- Page 1 P2152CH Extractors Installation, use and maintenance Cod:0103091364-00.01...
- Page 3 Information and Advice CAUTION:Accessible parts may become hot when used with cooking appliances. In certain circumstances electrical appliance may be a danger hazard. A) There must be adequate ventilation of the room when the cooker hood is used at the same time as appliances burning gas or other fuels.
-
Page 4: Using Your Extractor
Using your Extractor For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for approximately 15 minutes after the end of cooking. Control Panel B - Speed level buttons C - Light button Fig. -
Page 5: Care And Maintenance
Care and Maintenance IMPORTANT：DO NOT PERFORM MAINTENANCE OR CLEANING OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY SUPPLY. Cleaning You should use a non-abrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. -
Page 6: Charcoal Filter
Charcoal filter In re-circulating mode, air is vented back into the kitchen through the opening in the cooker hood. This method is advised if you are not using your hob intensively. Re-circulated air requires the use of charcoal filters to remove odours. To ensure the best performance from your cooker hood, the charcoal filter should be replaced every 3-6 months, dependent on use. -
Page 7: Electrical Information
PROTECTION LINE 5A Fuse is installed inside the plug to protection line. FUSE 5A Electrical Information Mains electrical voltage: 230 – 240Vac Total rated power consumption: Troubleshooting Please note: Your extractor is equipped with a motor protection device that will happen during cooking when most or all of the zones/burners are being used simultaneously, or if your extractor is installed incorrectly, lower than the recommended height. - Page 8 GUARANTEE comes with a 1 Year Warranty. An additional 1 year extended warranty is available by registering your product here www.powerpointaplliances.ie...
-
Page 9: Installation
Installation NB. This hood is supplied with a charcoal filter as standard. If you are ducting the air outside please ensure this filter is removed before use. When the extractor is to be installed above an electric hob, the minimum distance between the hob and extractor must exceed 600mm for ceramic and solid plate hobs and 550mm for induction Hobs. - Page 10 Extractor dimensions. . g i INSTALLATION Mark out the dimensions of the cut-out based on your extractor. . g i...
- Page 11 INSTALLATION NB. Ducting Kit - For best results Please use 120mm ducting. A reducer maybe required for smaller diameter ducting. Remove the grease filter, unscrew Connect the exhaust pipe to the the 4 screws of the fixed panel and ducting adaptor and locate on the remove it.
- Page 12 This product was supplied by Shomar Ltd Dublin Ireland. To contact us for after-sales service or spare parts please visit our website www.powerpointapplainces. ie or scan the QR code below.
