BOHYUN BY- 6S User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Wheel Balancer
BY- 6S
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the BY- 6S and is the answer not in the manual?

Questions and answers

Summary of Contents for BOHYUN BY- 6S

  • Page 1 Wheel Balancer BY- 6S User Manual...
  • Page 2 Technical performance of BY series tire balancer -This machine adopts central computer system imported components, high intelligence, high stability. -The main shaft of the mechanism is driven by imported bearing, with high wear-resisting precision and low noise. -With the most advanced computer drive system, high stability. -With automatic dynamic and static balance detection function.
  • Page 3 reliably connected to the power cord of the balancing machine to avoid human stampede. 8. Between the back and the wall of the balancer, there should be a distance of 50 CM to ensure good ventilation and heat dissipation. 9. Contact your maintenance service personnel before moving the balance machine. BY main components of tire balancer...
  • Page 4 Installation debugging method 1. Switch on and display HLP 2. Press F+FINE key to display the window is lit up 3. Press ALU key to enter the setting program. The current spindle tooth position is displayed, and the spindle can be rotated forward and backward to check the phototelex Sensory work.
  • Page 5 Aging of balancing machine 1. Press F+FINE key to display the window is lit up 2. Press ALU key to enter the setting program. The current spindle tooth position is displayed, and the spindle can be rotated forward and backward to check the phototelex Sensory work.
  • Page 6 screw Width measuring calipe Quick change of nuts Balance block disassembly clamp Optional accessories for BY series tire balancer shield Special - made large cone Special - made fl ange Standard Annex for Tire Balancer (List) Balance block disassembly clamp...
  • Page 7 Width measuring caliper Axial - positioning cone Quick - change nut Balancer Lead Screw Basic operation of tire balancer 1. turn on the power switch on the left side of the machine to display 411, and then the display 9,10 to A ","8.0". 2.
  • Page 8 4. Enter the L value data Measure the width of the cali per in the attachment , press the button to input the data on the cali per into the display , when the display is " L" 5. input D value data After confirming the rim diameter, press the button to enter the data into the display 10, where the display 9 is D"...

  • Page 9: Function Select

    10. Repeat the operation steps 6 to 9 until 9,10 shows "00". 11 . Remove the wheel from the balance rotation shaft and end the operation procedure . Function Select When this light is on, it is suitable for other tires on both sides of motorcycle tires or rims which can not be balanced When this light is on, it is suitable for the alloy ring tire with the balance block attached to the shoulder of the rim.
  • Page 10 BY Series Balance Computer Self-Def code 1. no rotation signal, motor does not turn or position sensor position is wrong, sensor bad and plug contact, computer board bad, etc. 2., the coil speed is less than 60 rpm, during the measurement of the computer phone. Too loose and too tight tires and belts can cause errors.

  • Page 11: Main Technical Specification

    Main Technical Specification Motor 110 V, 60 Hz, 1 Ph, 1.5 HP ( 1.1 kW ) Working Temperature 32 ℉ - 122 ℉ ( 0 ℃ - 50 ℃ ), humidity ≤ 80 % Cycle Time 6 to 9 seconds Data Entry Keypad Balancing Modes...
  • Page 12 General common faults and troubleshooting methods : Failure performance Fault cause Remedy 1.Check external circuit 220v 1.Check the external power for normal . supply. 2.power supply board failure. 2.Replace the power board. Not on display 3.power supply board to the 3.Check the plug connection.
  • Page 13 Method of adjusting three parameter values: In normal use, if there is too much or uneven lead block phenomenon, first of all, if the above phenomenon occurs under self-calibration, then adjust the parameters of the triplet. 1. adjustment angle SFA value: after self-calibration, it is found that the position of 100g lead block is not directly below the spindle or the value is not correct, Can use this function to see 100 grams of lead block imitation off the spindle about how many degrees.
