ultraviolet disinfection system, a prefilter with sump may serve as a source to sanitize the water lines only.
- Page 14 DRILLED WELLS: 1. Remove the cap or seal from the casing and measure the depth of the water in the well, then refer to Table 1 to determine how many chlorine pellets should be used. In some instances removing the seal to measure the water can be a difficult task, and it is easier to estimate well and water depth from well log or other records.
-
Page 15: Troubleshooting Guide
TROUBLESHOOTING GUIDE PROBLEM CAUSE CORRECTION U.V. lamp will not light Check input voltage if below Install a voltage regulator or above 120 volts Line cord disconnected Check, replace or outlet defective Defective U.V. lamp Replace Defective lamp ballast Check output voltage Replace ballast Loose open-circuit wire Trace out and repair... -
Page 16: Limited Warranty
LIMITED WARRANTY All parts of the disinfection unit, with the exception of the U.V. lamp, are guaranteed for one (1) year against defective parts and workmanship. The stainless steel disinfection chamber series guaranteed (10) years. component which fails to operate satisfactorily within their time period will be replaced free of charge under the following conditions: NOTIFY YOUR LOCAL DEALER OR DISTRIBUTOR OF ANY PARTS SUSPECTED OF BEING DEFECTIVE. -
Page 17: Specifications
SPECIFICATIONS Model # Max. Flow No. Lamps KW @ AMP @ Pipe Size Overall Dimensions Shipping 120V 120V L x W x D Weight PT-8 0.03 0.25 3/4'' MIP 21'' x 3.5'' x 3.5'' 9 Lbs. PT-12 0.03 0.25 3/4'' MIP 32'' x 3.5'' x 3.5'' 18 Lbs. - Page 18 SUGGESTED PROCEDURE FOR OBTAINING STERILE WATER SAMPLES: Prior to taking the water sample, be sure to have on hand an adequate supply of sterile bottles. These sterile bottles should be obtained from a reputable laboratory and should have been autoclaved and contained within a plastic outer wrapping.
-
Page 19: Wiring Diagram
WIRING DIAGRAM... - Page 21 DRAWING AND PART NUMBERS...
- Page 22 PT-8 Explosion...
- Page 23 PT-8 Parts List CODE PART# DESCRIPTION QTY. P8-5249 Chamber P8-R01 ¾” Flo.-Et. Retainer 8 gpm P8-F08 8 gpm Flo.-Et. P8-268 Top Mounting Bracket P8-5-410 Lock Nut P8-8-544 End Nut O-Ring (seal quartz sleeve) P8-5-409 Brass End Nut P8-8-546 O-Ring (for shroud on end nut) P8-7091 Gaynor Connector P8-HS4-075-BK Shrink Tubing...
- Page 24 PT-12 Explosion...
- Page 25 PT-12 Parts List CODE PART# DESCRIPTION QTY. P12-5252 Chamber P12-R02 ¾” Flo.-Et. Retainer 12 gpm P12-F12 12 gpm Flo.-Et. P12-268 Top Mounting Bracket P12-5-410 Lock Nut P12-8-544 End Nut O-Ring (seal quartz sleeve) P12-5-409 Brass End Nut P12-8-546 O-Ring (for shroud on end nut) P12-7091 Gaynor Connector P12-HS4-075-BK Shrink Tubing...
- Page 26 PT-20 Explosion...
- Page 27 PT-20 Parts List CODE PART# DESCRIPTION QTY. P20-5266 Chamber P20-270 Top Mounting Bracket P20-5-410 Lock Nut P20-8-544 End Nut O-Ring (seal quartz sleeve) P20-5-409 Brass End Nut P20-8-546 O-Ring (for shroud on end nut) P20-7091 Gaynor Connector P20-HS4-075-BK Shrink Tubing .167 P20-N1155 Brass Shroud...
