Summary of Contents for Unicare Health KRATOS 320
- Page 1 KRATOS 320 Mobile Patient Lifting Hoist Instruction & Safety Manual Please read this manual before operation, for maintenance instructions and safe usage The enabling power of applied knowledge...
-
Page 2: Table Of Contents
KRATOS 320 Mobile Patient Lifting Hoist Instruction & Safety Manual Contents Overview Important Saftey Considerations Assembly Instructions Hoist Operation Actuator Charging Charging Indicator Display External Charging Unit Charging Do’s and Don’ts Lifting Procedures Moving the Patient general Maintenance Trouble Shooting Specifi... -
Page 3: Overview
360° at full lift height , thus making the carers job easier and safer. The KRATOS 320 lifting range allows patients to be lifted from the fl oor, bed or chair with ease and safety. -
Page 4: Important Saftey Considerations
The KRATOS 320 compact mobile patient lifting hoist has been designed to lift and transfer a less able person with the assistance of a carer. The KRATOS 320 should be used with one of the ALLEGRO range of patient slings, as assessed by a competent trained person. - Page 5 Mast Push Handle Spreader Bar Actuator Battery & Control Box Base Chassis 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au...
-
Page 6: Assembly Instructions
Plug the lift actuator cable into port 1 positioned on the underside of the control box, ensuring it is driven fi rmly home in the socket. Your KRATOS 320 hoist uses an electric leg adjustment; plug the leg actuator lead into port 2 positioned on the underside of the control box. -
Page 7: Hoist Operation
When either button is released the jib will remain in position. • The KRATOS 320 hoist incorporates an actuator driven leg opening adjustment. Two buttons will be seen on the handset with arrows and symbolised legs indicating the direction of travel. This function allows an unrestricted range of leg adjustment. -
Page 8: Actuator
Charging The KRATOS 320 is supplied with a LINAK external wall mount charger. This is powered by plugging the 3 pin plug into a standard 240V ac outlet To recharge the battery pack, perform the following steps Release battery pack from control box by pulling the handle on the pack towards you. -
Page 9: External Charging Unit
KRATOS External Charging Unit Charging Do’s & Don’ts Do charge the battery whenever possible. This will extend the battery life. A large number of cycles can be obtained from operating on the batteries, but battery lifetime is reduced with frequent discharging. •... -
Page 10: Lifting Procedures
KRATOS 320 Mobile Patient Lifting Hoist Instruction & Safety Manual Lifting Procedures • Carer should be fully conversant and trained in the use of lifter and sling. This will decrease patient apprehension and increase their co-operation and overall safety of the lifting process. -
Page 11: General Maintenance
General Maintenance To prolong the working life of the lifter and for trouble free operation it is recommended that periodic inspections should be performed routinely and as often as necessary. Periodic inspections should be performed by a person who is suitably qualifi ed and well acquainted with the design, use and care of patient lifting hoists. -
Page 12: Trouble Shooting
KRATOS 320 Mobile Patient Lifting Hoist Instruction & Safety Manual Trouble Shooting WARNING TROUBLE SHOOTING SHOULD ONLY BE CARRIED OUT BY ALLEGRO CONCEPTS AUTHORISED PERSONNEL FAMILIAR WITH BOTH USE, ELECTRICAL AND MECHANICAL FEATURES OF PATIENT LIFTING HOISTS. The following is a guideline only to general trouble shooting. -
Page 13: Specifi Cations
Specifi cation Safe working load (SWL) 320kg Base length 1500mm External base width 760mm Internal base width closed 640mm Internal base width open 1060mm Maximum internal length 920mm Base width adjustment Electric Adjustment Base height / under bed clearance 155mm Minimum height of spreader bar 575mm Maximum height of spreader bar... -
Page 14: Warranty
KRATOS 320 Mobile Patient Lifting Hoist Instruction & Safety Manual Warranty ALLEGRO CONCEPTS PTY LTD warrants its products to be free from defects in materials and workmanship under normal use and service and will within the period stated below, from the date of... -
Page 15: Slings
Slings ALEGRO CONCEPTS manufactures a large range of patient lifting slings in both mesh and fabric to suit the ALLEGRO range of patient lifting hoists. A range of custom made to specifi cation slings are available on request. Sling Sizes Available X small, small, medium, large, X large, XX large Main Sling Categories General Purpose Sling... -
Page 16: Key Symbols
KRATOS 320 Mobile Patient Lifting Hoist Instruction & Safety Manual Key Symbols The following symbols are used on the lifter and attachments including the comfort range of GP and TILT/PIVOT SLINGS. SWL Safe working load: this symbol represents the maximum load the lifter, sling or attachment is rated to for safe operation. -
Page 17: Log Book
Log Book Service Type Condition Report Date: Inspection by: Signature: Action Taken Service Type Condition Report Date: Inspection by: Signature: Action Taken 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au... - Page 18 KRATOS 320 Mobile Patient Lifting Hoist Instruction & Safety Manual Log Book Service Type Condition Report Date: Inspection by: Signature: Action Taken Service Type Condition Report Date: Inspection by: Signature: Action Taken 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au...
- Page 19 Log Book Service Type Condition Report Date: Inspection by: Signature: Action Taken Service Type Condition Report Date: Inspection by: Signature: Action Taken 08 9351 7500 info@unicarehealth.com.au www.unicarehealth.com.au...
- Page 20 PO Box 82 Bentley WA 6982 Authorised Distributor T 08 9351 7500 F 08 9350 5299 info@unicarehealth.com.au www.unicarehealth.com.au...
