Canberra 3102D User Manual

Hv power supply
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model 3102D
HV Power Supply
User's Manual
9231570A

Advertisement

Table of Contents
loading

Summary of Contents for Canberra 3102D

  • Page 1 Model 3102D HV Power Supply User’s Manual 9231570A...
  • Page 2 Copyright 2004, Canberra Industries, Inc. All rights reserved. The material in this document, including all information, pictures, graphics and text, is the property of Canberra Industries, Inc. and is protected by U.S. copyright laws and international copyright conventions. Canberra expressly grants the purchaser of this product the right to copy any material in this document for the purchaser’s own use,...

  • Page 3: Table Of Contents

    Table of Contents 1. Introduction ......1 2. Controls and Connectors ..... . 2 3.
  • Page 4 Notes...

  • Page 5: Introduction

    The 3102D can withstand any overload or short circuit for an indefinite period of time. It can be set using an internal jumper to allow for a manual reset or an automatic reset when the fault condition is removed.

  • Page 6: Controls And Connectors

    Controls and Connectors 2. Controls and Connectors This is a brief description of the front panel controls and connectors. For more detailed information, refer to Appendix A, Specifications. Figure 1 Front Panel Controls...
  • Page 7 This is a brief description of the rear panel connectors. For more detailed information, refer to Appendix A, Specifications. Figure 2 Rear Panel Controls...
  • Page 8 Controls and Connectors This is a brief descriptions of the internal controls. For more detailed information, re- fer to Appendix A, Specifications. Figure 3 Internal Controls...

  • Page 9: Operating Instructions

    Installation 3. Operating Instructions The Model 3102D is factory set for positive output polarity. If negative polarity is re- quired, change the internal polarity board before installing the unit in the NIM bin (re- fer to the Internal Controls section, below, for instructions).

  • Page 10: Polarity Selection

    STATUS indicator lights when the output has been inhibited. Jumper J5 The INHIBIT input is compatible with all Canberra preamps for either position of Jumper plug J5; it isn’t necessary to set jumper plug J5 to match the HV INHIBIT logic high level of the associated Canberra preamp.

  • Page 11: Automatic Overload Shutdown

    B, the output will automatically resume when the fault condition is removed. Setup After setting the internal controls, install the Model 3102D in the NIM bin. Connect the load to the appropriate rear panel SHV connector, set the HV ON/OFF switch to OFF, and set the VOLTAGE control to zero.

  • Page 12: Preventive Maintenance

    Operating Instructions Preventive Maintenance Preventive maintenance is not required for this unit. When needed, the front panel of the unit may be cleaned. Remove power from the unit before cleaning. Use only a soft cloth dampened with warm water and make sure the unit is fully dry before restoring power.

  • Page 13: Circuit Description

    4. Circuit Description A functional schematic of the Model 3102D is included at the rear of the manual. The high voltage module is basically a dc to dc converter which converts low voltage dc power to a high voltage dc output. This output voltage is highly regulated and filtered, and can be varied by the front panel VOLTAGE control.

  • Page 14: Specifications

    A. Specifications Inputs INPUT POWER – The Model 3102D is powered from a standard NIM Bin and power supply, such as the Model 2100, 2000 or 1000. INHIBIT – Logic low or ground inhibits the HV outputs; max logic low ≤0.7 V; logic high ≥1.3 V or open circuit enables.

  • Page 15: Performance

    Performance INHIBIT – LED indicates Inhibit status. OVERLOAD – LED indicates overload status. Performance RIPPLE AND NOISE – ≤3 µV peak to peak at 1 µA. OUTPUT STABILITY – Long term drift of output voltage is ≤0.01%/hr. and ≤0.02%/8 hr. at constant input line voltage, load, and ambient temperature after a 30 minute warmup.

  • Page 16: Power Requirements

    Specifications Power Requirements +24 V – 70 mA +12 V – 160 mA* –24 V – 10 mA –12 V – 150 mA *With Brightness Control J4 set to HI, +12 V will draw 265 mA, which exceeds the normal Bin allotment of 167 mA for a single-width module. Physical SIZE –...

  • Page 17: Installation Considerations

    • Compliant grounding and safety precautions for any internal power distribution • The use of CE compliant accessories such as fans, UPS, etc. Any repairs or maintenance should be performed by a qualified Canberra service representative. Failure to use exact replacement components, or failure to reassemble the unit as delivered, may affect the unit’s compliance with the specified EU...
  • Page 18 Installation Considerations Notes...
  • Page 19 Canberra (we, us, our) warrants to the customer (you, your) that for a period of ninety (90) days from the date of shipment, software provided by us in connection with equipment manufactured by us shall operate in accordance with applicable specifications when used with equipment manufactured by us and that the media on which the software is provided shall be free from defects.
